JRC SAW FILTER
Application
420MHz PAGER
Electrical Specification: (Table 1)
The device characteristics are measured in the circuit shown in Fig.1.
Table 1. Electrical Specifications
Item
Input and Output Impedance
Nominal Center Frequency (f0)
Insertion Loss
Response Variation
Input and Output VSWR
Out of Band Rejection
(Relative to Through Level)
Maximum Rating: (Table 2)
Table 2. Maximum Ratings
Item
Maximum Input Power
Maximum DC Voltage
Operating Temperature Range
Storage Temperature
Mechanical Specifications: (Fig.2)
Package is designed as small as 5.2x4.5x1.5[mm
Notice:
This part is electrostatic discharge sensitive and may be damaged by improper handling.
Communications Equipment Marketing Department
http://www.jrc.co.jp/jp/product/device/saw/index.html (Japanese)
http://www.jrc.co.jp/eng/product/saw/index.html(English)
NSVS670
410~430MHz
410~430MHz
410~430MHz
380MHz
500MHz
(Operating Temperature Range: -10~+60ºC)
Communications Equipment Division
10-1, Nishi-Shinjuku 6-chome, Shinjuku-ku,
Tokyo, 160-8328 Japan
Tel. +81 3-3348-3845
Fax. +81 3-3348-3935
Spec.
50Ω
420MHz
4.0dB max.
2.0dB max.
2.5 max.
40dB min.
40dB min.
Rating
+20dBm
7.5V
-10~+60ºC
-30~+85ºC
3
] for SMD (Surface Mount Device) type.
NSVS670 Nov. 2004
Typ.
• |
• |
3.1dB
0.9dB
1.7
45dB
50dB
