JRC SAW FILTER
Application
1575.42MHz GPS
Electrical Specification: (Table 1)
The device characteristics are measured in the circuit shown in Fig.1.
Table 1. Electrical Specifications
Item
Input and Output Impedance
Nominal Center Frequency (f0)
Insertion Loss
Response Variation
Input and Output VSWR
Out of Band Rejection
(Relative to
Through Level)
Maximum Rating: (Table 2)
Table 2. Maximum Ratings
Item
Maximum Input Power
Maximum DC Voltage
Operating Temperature Range
Storage Temperature
Mechanical Specifications: (Fig.2)
Package is designed as small as 2.0x1.6x0.65[mm
Notice:
This part is electrostatic discharge sensitive and may be damaged by improper handling.
Communications Equipment Business Department
http://www.jrc.co.jp/jp/product/device/saw/index.html (Japanese)
http://www.jrc.co.jp/eng/product/saw/index.html (English)
NSVS1204
1574.42~1576.42MHz
1574.42~1576.42MHz
1574.42~1576.42MHz
DC~1000MHz
1500MHz
1675MHz
1800~3000MHz
Sales and Marketing
10-1, Nishi-Shinjuku 6-chome, Shinjuku-ku,
Tokyo, 160-8328 Japan
Tel. +81 3-3348-3845
Fax. +81 3-3348-3935
Spec.
-
-
1.6dB max.
0.8dB max.
1.8 max.
25dB min.
30dB min.
15dB min.
23dB min.
(Operating Temperature Range: -40~+85ºC)
Rating
+10dBm
7.5V
-40~+85ºC
-40~+95ºC
3
] for SMD (Surface Mount Device) type.
NSVS1204 Mar. 2007
Typical
50Ω
1575.42MHz
1.1dB
0.1dB
1.2
28dB
35dB
19dB
27dB

Advertisement

loading

Summary of Contents for JRC NSVS1204

  • Page 1 NSVS1204 Mar. 2007 JRC SAW FILTER NSVS1204 Application 1575.42MHz GPS Electrical Specification: (Table 1) The device characteristics are measured in the circuit shown in Fig.1. Table 1. Electrical Specifications Item Spec. Typical Input and Output Impedance 50Ω Nominal Center Frequency (f0) 1575.42MHz...
