JRC SAW FILTER
Application
380MHz WCDMA
Electrical Specification: (Table 1)
The device characteristics are measured in the circuit shown in Fig.1.
Table 1. Electrical Specifications
Parameter
Input and Output Impedance
Nominal Center Frequency (f0)
Pass Bandwidth
Insertion Loss
Response Variation
Group Delay Variation
Out of Band Rejection
Maximum Rating: (Table 2)
Table2. Maximum Ratings
Item
Maximum Input Power
Maximum DC Voltage
Operating Temperature Range
Storage Temperature
Mechanical Specifications:
Package is designed as small as 13.3x6.5x1.8[mm
This part is electrostatic discharge sensitive and may be damaged by improper handling.
Communications Equipment Marketing Department
http://www.jrc.co.jp/jp/product/device/saw/index.html (Japanese)
http://www.jrc.co.jp/eng/product/saw/index.html (English)
NSVS1115
378.08~381.92MHz
378.08~381.92MHz
378.08~381.92MHz
350.0~370.0MHz
370.0~375.0MHz
385.0~410.0MHz
(Operating Temperature Range: -10~+75ºC)
Rating
+10dBm
7.5V
-10~+75ºC
-20~+85ºC
Communications and Equipment Division
10-1,Nishi-Shinjuku 6-chome Shinjuku-ku,
Tokyo. 160-8328 Japan
Tel. +81 3-3348-3845
Fax. +81 3-3348-3935
NSVS1115 Jan. 2005
Spec.
-
-
380MHz
-
3.84MHz
18.5dB max.
17.5dB
1.2dB max.
0.9dB
200ns max.
160ns
50dB
40dB
50dB
3
] for SMD (Surface Mount Device) type.
Typ.
50Ω
57dB
42dB
58dB
Advertisement
Table of Contents
Related Manuals for JRC NSVS1115
Summary of Contents for JRC NSVS1115
- Page 1 NSVS1115 Jan. 2005 JRC SAW FILTER NSVS1115 Application 380MHz WCDMA Electrical Specification: (Table 1) The device characteristics are measured in the circuit shown in Fig.1. Table 1. Electrical Specifications Parameter Spec. Typ. Input and Output Impedance 50Ω Nominal Center Frequency (f0)
- Page 2 NSVS1115 Jan. 2005 ‚ ‚ ‚ ƒ ¶ *6.8nH ‚ U 18pF ƒ ¶ *10nH ‚ T ‚ ‚ ‚ ‚ 18pF *murata LQW18A series Fig.1 Measuring circuit 13.30±0.20 (1.26±0.13) J4Y1 1115 (R0.3) [4×] Marking (1) Manufacture's Mark (2) Lot Number...
- Page 3 NSVS1115 Jan. 2005 Notice 1. Use this component within operating temperature range. It might not be satisfied with electrical specification without operating temperature range. When it is used less than -10ºC or more than +75ºC, it might be a cause of degradation or destruction of the component.
- Page 4 NSVS1115 Jan. 2005 FREQUENCY CHARACTERISTICS Frequency [MHz] 2000 1800 1600 1400 1200 1000 Frequency [MHz]...
