Desa 28BN Owner's Operation And Installation Manual

Desa propane/lp gas outdoor patio heater owner's operation and installation manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
For more information, visit www.desatech.com
For more information, visit www.desatech.com
Adjustable Temperature Settings:
Low - 20,000 Btu
High - 24,000 Btu
WARNING: For Outdoor Use Only
WARNING: Read and understand this
manual before assembling, starting, or ser-
vicing heater. Improper use of heater can
cause serious injury, property damage, or
death. Keep this manual for future reference.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, immediately call your
gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
Fill In For Your Records
Model No. ___________________
(Located on side panel)
Serial No. ___________________
(Located near piezo ignitor)
Date of Purchase _____________
PROPANE/LP GAS OUTDOOR PATIO HEATER
TM
OWNER'S OPERATION AND INSTALLATION MANUAL
LISTED
Gas-Fired Infrared Patio Heater
28BN
Save this manual for future reference.
Save this manual for future reference.
