- Page 1 LED TV LH54** (M4 X L14) P/No: MFL69309604 (1605-REV01) www.lg.com Printed in Korea...
- Page 4 ANTENNA/ CABLE IN HDMI IN USB IN Satellite IN...
- Page 5 Satellite IN AV IN / OUT AUDIO / VIDEO : Depending on model / В зависимости от модели / Залежно від моделі / Үлгіге байланысты / Rusumiga qarab / Загвараас хамаарна COMPONENT IN AV IN VIDEO/Y L/MONO AUDIO R VIDEO/Y L/MONO AUDIO R...
- Page 6 AUDIO / VIDEO COMPONENT IN AV IN VIDEO/Y L/MONO AUDIO R VIDEO/Y L/MONO AUDIO R VIDEO AUDIO VIDEO L/MONO AUDIO R...
- Page 8 43LH540V-ZD 58.7 43LH541V-ZD 43LH543V-ZA 49LH540V-ZD 1103 58.7 13.4 13.1 49LH541V-ZD 49LH543V-ZA...
- Page 9 (Только для России) Данные по энергоэффективности для моделей телевизоров LG * Указанные модели телевизоров не имеют «выключенного режима». Для полного отключения телевизора - отсоедините его от сети питания. Потребляемая мощность Удельная мощность Потребляемая мощность изделием в Модель изделием в режиме рабочего режима: Вт/см выключенном режиме ожидания: Вт 43LH540V-ZD 0.012 43LH541V-ZD 43LH543V-ZA отсутствует 49LH540V-ZD 0.011 49LH541V-ZD...
- Page 11 OWNER’S MANUAL Safety and Reference LED TV* * LG LED TV applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. www.lg.com *MFL69309718* P/NO : MFL69309718 (1603-REV01) Printed in Korea...
-
Page 12: Safety Instructions
Safety instructions Please read these safety precautions carefully before using the product. Make sure to connect Mains cable to compliant AC mains socket with Grounded earth pin. (Except for devices which are not grounded on WARNING earth.) Otherwise possibility you may be electrocuted or injured. Insert power cable plug completely into wall socket otherwise if not Do not place the TV and/or remote control in the following secured completely into socket, fi re ignition may break out. - Page 13 Do not drop the product or let it fall over when connecting external Do not drop metallic objects such as coins, hair pins, chopsticks or wire devices. Otherwise, this may result in injury or damage to the product. into the product, or inflammable objects such as paper and matches. Children must pay particular attention.
- Page 14 Only use an authorized AC adapter and power cord approved by LG Electronics. Otherwise, this may result in fire, electric shock, If you install the TV on a stand, you need to take actions to prevent the malfunction or product deformation.
- Page 15 If you intend to mount the product to a wall, attach VESA standard mounting interface (optional parts) to the back of the product. When you install the set to use the wall mounting bracket (optional parts), fix it carefully so as not to drop. Signal from Remote Control can be interrupted due to external/internal Only use the attachments / accessories specified by the manufacturer.
- Page 16 As long as this unit is connected to the AC wall outlet, it is not disconnected from the AC power source even if you turn off this unit by SWITCH. Prevent dust collecting on the power plug pins or outlet. This may cause a fire hazard.
- Page 17 Preparing NOTE This panel is an advanced product that contains millions of pixels. • Image shown may differ from your TV. You may see tiny black dots and/or brightly coloured dots (red, blue • Your TV’s OSD (On Screen Display) may differ slightly from that or green) at a size of 1 ppm on the panel.
-
Page 18: Lifting And Moving The Tv
CAUTION • Do not use any unapproved items to ensure the safety and product life span. • Any damage or injuries caused by using unapproved items are not covered by the warranty. • When transporting the TV, do not expose the TV to jolts or • ... -
Page 19: Mounting On A Table
Securing the TV to a wall Basic functions Power On (Press) (This feature is not available for all models.) Power Off (Press and hold) Volume Control Programmes Control 1 If the Menu button is on the screen, pressing and holding the button will let you exit the Menu. -
Page 20: Mounting On A Wall
We recommend the use accumulating dust and dirt. (Only when the item of the following of LG’s wall mount bracket. LG’s wall mount bracket is easy to move with form is provided) cables connected. When you do not use LG’s wall mount bracket, please... -
Page 21: Antenna Connection
CI module connection NOTE • The external device connection may differ from the model. (Depending on model) • Connect external devices to the TV regardless of the order of the View the encrypted (pay) services in digital TV mode. TV port. • ... -
Page 22: Remote Control
Remote control (Depending on model) The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully and use the TV correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching the ends to the label inside the compartment, and close the battery cover. -
Page 23: Automatically Setting Up Programme
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com. -
Page 24: Resetting Picture Settings
Fine-tuning Picture Mode • Colour Management System : This is a system that experts use when they adjust colour with a test pattern. They can select from (Settings) Picture Picture Mode Settings six colour areas (Red / Green / Blue / Cyan / Magenta / Yellow) This feature allows you to adjust the selected picture mode in detail. -
Page 25: Selecting Sound Mode
To use Eye Comfort Mode feature To synchronize audio and video (Settings) Picture Eye Comfort Mode (Settings) Sound AV Sync Adjustment If you turn this option on, colour temperature will be automatically [Depending on model] adjusted to reduce eye strain. Synchronizes video and audio directly when they do not match. - Page 26 To remove the USB device • If you switch to another input, the SIMPLINK device will stop. • If a third-party device with the HDMI-CEC function is also used, the Select the connected USB HDD from (HOME) Inputs and select SIMPLINK device may not work normally.
-
Page 27: Supported Video Formats
Supported Video Formats Supported Audio Formats • Maximum : 1920 x 1080 @ 30p (Only Motion JPEG 640 x 480 @ 30p) • File type : mp3 • .asf, .wmv [Bit rate] 32 Kbps - 320 Kbps [Video] MPEG-4 Part2, XViD, H.264/AVC, VC1(WMV3, WVC1), MP43 [Sample freq.] 16 kHz - 48 kHz [Audio] WMA Standard, WMA9(Pro), MP3, AAC, AC3 [Support] MPEG1, MPEG2, Layer2, Layer3... -
Page 28: To See Web Manual
To see web manual To obtain detailed User Guide information, please visit www.lg.com. External control device setup To obtain the external control device setup information, please visit www.lg.com. Troubleshooting Cannot control the TV with the remote control. • Check the remote control sensor on the product and try again. -
Page 29: Specifications
Specifications CI Module (W x H x D) 100.0 mm x 55.0 mm x 5.0 mm Operating Temperature 0 °C to 40 °C Operating Humidity Less than 80 % Environment condition Storage Temperature -20 °C to 60 °C Storage Humidity Less than 85 % (Depending on country) Digital TV... - Page 30 HDMI-DTV supported mode Component port connecting information Horizontal Vertical Resolution Frequency Frequency Component ports on the TV (kHz) (Hz) 31.46 59.94 640 x 480 31.50 60.00 31.47 59.94 Video output ports on 720 x 480 31.50 60.00 DVD player 720 x 576 31.25 50.00 37.50...
-
Page 31: External Control Device Setup
OWNER’S MANUAL EXTERNAL CONTROL DEVICE SETUP Please read this manual carefully before operating the set and retain it for future reference. www.lg.com... -
Page 32: Key Codes
KEY CODES key CODeS • This feature is not available for all models. Code Code Function Note Function Note (Hexa) (Hexa) CH +, PR + R/C Button List R/C Button CH -, PR - R/C Button Exit R/C Button Volume + R/C Button PIP(AD) R/C Button... -
Page 33: Usb To Serial Converter With Usb Cable
(TV) (PC) • LGTV supports PL2303 chip-based (Vendor ID : 0x0557, Product ID : 0x2008) USB to serial converter RS-232C IN which is not made nor provided by LG. (CONTROL & SERVICE) (PC) (TV) • It can be purchased from computer stores that carry accessories for IT support professionals. -
Page 34: Customer Computer
(TV) (PC) EXTERNAL CONTROL DEVICE SETUP (TV) (PC) Phone jack Type RS-232C IN • You need to purchase the phone-jack to RS-232 cable required for the connection between the PC and (CONTROL & SERVICE) (PC) (TV) the TV, which is specified in the manual. RS-232C IN (CONTROL &... -
Page 35: Communication Parameters
EXTERNAL CONTROL DEVICE SETUP Communication Parameters • Baud rate : 9600 bps (UART) • Stop bit : 1 bit • Data length : 8 bits • Communication code : ASCII code • Parity : None • Use a crossed (reverse) cable. Command reference list (Depending on model) DATA... -
Page 36: Transmission / Receiving Protocol
EXTERNAL CONTROL DEVICE SETUP Transmission / Receiving Protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] [Command 1] : First command to control the TV. (j, k, m or x) [Command 2] : Second command to control the TV. [Set ID] : You can adjust the [Set ID] to choose desired monitor ID number in option menu. Adjustment range in TV is 1 to 99. - Page 37 EXTERNAL CONTROL DEVICE SETUP * Commands may work differently depending on model and signal. 01. Power (Command: k a) Ack [d][ ][Set ID][ ][OK/NG][Data][x] ► To control Power *On or Off of the set. * In case of video mute on only, TV will display On Transmission[k][a][ ][Set ID][ ][Data][Cr] Screen Display(OSD).
- Page 38 EXTERNAL CONTROL DEVICE SETUP Data Min : 00 to Max : 64 * (Depending on model) Ack [i][ ][Set ID][ ][OK/NG][Data][x] 14. Bass (Command: k s) 09. Tint (Command: k j) ► To adjust Bass. ► To adjust the screen tint. You can also adjust in the AUDIO menu.
- Page 39 EXTERNAL CONTROL DEVICE SETUP Set ID = All = 00 5th Band 20(decimal) Data 00 & 01 = Channel Data is 10 = 00 0a Acknowledgement [v][ ][Set ID][ ][OK/NG][Data][x] Data 02 = Analog Antenna TV = 00 Result = ma 00 00 0a 00 * It depends on model, and can adjust when sound mode is EQ adjustable value.
- Page 40 EXTERNAL CONTROL DEVICE SETUP Number Data 05 = Digital Antenna TV = 02 - 22 : Antenna TV (DTV) – Don’t Use Physical Total = ma 00 00 00 11 00 01 02 Channel Number - 26 : Cable TV (CADTV) - Don’t Use Physical 2.
- Page 41 11 11 EXTERNAL CONTROL DEVICE SETUP 24. Input select (Command: x b) (Main Picture Input) ► To select input source for main picture. Transmission [x][b][ ][Set ID][ ][Data][Cr] Data X : don’t care 00 : DTV 01 : CADTV 02 : Satellite DTV 10 : ATV Ack [t][ ][Set ID][ ][OK][Data00][Data01][Data02] ISDB-BS (Japan)
- Page 42 EXTERNAL CONTROL DEVICE SETUP 27. Auto Configure (Command: j u) (Depending on model) ► To adjust picture position and minimize image shaking automatically. It works only in RGB (PC) mode. Transmission [j][u][ ][Set ID][ ][Data][Cr] Data 01 : Run Auto Configure Ack [u][ ][Set ID][ ][OK/NG][Data][x]...
