Installation Guide
Attach Screen Mounting Strips
Secure the strips (B) to the screen using appropriate hardware as per manual.
Pull Down Release Strip
Descend the release strip to prepare for screen detachment or adjustment.
Position and Cut Release Block/Strips
Place release block (C) and trim release strips to the correct length for mounting.
Remove TV Mount Cover
Detach the protective cover from the TV mounting bracket.
Drill Holes for Wall Mounting
Drill holes in the wall using a spirit level for accurate placement of the mount.
Screw Wall Mount to Wall
Fasten the wall mount (A) securely to the wall using screws.
Replace Mounting Cover
Reattach the cover onto the wall bracket after the screen is mounted.
Mount Screen on Wall Bracket
Hang the TV screen onto the installed wall bracket assembly.
Guarantee Information
Guarantee Period and Coverage
Details the lifelong guarantee for material and manufacturing defects.
Guarantee Claim Process
Instructions for submitting a warranty claim with proof of purchase.
Guarantee Exclusions
Lists conditions that void the product warranty.
