Vogel's WALL 3350 Installation Guide
Important Pre-Installation Warnings
Read all safety warnings before proceeding with the wall mount installation.
Prepare Screen for Mounting
Position strips (D) on the screen and screw them on, ensuring no connectors are covered.
Assemble Mounting Bars
Loosen bolts on strips (D), remove caps (Q), then slide bars (C) onto strips (D).
Secure Mounting Assembly
Tighten bolts, replace caps (Q) on bars (C), and prepare for wall mounting.
Wall Drilling and Bracket Installation
Use drilling template for holes, then screw wall mount (A) onto the wall.
Attach Screen to Wall Bracket
Place the TV screen onto the wall mount (A) and tighten the securing bolts (L).
Cable Management Setup
Install cable guide (S), route cables, and attach cover (F) for tidy cable management.
Final Covers and Tilt Adjustments
Install covers (B) and adjust screen tilt using bolt X or Z if necessary.
