Summarization of Contents
Installation Location Requirements
Room Dimensions and Outlet Box Check
Verify room clearances and ensure a secure, fan-rated outlet box for safe installation.
Ceiling Angle and Mounting Type
Determine if standard or angled mounting is needed based on ceiling slope.
Angled Mounting Kit Determination
Guide to check if an angled mounting kit is required for sloped ceilings.
Ceiling Bracket Installation
Option 1: Machine Screws Mounting
Secure the bracket using machine screws and washers to the outlet box.
Option 2: Wood Screws Mounting
Secure the bracket using wood screws and washers to the support structure.
Downrod Assembly and Installation
Prepare Downrod: Remove Setscrew
Remove the pre-installed setscrew from the downrod assembly before insertion.
Install Downrod: Pass Wires and Tighten
Thread wires through downrod, hand-tighten onto motor, trim wires to 8 inches.
Secure Downrod: Tighten Setscrew
Tighten the setscrew firmly with pliers to prevent fan fall hazard.
Hanging the Ceiling Fan
Position Canopy Over Downrod and Wires
Slide the canopy over the downrod and wires before placing it into the bracket.
Seat Downrod Ball in Ceiling Bracket
Ensure the downrod ball is correctly seated in the ceiling bracket for stability.
Wiring the Ceiling Fan
Connect Ceiling to Receiver Wires
Connect black, white, and grounding wires from ceiling to receiver.
Connect Receiver to Fan Wires
Connect yellow, blue, and white wires from receiver to fan motor.
Connect Grounding Wires
Connect all grounding wires (green, bare copper) together for electrical safety.
Canopy Installation
Align and Secure Canopy
Fit the canopy, align screw holes, and insert two canopy screws.
Blade Installation
Attach Blades to Blade Irons
Secure each blade to its iron using washers and blade assembly screws.
Light Fixture Preparation
Remove Shipping Hardware from Light Kit
Remove the pre-installed fixture screw and red flag from the light kit assembly.
Separate Light Fixture Assembly
Carefully detach the light fixture from its assembly and set it aside.
Light Kit Assembly
Install Light Kit Screws and Feed Wires
Install screws, feed wire plug through housing, and twist counterclockwise.
Connect Wiring and Align Keyhole Slots
Connect colored wire connectors and align light kit keyhole slots with screws.
Secure Light Kit Fixture
Ensure all screws are tight to securely attach the light fixture.
Glass Globe Installation
Install Bulbs and Prepare Glass
Insert bulbs and align glass globe notches with light kit tabs.
Attach and Secure Glass Globe
Secure the glass globe by turning it clockwise for proper engagement.
Remote Control Preparation
Access and Replace Remote Battery
Remove screw to access battery compartment and replace with a CR2032 battery.
Remote Control Cradle Mounting
Mount Cradle Using Adhesive Strip
Secure the cradle bracket to the wall using the adhesive strip for convenient access.
Mount Cradle Using Screws
Mount the cradle bracket using screws, potentially with drywall anchors for secure fitting.
Reversing Fan Airflow Direction
Locate and Operate Reverse Switch
Turn fan off, remove glass, slide switch to change airflow direction (updraft/downdraft).
Hunter Fan Limited Warranty
Warranty Service and Claims
Instructions on how to obtain warranty service, including required proof of purchase.
Covered Warranty Items
Details on motor, one-year parts, and specific light kit warranty coverage.
Warranty Exclusions and Limitations
Lists items and conditions not covered by the warranty, including labor.
State Law and Warranty Rights
Information on how state laws impact specific warranty rights.
Downrod Replacement Procedure
Remove and Reassemble Downrod
Detailed steps for removing the standard downrod and assembling with a new one.
Troubleshooting Common Issues
Fan Not Working
Steps to diagnose and fix issues where the fan is not operating.
Excessive Fan Wobbling
Solutions for excessive fan wobbling, including checking blades and seating.
Noisy Fan Operation
Tips to address noisy fan operation, such as checking blade installation.
Remote Control and Interference Issues
Troubleshooting for erratic remote control or multiple remote interference.
