- Page 1 Dempsey Installation Manual Model: 50283 Brushed Nickel 59241 Brushed Nickel 59242 Fresh White 59447 Noble Bronze Fan weight ±2 lbs: 19.8 lbs (9.0 kg) ©2019 Hunter Fan Co. PG3774 r042519...
- Page 2 - All wiring must be in accordance with national and local electrical codes ANSI/NFPA 70. If you are unfamiliar with wiring, use a qualified electrician. c.2 - Use only Hunter replacement parts. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 We recommend that you pull everything out of the box and lay it out. We have grouped the drawn components below with the hardware you’ll need for those Hunter Pro Tip: parts. The screws below are drawn to scale to make it easier to identify what piece of hardware is needed to install each component.
-
Page 4: Choosing The Right Installation Location
Installing the Ceiling Bracket You have two options for installation. Pick which one works best for your location. Remove any existing bracket prior to installation. Only use the provided Hunter ceiling bracket that came in your fan’s box. Do this first! -
Page 5: Hanging The Fan
1886 Installing the Top Housing 3/8” Top Housing Screw 8” Grounding Screw Grounding Screw The wires can be cut, but leave at least 8” extending from the top of the canopy. Install the top housing screws. Install the grounding screw in the smaller screw hole. -
Page 6: Wiring The Fan
If you are unfamiliar with wiring or uncomfortable doing it yourself, please contact a qualified electrician. You are going to need these: Hunter Pro Tip: Here is how to connect the wires: 4 Wire Nuts (these are in the... -
Page 7: Installing The Canopy
1886 Installing the Canopy 2 of 3 Canopy Screws Hold the canopy up with the screw holes Swing the fan up to align the Place the receiver inside the aligned. Partially install two canopy screws, canopy screw holes with the canopy. -
Page 8: Assembling The Light Kit
1886 Assembling the Switch Housing 2 of 6 1 of 6 Light Kit Screw Light Kit Screw Insert the third screw, found in the hardware bag, into place and then tighten all three screws. WARNING Feed the wire plug through the center hole of the Screw two housing assembly screws from the hood, then wrap keyhole slots around the screws hardware bag halfway into the motor housing. -
Page 9: Preparing The Remote Control
1886 Preparing the Remote Control The remote control is already For your convenience, a remote function card is paired for use. packed in with your remote. Fan Medium Fan Off Fan High Fan Low Light On/Off Battery Door The remote transmitter should already be paired To turn on fan, press a fan speed Phillips Head Screw... -
Page 10: Limited Lifetime Warranty
Hunter instructions, accidental damage caused by the fan owner or related parties, Please do not ship your fan or any fan parts to Hunter. Delivery will be refused. modifications to the fan, improper or incorrectly performed maintenance or repair,... -
Page 11: Troubleshooting
“How do I properly install multiple remote-controlled fans?” for information on how to correct this issue. Hunter Pro Tip: Cleaning the Fan Use soft brushes or cloths to prevent scratching. Cleaning products may damage the finishes.
