- Page 2 Before you start, you should prepare the following items: One Windows-based PC with print server setup CD One printer One printer cable One HUB Wired Network with Print Server: Print Server Printer Computer Computer Computer Hardware Installation: Turn off the printer’s power. Connect the print server to your printer with the supplied printer cable.
- Page 3 Choose Setup Wizard to install the print server and configure the connected printer.
- Page 4 Click Next, the wizard will automatically discover the print server. From the Select A Print Server screen, select the print server that you want to configure and click Next.
- Page 5 On the Change Settings screen, select No or Yes: Click No if you want the print server to keep using the default IP address and keep the default settings, and then click Next. IP address: 192.168.0.10 Subnet Mask: 255.255.255.0 Click Yes if you want change IP address to the print server, and then click Next. Note: The IP address of print server must be within the same subnet as your network adapter.
- Page 6 Click Add New Printer to launch Windows Add Printer Wizard.
- Page 7 Click Next and select Local Printer, make sure the Automatically detect and install my Plug and Play printer check box is NOT checked. Then click Next. 10. Make sure the Use the following port radio-button is clicked and select LPT1: (Recommended Printer Port) from the pull-down list.
- Page 8 11. Select Manufacturer and Printer from the lists of printer’s driver. Then click Next. 12. If you already have the printer’s driver installed, you will be asked whether to keep it or to replace it. Click Next. Supply a name for the printer and choose whether you want to make it your default printer.
- Page 9 13. Then, choose whether you want to share the printer with other network users, print a test page (please select No.), etc. Select the appropriate radio-button and click Next and Finish. 14. In the setup wizard, finish the installation by highlighting the installed printer in the Select a Printer list and click Next ->...
- Page 10 16. Right-click, select Properties -> Ports and verify that the print server’s port appears. 17. Go to General; click Print Test Page to verify the configuration.
- Page 11 18. Done. Note: If you wish to install more print servers, start setup wizard from your Windows Start menu: start -> All Programs -> Network Print Server -> PSWzard and repeat the installation procedure. All contents are subject to change without prior notice.
