Zonet ZPS1002 Quick Installation Manual

Linking Technology
Friendly Integration
Supports multiple protocols and all
popular operating system
Package Content:
ZPS1002
CD Driver w/Manual
Quick Installation Guide
AC Power Adapter
Toll-Free
1-888-883-8880
Zonet USA Corporation
19929 Harrison Dr. Walnut, CA 91789
Email: Sales@zonetusa.com
support@zonetusa.com
Web: www.zonetusa.com
PRINT SERVER
computer to share an USB printer. It provides users with an auto-
sensing 10/100Base-T port. It works with either 10BaseT or 100BaseT
networks. This unit also supports multiple protocols and multiple
operating systems, and it integrates Internet Printing Protocol (IPP) in
LAN/WAN or the Internet by specifying the device's URL. The built-in
web management feature provides more convenience by allowing the
user to configure and monitor via a web browser. This eliminates the
Performance & Flexibility
Integrates with 10Base-T, 100Base-TX.
100Mbps bandwidth for wired network
Specifications:
Standards
Printer
Interface
LAN Port
CPU/ SDRAM /
Flash ROM
LEDs
Protocol
OS Support
Management
Power
Dimension
Weight
Temperature
Humidity
Certification
| WIRED
USB 2.0 Print Server
The Zonet ZPS1002 – USB 2.0 Print Server allows any networked
this print server to allow users to print from any computer over a
need to place the printer right next to the computer.
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
USB 2.0, 1.1 Compliant USB Type A Port
10/100Mbps Auto-Negotiation UTP/STP RJ-45 Port
RDC R2886 133MHz / 2MByte / 1MKByte
Power, USB, Link/Act
TCP/IP, IPX, NetBEUI, AppleTalk, LPR, SMB over TCP/IP
Windows 98SE/Me/2000/XP/Vista,
Mac OS 8.1 or higher, UNIX/Linux, NetWare
(Bindery/NDS)
Web interface,
3.3V, 2A
73.16(Length) x 64.75(Width) x 28.39(Height) mm
58g
Operating: 0°~50°C
Storage: -5°~55°C
10%~90% (non-condensing)
CE, FCC
Information provided in this document pertains to Zonet products and is subject to change at any time, without notice.
ZPS1002
Cost Effective
Turns the stand-alone printer into a
network printer
Web-Browser Configuration
ZPS1002
Zonet Model:
