Summarization of Contents
Using the Bi Distillation Apparatus
Intended Use
Describes the apparatus's function, stages, distillate quality, and safety precautions.
Improper Use
Details prohibited operating environments and non-medical device classification.
Warranty, Initiation, and Transport
Warranty Information
Details on warranty claims and required unit identification.
Before Initiation
Highlights important information and safety indications for initial setup.
Transport and Setup Guidelines
Guidelines for safe transport, lifting, placement, and wall mounting.
Transport Protection and Operating Voltage
Removing Glass Condenser Protection
Steps to remove transport protection, clean, and re-assemble glass condenser and fittings.
Operating Voltage and Mains Connection
Details on voltage compatibility, mains connection, protection class, and fuse values.
Water Connections
Tap Water Inlet Connection
Instructions for connecting the tap water inlet with solenoid valve and hose clips.
Separate Water Supply Connections
Details for connecting and draining separate water supply.
Water Outlets and Initiation
Cooling Water and Boiler Drain Hoses
Connecting hoses for cooling water outlet and boiler drains, noting temperatures.
Apparatus Initiation Procedure
Steps for initial operation, opening valves, switching on main switch, and discarding initial distillate.
Functional Description
Double Distillation Process
Detailed explanation of the double distillation process and components.
Separate Water Supply Operation
How the apparatus works with an optional separate water supply.
Degassing Function
Explanation of how carbon dioxide is released from the unit.
Maintenance and Sterilising
Descaling Procedure
Procedure for descaling the apparatus using a specific chemical mixture or commercial agents.
Condenser Sterilisation Method
Method for sterilizing condensers by temporarily stopping cooling water flow.
Troubleshooting: Water Shortage and Pilot Lamps
Water Shortage Handling and Reset
How to handle water shortage, reset low water cut-off, and check float switches.
Pilot Lamp "Clean" Functionality
Explanation of the "Clean" pilot lamp, foam formation, and reset procedure.
Disposal of Old Units
Environmentally Sound Disposal Guidelines
Guidelines for responsible disposal and LAUDA-GFL's role.
Technical Data - Models PD 2 D, PD 4 D
PD 2 D Technical Specifications
Technical specifications for the PD 2 D model.
PD 4 D Technical Specifications
Technical specifications for the PD 4 D model.
Technical Data - Model PD 8 D
PD 8 D Technical Specifications
Technical specifications for the PD 8 D model.
Circuit Diagrams Overview
Circuit Diagram Component List
List of components used in the circuit diagrams with their references.
PD 2 D Circuit Diagram
Electrical schematic diagram for the PD 2 D model.
Circuit Diagrams - PD 4 D Versions
PD 4 D 220 V/3~ Wiring
Electrical schematic for the PD 4 D, 220 V/3~ version.
PD 4 D 400 V/3~ Wiring
Electrical schematic for the PD 4 D, 400 V/3~ version.
Circuit Diagrams - PD 8 D Versions
PD 8 D 220 V/3~ Wiring
Electrical schematic for the PD 8 D, 220 V/3~ version.
PD 8 D 400 V/3~ Wiring
Electrical schematic for the PD 8 D, 400 V/3~ version.
Connection to the Mains Supply
Mains Cable Colour Decoding
Guide to wire colours and their corresponding connections for different models.
On-site Electrical Fuse Recommendations
Details required on-site fuses for each model based on power and voltage.
Mains Supply Connection Examples
PD 2 D 230 V Mains Connection
Example wiring diagram for connecting the PD 2 D to 230 V mains.
Mains Supply Connection Examples (220 V/3~)
PD 4 D/PD 8 D 220 V/3~ (Switch)
Example wiring for PD 4D/PD 8D with a 220V/3~ switch.
PD 4 D/PD 8 D 220 V/3~ (CEE Plug)
Example wiring for PD 4D/PD 8D with a 220V/3~ CEE plug.
Mains Supply Connection Examples (400 V/3~)
PD 4 D/PD 8 D 400 V/3~/N/PE (Switch)
Example wiring for PD 4D/PD 8D with a 400V/3~ switch.
PD 4 D/PD 8 D 400 V/3~/N/PE (CEE Plug)
Example wiring for PD 4D/PD 8D with a 400V/3~ CEE plug.
List of Spare Parts
Spare Parts Diagram
Visual diagram showing numbered spare parts for the distillation apparatus.
Detailed Spare Parts List
Comprehensive list of part numbers and articles for all components.
Accessories and Options
Separate Water Supply Options
Information on factory-installed separate water supply systems with solenoid valves.
Water Filtration Accessories
Details on Dechlorite Filter and Phosphate Cartridge accessories.
Accessory Options and Control Switches
Pre-Filter and Wall Bracket Options
Information on pre-filters, spare candles, and wall brackets for filter systems.
Hose Sets and Level Control Switch
Description of hose sets and the optional level control switch for external tanks.
EC Declaration of Conformity
Conformity to EC Directives and Standards
Lists EC directives and standards the apparatus conforms to.
