Lennox MCB024S4S-1P Installation Instruction

Lennox MCB024S4S-1P Installation Instruction

Single-zone mini-split system

Advertisement

2021 Lennox Industries Inc.
©
Dallas, Texas, USA
General ..........................................................................1
Included Parts ...............................................................2
Model Number Identification .......................................3
Typical System Components .......................................4
System Dimensions .....................................................4
Outdoor Units ..............................................................4
Indoor Units .................................................................5
Indoor Unit Wall Mounts ..............................................5
System Clearances.......................................................5
Outdoor Unit ................................................................5
Indoor Unit ...................................................................5
Multiple Outdoor Units .................................................6
Indoor Unit Installation ................................................6
Unit Placement Considerations ...................................6
Installation of Wall Mounting Plate...............................7
Installation of Wall Sleeve............................................7
Outdoor Unit Installation .............................................8
Placement Considerations ...........................................8
Direct Sunlight and Rain Protection .............................9
Buried Refrigerant Pipe Protection ..............................9
Securing the Outdoor Unit ...........................................9
Refrigerant Piping Connections ................................10
Leak Test and Evacuation ..........................................12
Leak Test ...................................................................12
Triple Evacuation Procedure......................................12
Wiring Connections ....................................................12
Outdoor Unit .............................................................13
Indoor Unit .................................................................13
Unit Start-Up ...............................................................14
Service Information ....................................................14
Test Run ....................................................................15
Double-Check Line Set Connections .........................15
Indoor Unit Wiring Diagrams .....................................16
Outdoor Unit Wiring Diagrams ...................................17
INSTALLATION INSTRUCTION &
SERVICE INFORMATION
MCB and MWCB Series Units
SINGLE-ZONE MINI-SPLIT SYSTEM
(115V and 208/230V)
508241­01 12/2021
THIS MANUAL MUST BE LEFT WITH THE OWNER
FOR FUTURE REFERENCE
WARNING
Improper installation, adjustment, alteration, ser vice
or maintenance can cause property damage, personal
injury or loss of life.
Installation and service must be performed by a li­
censed professional HVAC installer (or equivalent) or a
service agency.
CAUTION
In order to avoid injury, take proper precaution when
lifting heavy objects.
General
Refer to the Product Specifications bulletin (EHB) for
additional product information. These instructions are
intended as a general guide and do not supersede local or
national codes in any way. Authorities having jurisdiction
should be consulted before installation.
This wall­mounted indoor unit is matched with an outdoor
air conditioner unit to create a mini­split system that uses
HFC­410A refrigerant.
Use of Mini-Split System During
Construction
Lennox does not recommend the use of its mini­split
systems during any phase of construction. Very low return
air temperatures, harmful vapors and operation of the unit
with clogged or misplaced filters will damage the system.
However, mini­split systems may be used for cooling of
buildings under construction, if the following conditions
are met:
Air filter must be installed in the system and must be
maintained during construction.
Air filter must be replaced upon construction comple­
tion.
The indoor wall unit assembly must be thoroughly
cleaned following final construction clean-up.
All mini-split operating conditions must be verified ac­
cording to these installation instructions.
