Summarization of Contents
Safety Information
Product Disposal Guidelines
Instructions for proper disposal of the electrical product as per EU and other collection systems.
Model Handling Precautions
Warning that the product is a model and not a toy, requiring careful handling.
Transformer Operating Requirements
Specifies voltage requirements for AC and DC operation using an approved transformer.
Locomotive Operation and Care
Lubrication and Running-In Procedure
Recommends lubricating wheelsets and a running-in period for optimal performance.
Rail Maintenance for Smooth Running
Emphasizes the importance of clean rails for ensuring good operational performance.
Wheelset and Traction Tire Service
Traction Tire Replacement Procedure
Details the process of removing the wheelset to replace the traction tire, including component removal.
PluX Interface Pin Assignments
F0f/F0r - Headlight Assignment
Assigns F0f/F0r to white headlights at the front and rear.
Train End Light Assignments (AUX1, AUX2)
Assigns AUX1 to train end light FS2 and AUX2 to FS1.
Driver Cab Light Assignments (AUX4, AUX5)
Assigns AUX4 to cab light FS1 and AUX5 to FS2.
Other Light Assignments (AUX3, AUX6, AUX7)
Assigns AUX3 to engine room light, AUX6 to front top, AUX7 to back top.
DC Version Specifics
Radio Interference Suppression
Explains that radio interference is suppressed in DC version if the track connector has a 680 nF capacitor.
Accessing Further Safety Information
Directs users to the website for safety instructions in other languages.
