OWNER'S OPERATION AND INSTALLATION MANUAL
NATURAL GAS "TUDOR" MODELS (V)T36NA SERIES
PROPANE/LP GAS "TUDOR" MODELS (V)T36PA SERIES
WARNING: If the information in this manual is not fol-
lowed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a quali-
fied installer, service agency or the gas supplier.
INSTALLER: Leave this manual with the appliance
CONSUMER: Retain this manual for future reference.
For more information, visit www.desatech.com
DIRECT-VENT FIREPLACE
AND CTDV36NRA
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Desa Tudor VT36NA Series
Summary of Contents for Desa Tudor VT36NA Series
- Page 1 DIRECT-VENT FIREPLACE OWNER’S OPERATION AND INSTALLATION MANUAL NATURAL GAS “TUDOR” MODELS (V)T36NA SERIES PROPANE/LP GAS “TUDOR” MODELS (V)T36PA SERIES WARNING: If the information in this manual is not fol- lowed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. —...
-
Page 2: Table Of Contents
Safety Information ... 2 Local Codes... 4 Product Identification ... 4 Product Features ... 4 Pre-Installation Preparation ... 5 Location of Termination Cap ... 7 Venting Installation Instructions ... 8 Fireplace Installation... 18 Operating Fireplace ... 27 Inspecting Burners... 30 WARNING: Improper in- stallation, adjustment, al- teration, service or main-... - Page 3 SAFETy INFORMATION Continued This fireplace must be installed by a qualified (cer- tified or licensed) service person. It has a sealed gas combustion chamber that uses a coaxial pipe (pipe within a pipe and having the same center) venting system. It brings in fresh air for combus- tion through the outer pipe and combustion gases are exhausted through the inner pipe.
-
Page 4: Local Codes
SAFETy INFORMATION Continued 2. If you smell gas • shut off gas supply • do not try to light any appliance • do not touch any electrical switch; do not use any phone in your building • immediately call your gas supplier from a neighbor’s phone. -
Page 5: Pre-Installation Preparation
LOCATION AND SpACE REqUIREMENTS Determine the safest and most efficient location for your DESA direct-vent fireplace. Make sure that rafters and wall studs are not in the way of the venting system. Choose a location where the heat output is not affected by drafts, air conditioning ducts, windows or doors. -
Page 6: Framing And Finishing
PRE-INSTALLATION PREPARATION Continued CLEARANCES Minimum clearances to combustibles for the fire- place are as follows: Back and sides 0" Perpendicular walls 6" Floor 0" Ceiling to louver opening 42" Front 36" Top of Standoffs 0" Vent (See venting instructions for specific venting clearances.) Combustible material with a maximum thickness of 5/8"... -
Page 7: Location Of Termination Cap
LOCATION OF TERMINATION CAP Fixed Closed TERMINATION CAP A = clearance above grade, veranda, porch, deck, or balcony [*12" (30.5 cm) minimum] B = clearance to window or door that may be opened [12" (30.5 cm) minimum] C = clearance to permanently closed window [minimum 12"... -
Page 8: Venting Installation Instructions
These models are tested and approved for use with DESA (direct-vent) pipe components and termina- tions as well as Simpson-Duravent direct-vent pipe components and terminations. The venting system must terminate on the outside of... -
Page 9: Installation Planning
VENTING INSTALLATION INSTRUCTIONS Continued INSTALLATION pLANNING There are two basic types of direct-vent in- stallation: • Horizontal Termination • Vertical Termination Horizontal Termination Installation IMPORTANT: Horizontal square terminations require only inner portion of wall firestop. Hori- zontal installations using round termination require exterior portion of wall firestop available only in vent kit HTK (see Figure 14, page 11). - Page 10 VENTING INSTALLATION INSTRUCTIONS Continued WARNING: Do not recess vent termination into any wall. This will cause a fire hazard. Noncombustible Exterior Wall: horizontal vent cap in the center of the 7 round hole and attach to the exterior wall with four wood screws provided.
- Page 11 VENTING INSTALLATION INSTRUCTIONS Continued Minimum Pipe Overlap 1 " Direct-Vent Pipe Wall Firestop Maintain 1" Minimum Air Space Around Outer Pipe When Penetrating a Wall 10" x 10" Framed Opening Exterior Wall with Vinyl Siding Figure 13 - Typical Horizontal Termination Cap Mounting with Additional Siding Standoff Installed Horizontal Termination Configurations...
-
Page 12: Snorkel Termination Installation
VENTING INSTALLATION INSTRUCTIONS CORNER AND ALTERNATE INSTALLATION Recommended Applications: • Corner ground floor installation • Ground floor installation where pipe vents horizon- tally through wall (over 12" horizontal pipe) • Basement installation where one foot clearance from ground to termination is possible Not to Exceed (H) Limits Square Termination... - Page 13 VENTING INSTALLATION INSTRUCTIONS HORIZONTAL SYSTEM INSTALLATION USING TWO 90° ELBOWS The following configurations show the minimum vertical rise requirements for a horizontal system using two 90° elbows. Venting with Two 90° Elbows Vertical (V) Horizontal (H 5' min. 2' max. 6' min.
-
Page 14: Installation For Vertical Termination
VENTING INSTALLATION INSTRUCTIONS Continued INSTALLATION FOR vERTICAL TERMINATION Note: Vertical restrictor must be installed in all vertical installations. 1. Determine the route your vertical venting will take. If ceiling joists, roof rafters or other framing will obstruct the venting system, consider an offset (see Figure 19) to avoid cut- ting load bearing members. - Page 15 VENTING INSTALLATION INSTRUCTIONS Continued 5. Place the flashing over the pipe section(s) extending through the roof. Secure the base of the flashing to the roof and framing with roof- ing nails. Be sure roofing material overlaps the top edge of the flashing as shown in Figure 19, page 14.
-
Page 16: High Altitude Installation
12' max. 18' max. 20' max. HIGH ALTITUDE INSTALLATION Your DESA direct-vent fireplace has been tested and ) = 40' max. approved for elevations from 0-2,000 feet (USA) and elevations from 0-4,500 feet (Canada). When installing this fireplace at an elevation... - Page 17 VENTING INSTALLATION INSTRUCTIONS Continued PARTS LIST FOR VENTING KITS AND COMpONENTS DESA Pipe & Vent Kits Number Description P47-6 6" Section Coaxial Pipe, Galvanized P47-12 12" Section Coaxial Pipe, Galvanized P47-24 24" Section Coaxial Pipe, Galvanized P47-36 36" Section Coaxial Pipe,...
-
Page 18: Fireplace Installation
FIREPLACE INSTALLATION CHECK GAS TYPE Use proper gas type for fireplace unit you are installing. If your gas supply is not correct, do not install fireplace. See retailer where you purchased the fireplace for proper fireplace according to your gas type or to purchase gas conversion kit (see Ac- cessories, page 36). - Page 19 FIREPLACE INSTALLATION Continued 9. Check to make sure power cord is completely clear of blower wheel and there are no other foreign objects in blower wheel. Turn blower on and check for operation. Turn blower off by turning knob fully counterclockwise before continuing.
-
Page 20: Installing Gas Piping To Fireplace Location
FIREPLACE INSTALLATION Continued 11. Peel off backing paper and stick supplied wiring diagram decal on firebox bottom ap- proximately 12" in front of blower (see Figure 27, page 19). Blower Wiring Diagram CAUTION: Label all wires prior to disconnection when servicing controls. -
Page 21: Connecting Fireplace To Gas Supply
FIREPLACE INSTALLATION Continued Installation must include an equipment shutoff valve, union, and plugged 1/8" NPT tap. Locate NPT tap within reach for test gauge hook up. NPT tap must be upstream from fireplace (see Figure 31). IMPORTANT: Install main gas valve (equipment shutoff valve) in an accessible location. - Page 22 FIREPLACE INSTALLATION Continued pRESSURE TESTING GAS SUppLY pIpING SYSTEM Test pressures In Excess Of 1/2 pSIG (3.5 kPa) 1. Disconnect fireplace and its individual equip- ment shutoff valve from gas supply piping system. Pressures in excess of 1/2 psig (3.5 kPa) will damage fireplace gas regulator.
- Page 23 FIREPLACE INSTALLATION Continued INSTALLING OpTIONAL WALL MOUNT SWITCH - GWMS2 1. Connect one terminal of 25 ft. wire for wall switch to TPTH terminal on the valve. Con- nect remaining wire terminal to the TH termi- nal on the valve. Make sure wire terminals are in positions on unit as pictured in Figure 36.
- Page 24 FIREPLACE INSTALLATION Continued REMOvING/REpLACING GLASS DOOR CAUTION: Do not operate this fireplace with a broken glass door panel or without the glass door panel securely in place. For replacement part informa- tion see Replacement Parts, page 36. CAUTION: Wear gloves and safety glasses while handling or removing broken glass.
-
Page 25: Brick Panels
FIREPLACE INSTALLATION Continued INSTALLING OPTIONAL BRICK LINER MODELS BL36DA(SA) AND BL36DHA(SA) WARNING: If fireplace has been running, turn off and un- plug fireplace. Let cool before installing brick liner. This brick liner kit is optional. You may purchase brick liner from your local retailer or see Acces- sories, page 36. - Page 26 FIREPLACE INSTALLATION Continued 6. Place log #6 (left log) onto two pins on left side of back and front log. See Figure 48. 7. Place lava rock along sides and front of firebox bottom in areas that are visible only. It is not necessary to use all of lava rock provided.
-
Page 27: Operating Fireplace
OPERATING FIREPLACE FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not fol- low these instructions exactly, a fire or explosion may result causing property damage, per- sonal injury or loss of life. A. This appliance is equipped with an ignition device which automatically lights the pilot. Do not try to light by hand. B. BEFORE LIGHTING smell all around the appliance area for gas. Be sure to smell next to the floor because some gas is heavier than... -
Page 28: Operating Fireplace
OPERATING FIREPLACE Continued MANUAL LIGHTING pROCEDURE 1. Remove glass door (see Removing/Replacing Glass Door, page 24.) 2. Follow steps 1 through 7 under Lighting Instructions, page 27. 3. Depress gas control knob and light pilot with match. 4. Keep gas control knob pressed in for 30 seconds after lighting pilot. After 30 sec- onds, release gas control knob. Follow steps 9 through 12 under Lighting Instructions, page 27. - Page 29 OPERATING FIREPLACE Continued 4. Press the POWER and LOCK buttons together to turn off the fireplace Note: Do not leave the hand-held remote in the AUTO mode close to the fireplace. The radiant heat from the fireplace will turn off the fireplace. Ideally, place the hand-held remote in the center of the room facing towards the fireplace. Note: Do not hold the hand-held remote for a long time. Body temperature will affect its operation in the AUTO mode.
-
Page 30: Inspecting Burners
INSPECTING bURNERS Check pilot flame pattern and burner flame pat- terns often. PILOT ASSEMBLY The pilot assembly is factory preset for the proper flame. Alterations may have occurred during ship- ping and handling. The pilot is located on the back right hand side of the burner. -
Page 31: Venting System
CLEANING AND MAINTENANCE Continued WARNING: Only parts sup- plied by the manufacturer should be used when replacing broken or damaged glass door panel (see Replacement Parts, page 36). This glass door panel is a complete unit. No substitute materials may be used. CAUTION: Wear gloves and safety glasses while handling or removing broken glass. -
Page 32: Troubleshooting
WARNING: Turn off heater and let cool before servicing. Only a qualified service person should service and repair heater. CAUTION: Never use a wire, needle, or similar object to clean pilot. This can damage pilot unit. Note: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM When ignitor button is pressed, there is no spark at pilot... -
Page 33: Troubleshooting
OBSERVED PROBLEM Pilot lights but flame goes out when control knob is released Burner does not light after pilot is lit Delayed ignition burner Burner backfiring during com- bustion Slight smoke or odor during initial operation 111250-01E TROUbLEShOOTING Continued POSSIBLE CAUSE 1. - Page 34 OBSERVED PROBLEM Heater produces a whistling noise when burner is lit Glass soots Fireplace produces a clicking/tick- ing noise just after burners are lit or shut off Remote does not function Fireplace shuts off in use TROUbLEShOOTING Continued POSSIBLE CAUSE 1.
- Page 35 WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Fol- low the gas supplier’s instructions.
-
Page 36: Replacement Parts
If so, contact DESA’s Customer Service Department at 1-866-672-6040. When calling please have your model and serial numbers of your heater ready. You can also visit DESA’s technical service web site at www.desatech.com SPECIFICATIONS (V)T36NA Series and CTDV36NRA •... - Page 37 ACCESSORIES Continued FACE/LOUVER PANEL KIT (Not Shown) RLD36 - Rolled Louver, Black FPD36 - Filligree, Black FPD36B - Filligree, Brushed Brass FPD36P - Filligree, Platinum FPD36PB - Filligree, Polished Brass ROLLED LOUVER TRIM KIT (Not Shown) LT36B - Brushed Brass LT36P - Platinum LT36PB - Polished Brass DEFLECTION HOOD...
-
Page 38: Illustrated Parts Breakdown And Parts List
ILLUSTRATED PARTS bREAkDOWN MODELS (V)T36NA, (V)T36NBA, (V)T36NRA, (V)T36NRBA, (V)T36PA, (V)T36PBA, (V)T36PRA, (V)36PRBA AND CTDV36NRA 22-5 22-6 22-2 22-3 22-4 22-1 www.desatech.com 111250-01E... -
Page 39: Parts List
MODELS (V)T36NA, (V)T36NBA, (V)T36NRA, (V)T36NRBA, (V)T36PA, (V)T36PBA, (V)T36PRA, (V)36PRBA AND CTDV36NRA This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts on page 36 of this manual. PART NO. DESCRIpTION Firebox Assembly Face Weldment 108010-01 Door Assembly, T &... - Page 40 ILLUSTRATED PARTS bREAkDOWN BURNER FOR MODELS (V)T36NA, (V)T36NBA, (V)T36NRA, (V)T36NRBA, (V)T36PA, (V)T36PBA, (V)T36PRA, (V)36PRBA AND CTDV36NRA www.desatech.com 111250-01E...
- Page 41 BURNER FOR MODELS (V)T36NA, (V)T36NBA, (V)T36NRA, (V)T36NRBA, (V)T36PA, (V)T36PBA, (V)T36PRA, (V)36PRBA AND CTDV36NRA This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts on page 36 of this manual. NO. PART NO. 11102 11105 11179...
- Page 42 _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ NOTES www.desatech.com 111250-01E...
- Page 43 _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ 111250-01E NOTES www.desatech.com...
-
Page 44: Limited Warranty
We make no other warranty, expressed or implied. DESA warrants this product to be free from defects in materials and components for two (2) years from the date of first purchase, provided that the product has been properly installed, operated and maintained in accordance with all applicable instructions.
