- Page 1 64, 72, 76 Meter Irrigation Boom OPERATING AND PARTS MANUAL 2022 Edition CB-MAN-64...
-
Page 3: Table Of Contents
Parts Section ...................... 21 Required Maintenance ..................69 Irrigation Boom Dimensions and Weight ............. 72 Useful Information ....................74 Page 1 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 4 CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M Notes: Page 2 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 5: Cadman Irrigation Boom
REPORT ANY DAMAGE TO CADMAN POWER EQUIPMENT LIMITED OR YOUR LOCAL DEALER IMMEDIATELY. Page 3 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... -
Page 6: Warranty Policy
The warranties expressed herein are non-transferable and replace any other warranties, either written or verbal, which may have been given or implied. Page 4 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... -
Page 7: When Applying Liquid Manure
Please contact your local agricultural representative to obtain the latest information for legal handling and application of nutrient. Page 5 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... -
Page 8: Safety Precautions
Page 6 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... -
Page 9: Safety Decals
CAUTION - a potentially hazardous situation that if not avoided may result in minor or moderate injury. Page 7 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... -
Page 10: Safety Decals Continued
Figure 5 - Replace Decals img-00131-B Page 8 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... -
Page 11: Transport
Figure 7 - Boom towing orientation img-01459 Failing to follow these transport guidelines may result in equipment damage and/or personal injury. Page 9 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... -
Page 12: Lane Spacing
This will result in damage to your irrigation boom, and may cause serious injury and/or death. Page 10 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... -
Page 13: Wheel Alignment
Ensure the water feed and tow bar are parallel. Ensure that all fasteners are tightened. Alignment Detail img-01474 Page 11 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... -
Page 14: Connecting To Traveller
Replace the quick pin (3) to ensure the tube is secure. Figure 10 - Offset Connector Tube img-01462 Page 12 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... -
Page 15: Unfolding Boom
The center sprinklers must face away from the traveller so that the irrigation is behind the irrigation boom. Figure 12 - Locking Pin and Pivot Lock img-01464 Page 13 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 16 This will result in damage to your irrigation boom, and may cause serious injury and/or death. Page 14 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
- Page 17 This will result in damage to your irrigation boom, and may cause injury and/or death. Page 15 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
- Page 18 Once your irrigation boom is completely unfolded you may release the center pivot latch. Figure 16 - Release Pivot Latch img-01468 Page 16 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
- Page 19 You may now connect to your water supply line, and then raise the irrigation boom stabilizer legs. Page 17 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 20: Irrigation Pull
Exceeding the maximum pull out speed will result in damage to the irrigation boom and any attached equipment. Page 18 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... -
Page 21: Folding
This will result in damage to your irrigation boom, and may cause injury and/or death. Page 19 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 22 Figure 20 - Folded Irrigation Boom img-01471 Page 20 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 23: Parts Section
LEGEND Standard Equipment Model Variance Full Assembly As Required Optional Equipment Not Shown Page 21 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... -
Page 24: Cart Body Assembly
CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M Cart Body Assembly Page 22 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 25 CENTER STEERING LINK CB-665-157 TURN TABLE MACHINING CB-665-199-A LATCH HANDLE EXTENSION WELD CB-765-110-B MIDDLE PLUMBING MOUNT CB-960-011-A Page 23 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 26: Cart Wheel Assembly
CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M Cart Wheel Assembly Page 24 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 27 CB-665-040-B TIE ROD ADJUSTABLE TIP CB-665-043-B WHEEL WELDMENT CB-665-100-C WELDED EYELET CB-665-123 STEER OUTSIDE LINK 55DEG CB-665-158 Page 25 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 28: Cart Wheel Assembly - 96 Inch
Operator's Manual - Boom 64M, 72M, 76M Cart Wheel Assembly - 96 inch Cart Wheel Assembly - 120 inch Page 26 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 29 WELD TIE ROD 120IN WIDE SPACING CB-665-167-B WELD TIE ROD ADJUSTABLE TIP CB-665-174-A STEER OUTSIDE LINK 55DEG WS120 CB-665-178 Page 27 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 30: Center Feed Tongue Assembly
CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M Center Feed Tongue Assembly Page 28 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 31 CB-665-138-A LARGE WASHER CB-665-151 LATCH CB-665-153 LOWER CENTER PLUMBING CWF CB-960-121 HOSE - 3.00 CADMAN SUPPLY IR-HOZ-300CSSL.FT Page 29 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 32: Offset Feed Tongue Assembly
CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M Offset Feed Tongue Assembly Page 30 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 33 PLUMBING WELD OWF Y PIPE CB-960-013 GASKET - 3.00 WIL-LOC IR-GKT-WL3 HOSE - 3.00 CADMAN SUPPLY IR-HOZ-300CSSL.FT Page 31 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 34: Center Boom Section - Inner
CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M Center Boom Section - Inner Page 32 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 35 JACK LEG WELDMENT CB-765-051 JACK LEG PIN WELDMENT CB-765-057-A ALUPANEL LOGO PLATE CB-765-101 GASKET - 3" (WIL-LOC) IR-GKT-BAUER076 Page 33 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 36: Center Boom Section - Outer
CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M Center Boom Section - Outer Page 34 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 37 BEARING SHAFT WELD’T - FLANGE CB-765-026 WASHER UPPER PIVOT BEARING CB-765-029 HOSE - 3.00 CADMAN SUPPLY IR-HOZ-300CSSL.FT Page 35 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 38: Boom Section 2 Assembly
CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M Boom Section 2 Assembly Page 36 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 39 LATCH LINK - SECTION 2-3 CB-765-069-A LOWER HOOK WELD - SECTION 2-3 CB-765-070-A 50MM BAUER GASKET IR-GKT-BAUER050 Page 37 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 40: Boom Section 3 Assembly
CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M Boom Section 3 Assembly Page 38 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 41 UPPER HOOK - SECTION 3-4 CB-765-080-A SECTION HANGER WELDMENT CB-765-098 TRANSPORT LATCH WELD’T - 3 CB-765-119 50MM BAUER GASKET IR-GKT-BAUER050 Page 39 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 42: Boom Section 4 Assembly
CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M Boom Section 4 Assembly Page 40 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 43 UPPER HOOK - SECTION 4-5 CB-765-093-C LATCH LINK - SECTION 4-5 CB-765-094-A HANGER LASER CUT CB-765-099 50MM BAUER GASKET IR-GKT-BAUER050 Page 41 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
- Page 44 CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M Boom Section 5 Assembly Page 42 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
- Page 45 90-WSR-LOC038 MACH- OFFSET PIN OD0.75 H038 CB-005 END SECTION WELDMENT CB-565-001-A CENTER CABLE BRACKET - GALV CB-565-015 Page 43 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 46: Boom Section 6 Assembly
CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M Boom Section 6 Assembly Page 44 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 47 UPPER HOOK - SECTION 4-5 CB-765-093-C TRANSPORT LATCH WELDMENT 76M CB-765-134 PLATE CURVE CATCH LINK 5-6 CB-765-135-A 50MM BAUER GASKET IR-GKT-BAUER050 Page 45 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 48: Boom Section 7 Assembly
CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M Boom Section 7 Assembly Page 46 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 49 MACH- OFFSET PIN OD0.75 H038 CB-005 PLATE CABLE BRACKET 76M CB-676-008 END 7TH SECTION WELDMENT 76M CB-776-000 Page 47 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 50: Boom Section 8 Assembly
CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M Boom Section 8 Assembly Page 48 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 51 WASHER LOCK - 3/8 90-WSR-LOC038 MACH- OFFSET PIN OD0.75 H038 CB-005 END 8TH SECTION WELDMENT 72M CB-872-000 Page 49 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 52: Sprinkler Kit Assembly - Komet
CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M Sprinkler Kit Assembly - Komet Page 50 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 53 KOMET 20 PSI PRECISION REGULATOR SP-KOM-05010309 KOMET KPT LINK SP-KOM-05010333 KOMET KPT LINK SP-KOM-05010333 KOMET KPT LINK SP-KOM-05010333 Page 51 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 54: End Sprinkler Kit - R55
CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M End Sprinkler Kit - R55 Page 52 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 55 NOZZLE ASSY - SNAP FIT NPT - 52 SP-NEL-12679-052 BODY ASSY - BLUE PLATE - R55 VT SP-NEL-12885 Page 53 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 56: Blanking Plate Assembly
CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M Blanking Plate Assembly Page 54 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 57 MACH- OFFSET PIN OD0.75 H038 CB-005 BLANKING PLATE BRACKET CB-023-A BLANKING PLATE BRACKET CB-043 72M, 76M Page 55 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 58: Center Sprinkler Assembly
CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M Center Sprinkler Assembly Page 56 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 59 LOWER PIPE WELDMENT CS OPT 64 CB-165-054 UPPER PIPE WELDMENT CS OPT CB-165-074 HOSE - 3.00 CADMAN SUPPLY IR-HOZ-300CSSL.FT Page 57 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 60: Inlet Accessories
CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M Inlet Accessories Page 58 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 61 CART SLOTTED LINK WELDMENT CB-665-126 PREMIUM SUPPLY HOSE - 4 IN IR-HOZ-400CPSL/FT HOSE CLAMP - 4.00 SINGLE BARB IR-MIS-20063 Page 59 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 62: Boom Hitch Kit
CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M Boom Hitch Kit Page 60 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 63 NUT LOCK GR.8 - 1/2-13 89-NUT-LOC050-13 NUT LOCK GR.8 - 5/8-11 89-NUT-LOC063-11 WASHER SAE GR.8 - 1/2 89-WSR-SAE050 Page 61 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 64: High Crop Assembly - 1 Of 3
CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M High Crop Assembly - 1 of 3 Page 62 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 65 PLATE HIGH CROP SWAY BAR LOCK CB-960-120 HC64 BOOM - SECTION 1 ASY CB-965-000 HOSE - 3.00 CADMAN SUPPLY IR-HOZ-300CSSL.FT Page 63 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 66: High Crop Assembly - 2 Of 3
CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M High Crop Assembly - 2 of 3 Page 64 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 67 PLATE SWING ARM HOLDER CB-960-081 WELDMENT TUBE SWING ARM CB-960-084-B SWING ARM HOLDER LARGE TOP CB-960-086-C PLATE SWING BALANCE CB-960-087 Page 65 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 68: High Crop Assembly - 3 Of 3
CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M High Crop Assembly - 3 of 3 Page 66 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 69 WELD SLIDE HC TUBE FLANGE CB-960-907 WELDMENT INTAKE PLUMBING TUBE CB-960-908 GASKET - 2" X 4 BOLT URETHANE IR-GKT-FL21 Page 67 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
- Page 70 CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M Notes: Page 68 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 71: Required Maintenance
This may result in serious injury and/or death, and will damage the boom. Table 1 - Each Use Page 69 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 72 This may result in serious injury and/or death to operators and/or spectators. This may also damage the irrigation boom. Page 70 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
- Page 73 70 hours or one week (whichever comes first) Table 3 - Grease Point Figure 21 - Grease Point img-01472 Page 71 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 74: Irrigation Boom Dimensions And Weight
The weight for an empty Cadman 72m Irrigation Boom is 4,915 lbs (2230 kg) The weight for an empty Cadman 76m Irrigation Boom is 4,990 lbs (2265 kg) Page 72 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com... - Page 75 CB-MAN-64 Operator's Manual - Boom 64M, 72M, 76M Notes: Page 73 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
-
Page 76: Useful Information
CYLINDER VOLUME ( US GAL. ) = Diameter (ft) x Diameter (ft) x Length (ft) x 5.8752 Page 74 of 74 Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: 519-688-2222 ▪ Fax: 519-688-2100 ▪ www.cadmanpower.com...
