- Page 1 Part No. 69016 X-15 Floss Machine Instruction Manual 3015A Cincinnati, OH 45241-4807 USA...
- Page 3 Model 3015A Installation Instructions Inspection of Shipment: Unpack all cartons and check thoroughly for any damage that may have occurred during transit. Damage claims should be filed immediately with the transportation company. Gold Medal Products is not responsible for damage that occurs in transit. Setup: Your new Warmer is completely assembled and tested at the factory.
- Page 4 Model 3015A 4. Remove all padding and restraints. 5. Remove the four shipping brackets located around the motor mount casting. This will allow the motor mount casting to “float” freely on the springs. 6. Make sure the floss ribbon (heating element) located inside the head assembly has not shaken out of the band during transportation.
- Page 5 Model 3015A INSTALLATION OF FLOSS STABLIZER...
- Page 6 Model 3015A Making Cotton Candy 1. Follow the guidelines described on page 3 for supplying power to machine. 2. With main switch still OFF, fill floss head. Always fill it 90% full with sugar. This 90% level is necessary to obtain a balanced condition in the floss head. DO NOT OVERFILL! Excessive vibration will occur if overfilled.
- Page 7 Model 3015A Making Cotton Candy (con’t) Grip cone as shown. Break into web of Wind the sugar Lift web of floss from the floss with the cone. onto the cone. pan and roll onto the cone. DO NOT PUT HANDS OR OBJECTS IN ROTATING SPINNER HEAD. ...
- Page 8 Model 3015A FLOATER ADJUSTMENT In operation, the floss will collect on the FLOSS STABILIZER. If the floss collects “low” on the stabilizer, twist the front (leading) edge of the leather floaters down. You get more lift and the floss will collect higher. Form leather floaters as shown.
-
Page 9: Shutdown Procedure
Model 3015A SHUT DOWN PROCEDURE When completing operation for the day (or any prolonged period), run all the sugar out of the floss head. Turn the Heat Switch off and continue to run the machine for 1 minute to cool the floss head. Then turn off the main Switch. -
Page 10: Troubleshooting
Model 3015A TROUBLESHOOTING LOW PRODUCTION 1. Check for excessive carbon on the ribbons. Follow the instructions for removing and cleaning band and ribbon if needed. 2. Check the line voltage. A primary reason for low production and poor equipment performance is low line voltage. -
Page 11: Maintenance Instructions
MAINTENANCE INSTRUCTIONS... -
Page 12: Ordering Spare Parts
ORDERING SPARE PARTS Always speak to a Gold Medal Products Technical Service Advisor before ordering any parts to help ensure accuracy for your product. Included diagrams may not be the latest information. 1. Identify the needed part by checking it against the photos, illustrations, and/or parts list. 2. -
Page 13: Parts List Cabinet Assembly
Model 3015A PARTS LIST CABINET ASSEMBLY 47155 Rubber Feet 3/4" High Feet and Bowl Support 87085 Power Supply Cord 67069 Handle 20006 Suspension Spring Not Shown 55219 Relay 48018 Cooling Fan Shipping Brackets * 48019 Install when transporting 42798 Switch, On/Off 48786 Switch Cover 48675... - Page 14 Model 3015A FLOSS MACHINE ASSEMBLY...
- Page 15 Model 3015A...
-
Page 16: Head Assembly
Model 3015A HEAD ASSEMBLY Item No. Part No. Quantity Description 43166 Spinner Cap, High Capacity 42438 Lower Spinner Head 48671 Upper Spinner Head 42517 Floss Band, 5" Double (1) 48755 5" Ribbon Assembly (2) 42032 3 1/2" Head Stud 20020 Slip Ring 42025 Top Washer, Phenolic... - Page 17 Model 3015A 3015A FLOSS HEAD ASSEMBLY...
-
Page 18: Electrical Schematic
Model 3015A ELECTRICAL SCHEMATIC... -
Page 19: Warranty
WARRANTY WE WARRANT to the original purchaser the Gold Medal equipment sold by us to be free from defects in material or workmanship under normal use and service. Our obligation under this warranty shall be limited to the repair or replacement of any defective part for a period of six (6) months from the date of sale to the Original Purchaser with regard to labor and two (2) years with regard to parts and does not cover damage to the equipment caused by accident, alteration, improper use, voltage,...
