Summarization of Contents
Product Information
Unpacking and storage
Instructions for verifying product receipt, unpacking, and storing modules to maintain quality.
Module tag information
Describes the two types of labels affixed to each PV module and the information they provide.
Module electrical performance parameters
Details electrical performance parameters measured under standard test conditions.
Environmental Considerations
Climate conditions
Specifies conditions under which Maysun Solar Crystalline series modules can be installed for over 20 years.
Working environment
Outlines the environmental conditions, including temperature and humidity, for PV module operation.
Mounting Instructions
Mounting methods
Describes methods for mounting PV modules to substructures using bolts or clamps.
Mounting with Bolts
Details securing modules using M8 bolts, washers, and nuts, including torque specifications.
Mounting with Clamps
Provides instructions for using clamps to fix modules on mounting rails, specifying clamp overlap and quantity.
Mounting with Single-axis Tracking System
Details the mounting process for 72 cells polycrystalline modules on a single-axis tracking system.
Grounding
Explains the necessity of grounding module frames and mounting racks according to National Electrical Code.
Module wiring
Covers wiring procedures, series connections, polarity verification, and cable specifications for PV modules.
Electrical Configuration
Fusing
Explains fuse rating requirements for DC voltage and connection in array strings.
Inverter seletion and compatibility
Discusses inverter selection, compatibility with Maysun modules, and potential issues like PID.
