Summarization of Contents
1. Scope
Scope of Manual
Specifies installation and maintenance requirements for Maysun Solar monofacial PV modules.
2. Introduction to Installation Manual
Manual Purpose and Content
Provides electrical and mechanical installation information for stable power output.
3. Safety Precautions
General Safety Precautions
Essential safety measures including electrical shock prevention, handling, and module integrity.
4. Product Information
4.1 Unpacking and Storage
Procedures for receiving, unpacking, and storing PV modules safely.
4.2 Module Tag Information
Details on labels affixed to PV modules and their information content.
4.3 Module Electrical Performance Parameters
Module electrical specifications measured under standard test conditions.
5. Environmental Considerations
5.1 Climate Conditions
Suitable climate conditions and resistance to environmental factors.
5.2 Working Environment
Operating temperature, humidity, and mechanical load capacity requirements.
6. Site Selection
Site Selection Guidelines
Recommendations for module orientation, tilt angle, and placement to maximize energy output.
7. Mounting Instructions
7.1 Mounting Methods
Overview of methods for mounting PV modules using bolts or clamps.
A. Mounting with Bolts
Detailed instructions for securing modules using M8 bolts and washers.
B. Mounting with Clamps
Guidelines for using clamps, including overlap, number, and placement.
C. Mounting with Single-axis Tracking System
Specific mounting instructions for 72-cell modules on a single-axis tracking system.
7.2 Grounding
Requirements for grounding module frames and mounting racks according to electrical codes.
7.3 Module Wiring
Guidelines for connecting modules in series or parallel, including cable specifications.
8. Electrical Configuration
8.1 Fusing
Recommendations for fuse rating and placement in series with array strings.
8.2 Inverter Selection and Compatibility
Guidance on selecting inverters and addressing Potential Induced Degradation (PID).
9. Maintenance And Care
Maintenance and Cleaning Procedures
Recommended annual maintenance tasks and module cleaning methods.
10. Disclaimer Of Liability
Disclaimer of Liability
Statement on Maysun Solar's responsibility regarding installation, handling, and use.
