Organizational Unit Criterion - ACRONIS Backup & Recovery 10 Advanced Server SBS Edition User Manual

All the machines whose IP addresses are within the specified IP range will be members of
the dynamic group.

Listed in txt/csv file (p. 290)
All the machines that are listed in the specified .txt or .csv file will be members of the
dynamic group.
3. In the Comments field, enter a description of the created group.
4. Click OK.
Adding multiple criteria
Adding multiple criteria forms a condition according to the following rules:
a) All the entries of the same criteria are combined by logical addition (OR).
For example, the following set of criteria
Operating system: Windows Server 2008
Operating system: Windows Server 2003
will add to the same group all the machines whose operating system is Windows 2000 OR
Windows 2003.
b) Entries of different criteria are combined by logical multiplication (AND)
For example, the following set of criteria
Operating system: Windows Server 2008
Operating system: Windows Server 2003
Organizational unit: SERVERS
IP range:
will add to the same group all the machines whose operating system is Windows 2000 or
Windows 2003 and belong to the SERVERS organizational unit and whose IP addresses are
within the range 192.168.17.0 - 192.168.17.55.
How long does a dynamic group member remain in the group?
A dynamic group member remains in the group as long as the member meets the criteria. The
member is removed from the group automatically as soon as
 the member changes so that it no longer meets the criteria
 the administrator changes the criteria so that the member no longer meets the criteria
There is no way to remove a machine from a dynamic group manually except for deleting the
machine from the management server.

Organizational unit criterion

Organizational unit criterion is specified for the domain the management server is currently in, as
follows: OU=OU1
Select an organizational unit from the Active Directory tree by clicking Browse, or typing it manually.
If the domain access credentials were not specified in the management server options, the program
will ask you to provide them. The credentials will be saved in the Domain access credentials (p. 80)
option.
For example, suppose that the domain us.corp.example.com has OU1 (which is in the root), OU1 has
OU2, and OU2 has OU3. And you need to add the machines of OU3. So, the criterion will be:
OU=OU3, OU=OU2, OU=OU1
Copyright © Acronis, Inc., 2000-2010
192.168.17.0 - 192.168.17.55
289
