Filtering And Sorting Machines; Actions On Groups - ACRONIS Backup & Recovery 10 Advanced Server SBS Edition User Manual

The policy that is applied on the machine through inheritance is displayed as in the following
example:
Group1 > Group2 > Group3 > Machine1
Group1 in the root contains Group2 to which the policy is applied directly. Group2, in turn, contains
child Group3 that inherits the policy from the parent and applies the policy to Machine1 respectively.
The machine (or group) to which the policy was applied directly is boldfaced and marked with an
icon.
All items are interactive, i.e. when you click on a machine or a group, its parent group view will be
opened.

Filtering and sorting machines

To
Sort machines by any column
Filter machines by name.
Filter machines by status, last
connect, last backup,
availability.
Configuring the machines table
By default, the table has five columns that are displayed, others are hidden. If required, you can hide
the shown columns and show the hidden ones.
To show or hide columns
1. Right-click any column header to open the context menu. The menu items that are ticked off
correspond to the column headers presented in the table.
2. Click the items you want to be displayed/hidden.
7.1.3.2

Actions on groups

Actions are available when you select the
then click on a group.
The following is a guideline for you to perform actions on selected groups.
To
Create a custom static or a
dynamic group
Copyright © Acronis, Inc., 2000-2010
Do
Click the column's header to sort the machines in ascending order.
Click it once again to sort the machines in descending order.
Type a machine's name in the field below the corresponding column's header.
As a result you will see the list of machines, whose names fully or just partly
coincide with the entered value.
In a field below the corresponding column's header, select the required value
from the list.
Physical machines view in the Navigation tree, and
Do
Click Create group.
In the Create group (p. 288) window, specify the required parameters of the
group.
Custom groups can be created in the root folder (
other custom groups.
Physical machines), or in
287
