Front Panel Controls and Indicators
Power Control and Status LEDs
Details on the power switch, power, signal, limit, and protect LED indicators for amplifier status.
Volume Controls and LCD Display
Explanation of channel volume controls and the LCD screen for monitoring settings and temperature.
Physical Design: Airflow and Mounting
Information on the airflow vents for cooling and rack mount holes for installation.
Back Panel Connectivity and Features
Airflow Vent and Cooling System
Description of the dual variable speed fans and front-to-back forced air cooling.
Input and Link Connectors
Details on XLR input connectors for channels A and B, and link connectors for daisy-chaining.
Output Mode and Speaker Connectors
Explanation of the output mode switch and Speakon connectors for amplifier outputs.
Ground Mode Switch
Function of the Ground Mode switch for managing earth connection and noise reduction.
Connecting Inputs and Outputs
Audio Signal Connection
Guide on using XLR connectors for audio signals and link connectors for daisy-chaining.
Speaker Output Wiring
Instructions for connecting speakers using Speakon connectors in Stereo, Parallel, and Bridge modes.
Output Mode Selection Guide
Stereo Mode Operation
Configuration for independent Channel A and B operation with recommended load impedance.
Parallel Mode Operation
Setup for amplifying input to both channels with recommended load impedance.
Bridged Mono Mode Operation
Instructions for converting to a single mono output amplifier with recommended load impedance.
Protection Features Explained
Active Clip Limiting
Automatic gain reduction to protect loudspeakers from clipping waveforms.
Impedance Sensing Protection
Circuit protection against over-stressed loads or short circuits.
Thermal Protection
Automatic shutdown due to overheating, with details on fan operation.
DC Voltage and Subsonic Protection
Protection against DC voltage on outputs and subsonic frequencies for speaker safety.
User Precautions and Speaker Protection
General Speaker Protection
Guidelines to prevent damage to loudspeakers from power, clipping, or incorrect frequencies.
Frequency and Clipping Limits
Advice on avoiding clipping and using correct frequencies for speaker drivers.
Maintenance and Service Information
Routine Amplifier Maintenance
Instructions for cleaning airflow vents and heat sinks; no user-serviceable parts inside.
Service and Repair Procedures
Guidance on returning the amplifier for repair and details of the warranty.
