- Page 1 NEUTRON & PROTON Electric Scooter User Manual SHOKSCOOTERS.COM...
- Page 2 SHOKSCOOTERS.COM...
- Page 3 THANK YOU FOR YOUR PURCHASE! This user manual will help you assemble and operate your SHOK Neutron and Proton Electric Scooter. Be sure to read all of the information in this manual before riding.
-
Page 4: Table Of Contents
CONTENTS 1. Package Contents 2. Scooter Overview 3. Control Panel 4. Assembly & Setup 5. Charging the Scooter 6. Connect with the App 7. How to Ride 8. Safety Instructions 9. Folding & Carrying 10. Daily Care & Maintenance 1 1. Specifications 12. -
Page 5: Package Contents
PACKAGE CONTENTS Assembled Electric Scooter Neutron Proton... -
Page 6: Scooter Overview
SCOOTER OVERVIEW Accelerator Control Panel Headlight Brake Lever Scooter Bell Buckle Folding Mechanism Brake Light Disc Brake Kickstand Wheel Motor Battery Compartment Charging Port... -
Page 7: Control Panel
CONTROL PANEL Speedometer Displays the current speed of the scooter, and displays error codes. Modes The 3 modes available: “ECO” for Energy saving (smooth acceleration, suitable for beginners), “D” for Standard mode, and “S” for Sport mode km/h ECO D S (powerful, only recommended for skilled riders). -
Page 8: Assembly & Setup
ASSEMBLY & SETUP Put the kickstand down, and fasten the handlebar Attach the handlebar to the stem. stem on the headset. Tighten the screws onto both sides of the stem with the After assembly, press the power button to check that hexagon wrench. -
Page 9: Charging The Scooter
CHARGING THE SCOOTER Lift up the charging Plug the power When charging is port cover. adapter into the completed, cover charging port. the charging port. The scooter is fully charged when the LED on the charger changes from red (charging) to green. Safety Warnings •... -
Page 10: Connect With The App
The scooter will beep when the indicates the scooter is waiting for a connection. connection is successful and the Bluetooth icon will stop blinking and remain illuminated. Follow the app instructions to activate the scooter. You can now use your SHOK electric scooter. -
Page 11: How To Ride 1
HOW TO RIDE Always wear an approved safety helmet, elbow Turn on the scooter, and check the power indicator. pads and knee pads. A long-sleeve shirt and pants are recommended. Step on the deck with one foot, and slowly kick off When the scooter starts to coast, put both feet the other on the ground. - Page 12 This saves wear and tear on the brake assemblies, and prolongs the life of the battery and the scooter. At the heart of the SHOK EcoTrek Platform is a high purity copper motor with built-in cruise control, which reduces motor weight and increases motor efficiencies during operation.
-
Page 13: Safety Instructions
SAFETY INSTRUCTIONS Watch out for the following safety risks DO NOT ride the scooter in wet weather. It is NEVER ride the scooter indoors. You may risk injury dangerous and may result in injury. Wet conditions or cause damage to personal and private property. can damage the electronics and void the warranty. - Page 14 SAFETY INSTRUCTIONS Keep your speed between 5-10kph (3.1-6.2mph) DO NOT accelerate when going downhill, and when riding over speed bumps, or bumpy roads. brake in time to slow down. When encountering a Slightly bend your knees to adapt to uneven surfaces. steep incline, step off the scooter and push.
- Page 15 SAFETY INSTRUCTIONS DO NOT ride in traffic lanes or residential areas DO NOT abruptly change the steering direction. where vehicles and pedestrians are both allowed. DO NOT ride through puddles or any other (water) NEVER allow more than one person at a time to ride obstacles.
- Page 16 SAFETY INSTRUCTIONS DO NOT touch the disc brakes or motor on the DO NOT keep your feet on the rear mudguard. scooter when in use, or immediately after riding, as these parts can become very hot. DO NOT remove your hands from the handlebars DO NOT attempt to jump over obstacles, do stunts, while riding.
- Page 17 SAFETY REMINDER WARNING: Riding the electric scooter can be a hazardous activity. Whenever you ride the electric scooter, you risk severe injury or even death from loss of control, collisions, and falls. USE CAUTION AND RIDE AT YOUR OWN RISK. •...
-
Page 18: Folding & Carrying
FOLDING & CARRYING Folding & Opening Make sure that the scooter is turned off before folding. To fold, turn the handlebar stem counterclockwise to open the safety hook, and unlock the quick release lever. Bend the handlebar stem, aligning the bell to the buckle on the rear mudguard, and hook them together. -
Page 19: Daily Care & Maintenance
DAILY CARE & MAINTENANCE Adjusting the Disc Brake Brake Cable If the brake is too tight, use the 4mm Allen key to loosen If the brake is too loose, loosen the screw on the caliper. the screw on the caliper. Then slightly adjust the brake line Then slightly adjust the brake line (increase the exposed (decrease the exposed length), and tighten the screw again. - Page 20 DAILY CARE & MAINTENANCE Cleaning To clean the scooter, wipe it with a damp cloth. DO NOT use alcohol, gasoline, kerosene, or other corrosive chemical solvents to clean the scooter. It can severely damage the appearance and structure of the scooter. DO NOT use a pressure washer as it may cause damage to the electronics.
-
Page 21: 1. Specifications
SPECIFICATIONS Neutron Proton Performance Index Items 7.5Ah 15Ah Before Folding 1080mm X 430mm X 1090mm 1 180mm X 490mm X 1 180mm Dimensions After Folding 1080mm X 430mm X 490mm 1 180mm X 490mm X 530mm Weight Item weight Approx. 12kg... -
Page 22: Warranty
WARRANTY 90 Day Limited Warranty The manufacturer warranties this product to be free of manufacturing defects for a period of 90 days from date of purchase. This 90 Day Limited Warranty covers the battery, electric motor, and controller. This 90 Day Limited Warranty does not cover normal wear and tear, tires, tubes or cables, or any damage, failure or loss caused by improper assembly, maintenance, storage or use of the scooter.
