- Page 1 ELECTRON Electric Scooter User Manual SHOKSCOOTERS.COM...
- Page 2 SHOKSCOOTERS.COM...
- Page 3 THANK YOU FOR YOUR PURCHASE! This user manual will help you assemble and operate your SHOK Electron Electric Scooter. Be sure to read all of the information in this manual before riding.
-
Page 4: Table Of Contents
CONTENTS 1. Package Contents 2. Scooter Overview 3. Assembly & Setup 4. Charging the Scooter 5. How to Ride 6. Safety Instructions 7. Folding & Carrying 8. Daily Care & Maintenance 9. Specifications 10. Warranty For a digital copy of this manual visit our website at WWW.SHOKSCOOTERS.COM/MANUALS... -
Page 5: Package Contents
PACKAGE CONTENTS Assembled Electric Scooter Electron... -
Page 6: Scooter Overview
SCOOTER OVERVIEW Accelerator Brake Lever Power Button Charging Port Folding Mechanism Wheel Motor Front Wheel LED Light Strip Kickstand... -
Page 7: Assembly & Setup
ASSEMBLY & SETUP Place the handlebar on the attachment bracket on the stem. Connect the plug on the handlebar to the plug on the stem. Tighten the screw with a hex key Connect the plugs or wrench. Press the power button to turn the scooter on. -
Page 8: Charging The Scooter
CHARGING THE SCOOTER Open the charging port cover. Plug the power adapter into the charging port. When charging is completed, unplug the charger and close the charging port cover. Charging Port The scooter is fully charged when the LED on the charger changes from red (charging) to green. -
Page 9: How To Ride
HOW TO RIDE Always wear an approved safety helmet, elbow Turn on the scooter, and check the power indicator. pads and knee pads. A long-sleeve shirt and pants are recommended. Step on the deck with one foot, and slowly kick off When the scooter starts to coast, put both feet the other on the ground. - Page 10 This saves wear and tear on the brake assemblies, and prolongs the life of the battery and the scooter. At the heart of the SHOK EcoTrek Platform is a high purity copper motor with built-in cruise control, which reduces motor weight and increases motor efficiencies during operation.
-
Page 11: Safety Instructions
SAFETY INSTRUCTIONS Watch out for the following safety risks DO NOT ride the scooter in wet weather. It is NEVER ride the scooter indoors. You may risk injury dangerous and may result in injury. Wet conditions or cause damage to personal and private property. can damage the electronics and void the warranty. - Page 12 SAFETY INSTRUCTIONS Keep your speed between 5-10kph (3.1-6.2mph) DO NOT accelerate when going downhill, and when riding over speed bumps, or bumpy roads. brake in time to slow down. When encountering a Slightly bend your knees to adapt to uneven surfaces. steep incline, step off the scooter and push.
- Page 13 SAFETY INSTRUCTIONS DO NOT ride in traffic lanes or residential areas DO NOT abruptly change the steering direction. where vehicles and pedestrians are both allowed. DO NOT ride through puddles or any other (water) NEVER allow more than one person at a time to ride obstacles.
- Page 14 SAFETY INSTRUCTIONS DO NOT touch the disc brakes or motor on the DO NOT keep your feet on the rear mudguard. scooter when in use, or immediately after riding, as these parts can become very hot. DO NOT remove your hands from the handlebars DO NOT attempt to jump over obstacles, do stunts, while riding.
- Page 15 SAFETY REMINDER WARNING: Riding the electric scooter can be a hazardous activity. Whenever you ride the electric scooter, you risk severe injury or even death from loss of control, collisions, and falls. USE CAUTION AND RIDE AT YOUR OWN RISK. •...
-
Page 16: Folding & Carrying
FOLDING & CARRYING Folding the Scooter Quick Release Lever Make sure that the scooter is turned off before folding. To fold, pull the quick release lever on the folding mechanism to unlock. Then bend the handlebar stem, pulling it down towards the rear wheel. To open, pull the handlebar stem up, and close the quick release lever on the folding mechanism. -
Page 17: Daily Care & Maintenance
FOLDING & CARRYING Carrying the Scooter To carry the scooter, hold the handlebar stem with either one hand or both hands. DAILY CARE & MAINTENANCE Adjusting the Handlebar Long-term use of the scooter may result in loose screws, causing the handlebar stem to become unstable. If you notice the handlebar stem is shaky or loose when riding, use the 4mm Allen key to tighten the screws on the holding mechanism. - Page 18 DAILY CARE & MAINTENANCE Cleaning To clean the scooter, wipe it with a damp cloth. DO NOT use alcohol, gasoline, kerosene, or other corrosive chemical solvents to clean the scooter. It can severely damage the appearance and structure of the scooter. DO NOT use a pressure washer as it may cause damage to the electronics.
-
Page 19: Specifications
SPECIFICATIONS Electron Performance Index Items 2.0Ah Before Folding 85x40x85cm Dimensions After Folding 85x40x28cm Weight Item weight NW 5.7KG, GW 6.8KG Max load 60kg Riding 6-12 Requirements Body Length 1.4M Max. speed 16kph (10mph) Max. climbing angle Approx. 7° General range Approx. -
Page 20: Warranty
WARRANTY 90 Day Limited Warranty The manufacturer warranties this product to be free of manufacturing defects for a period of 90 days from date of purchase. This 90 Day Limited Warranty covers the battery, electric motor, and controller. This 90 Day Limited Warranty does not cover normal wear and tear, tires, tubes or cables, or any damage, failure or loss caused by improper assembly, maintenance, storage or use of the scooter.
