vaetrix Hydro Test Gauge User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Vaetrix HTG Series User Manual

• Table of Contents

Damping and Datalogging
Leak Test and Min/Max
Units and Temperature
Data Management Application
• Introduction
Thank you for choosing the Vaetrix Test Gauge. Vaetrix is
2-3
engineered by individuals that have been in the process
4
control industry for well over twenty years. We take pride in
the fact that our products are designed and manufactured in
5-8
the USA. The gauge itself is backed by an industry leading
9
four-year warranty. Our products are designed and built to
take abuse. We would have it no other way.
11
The only way we can get better is by listening to you, the
12
customer. If you have any comments or suggestions feel free
to send us an email at
13
3740.
14-15
16
• Brief Overview
17
18
The gauge is powered by 3 AA alkaline batteries that provide
over 1000 hours of continuous use. To replace the batteries
19
just remove the screw located in the battery door or use a
coin for the HTGX Series. Communications for datalogging
20-21
and downloads is handed by USB. A standard USB to Micro B
22-27
cable will work for the HTG Series or A Standard USB to B for
the HTGX (printer-style cable). For further details on all
28-31
important measurement parameters consult the
32-33
specifications section in the manual.
33
35
36
sales@vaetrix.com
or call at 888-797-
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hydro Test Gauge and is the answer not in the manual?

Questions and answers

Related Manuals for vaetrix Hydro Test Gauge

Summary of Contents for vaetrix Hydro Test Gauge

  • Page 1: Table Of Contents

    USB. A standard USB to Micro B Data Management Application 22-27 cable will work for the HTG Series or A Standard USB to B for the HTGX (printer-style cable). For further details on all Specifications...

  • Page 2: Operation And Quick Start Guide

    Operation and Quick Start Guide When the power key is pressed down the gauge enters the boot-up sequence. Gauge firmware revision, range, serial number, and contact information will be displayed for two seconds. Once complete the gauge is actively reading pressure and temperature in Measure Mode.
  • Page 3 Operation and Quick Start Guide MAIN MENU OPTIONS ADMIN Control Features, Reduce Resolution, Adjust Calibration, Restore Factory Calibration ALARMS On/Off/Set High or Low CLOCK Set Date, Time, Time Zone, and Format DAMPING On/Off DATALOGGING Start, Configure DISPLAY Timeouts, Contrast, Refresh Interval, Color LEAKTEST Start, Stop MINMAX...

  • Page 4: Safety

    Vaetrix HTG Series User Manual • Safety We use the International Electrical Symbols on our products • Use a #2 phillips screwdriver when tightening the battery and in the manuals to alert users of key criteria that must be door screws to prevent stripping and provide adequate sealing.

  • Page 5: Admin

    Vaetrix HTG Series User Manual • Admin • Admin - Control Features In the Admin menu you have the ability to CONTROL The menu options in the gauge can locked out according to FEATURES, REDUCE RESOLUTION, ADJUST CALIBRATION, or your preferences.
  • Page 6 Vaetrix HTG Series User Manual • Admin – Reduce Resolution • Admin – Adjust Calibration The least significant digit will removed from the display We recommend calibration on an annual basis. Calibration when selecting REDUCE RESOLUTION. This feature can be...
  • Page 7 Vaetrix HTG Series User Manual • Admin – Adjust Calibration • Admin – Adjust Calibration The unit will prompt you to apply the high reference The unit will respond by with “Storing Calibration” and pressure. We recommend that you are within 10% of the return to Measure Mode.
  • Page 8 Vaetrix HTG Series User Manual • Admin – Restore Calibration If you make a mistake during the calibration process or the gauge is not within specification the factory defaults can be restored. Navigate to RESTORE FACTORY CAL and press the SELECT key.

  • Page 9: Alarms

    Vaetrix HTG Series User Manual • Alarms The HTG can be setup to indicate a Low and High Alarm. Once the alarm setpoint has been reached the high or low Once the low or high value is reached the display or value alarm icon will show on the display and background color will turn red until the pressure changes.
  • Page 10 Vaetrix HTG Series User Manual • (Intentionally Left Blank) 12/10/2020...

  • Page 11: Clock

    Vaetrix HG Series User Manual • Clock A unique feature of the HTG is a real time operating clock Make sure that gauge is set to match the PC to avoid any for data logging or recording events. The unit will keep time synching issues with time when uploading or downloading even when the standard AA batteries are replaced.

  • Page 12: Datalogging

    Vaetrix HTG Series User Manual • Damping • Datalogging Damping is designed to average out pulsating pressure and The test gauge has the capability to store up to 22000 smooth out the pressure signal so that it is readable on the pressure readings in up to 200 unique sessions in the display.
  • Page 13 Vaetrix HTG Series User Manual • Datalogging DELETE ALL DATA will erase all the logged data on the unit. Use the UP arrow key or HOME to escape. Datalogging can be setup to automatically start on an Alarm condition as well. Simply choose START ON ALARM and press SELECT.

  • Page 14: Display

    Vaetrix HTG Series User Manual • Display The HTG has an active graphics display that can be setup Just choose SET and press SELECT to define the interval. Use based on your preferences. the left or right arrow keys to move the cursor and up and down arrow keys to set the value.
  • Page 15 Vaetrix HTG Series User Manual • Display Certain lighting conditions may require an adjustment to the display contrast for optimum viewing. Use the Up and Down arrow keys and bargraph indicator to set the contrast. Press SELECT to confirm the setting.
  • Page 16 Vaetrix HTG Series User Manual • Leak Test • Min/Max Pressure leak testing is used in many applications to verify The HTG tracks the Maximum and Minimum pressure product or process integrity. Once Leak Test is selected from readings from the time the unit powers on or the data was the menu selection a test will start.

  • Page 17: Sensor

    Vaetrix HTG Series User Manual • Sensor A unique feature that sets the HTG series apart from the competition is the ability to display Absolute or Gauge pressure from single unit. Just make your choice and press the SELECT key. The engineering unit chosen will be followed with A (absolute) Absolute pressure is referenced to a perfect vacuum so it’s...

  • Page 18: Snapshot

    Vaetrix HTG Series User Manual • Snapshot If you look carefully at the keypad on the HTG you will notice a camera icon next to right arrow key. The snapshot feature is a quick way to capture and record pressure readings while in Measure Mode.

  • Page 19: Tare

    Vaetrix HTG Series User Manual • Tare The tare feature lets you deduct a pressure value from live Tare is indicated in Measure Mode when applied. pressure. Applications where existing pressure can’t be removed and must be accounted for are perfect for the tare feature.
  • Page 20 Vaetrix HTG Series User Manual • Units If you would like to focus on a couple different engineering There are twenty three selectable engineering unit available units or prevent certain users from using an unapproved to choose from. In Measure Mode, press the UNITS key and choice for calibration, units can be locked or unlocked under use the ARROW keys to scroll through the options.
  • Page 21 Vaetrix HTG Series User Manual • Ambient Temperature To access temperature units scroll down in the menu and HTG units equipped with the ambient temperature option select TEMP. Choose CEL (Celcius) or FAR (Farenheit) to will display the ambient temperature in Measure Mode. The change the engineering unit.
  • Page 22 Vaetrix HTG Series User Manual • RTD Temperature(s) To access temperature units scroll down in the menu and HTG units equipped with a single or dual RTD port will select TEMP. Choose CEL (Celcius) or FAR (Farenheit) to display the temperature in Measure Mode as RTD A and/or change the engineering unit.
  • Page 23 Vaetrix HTG Series User Manual • Hydrotest Software Application The software application can be downloaded free at www.vaetrix.com. Datalogging sessions can be started with just one click. Simply connect the gauge with the USB cable. The software will automatically recognize the gauge and appear at the top of the software with the Model and S/N.
  • Page 24 Vaetrix HTG Series User Manual • Hydrotest Software Application Sessions will be listed by time sequence and numerical The software will confirm the files are saved with a pop-up sequence. Check the sessions and name the sessions you box. If you would like to open and older report that was would like to save in the default directory or any location previously created, select Open File and find the .rpt file.
  • Page 25 Vaetrix HTG Series User Manual • Hydro Testing Application Job Info – Define the job title, customer name, project title, location, testing company, location, and technicians. Cover Sheet – Use a standard cover sheet, custom cover sheet, and preview the cover sheet.
  • Page 26 Vaetrix HTG Series User Manual Creating Cover Sheets based on Job Information 12/10/2020...
  • Page 27 Vaetrix HTG Series User Manual Adding Notes and Arranging Pages (Report Options) 12/10/2020...
  • Page 28 Vaetrix HTG Series User Manual Previewing Graph 12/10/2020...

  • Page 29: Specifications

    Specifications Power 3AA Alkaline Batteries (LR6) Dimensions 9.75” x 5” x 6” (Portable) or 14.6” x 10.2” x 6” (X Model - Length x Width x Depth) Weight 7.5 Pounds (Portable) or 4.5 Pounds (X Model) Case Corrosion Resistant Aluminum (Powder Coated) or Plastic Display Tri-Color Graphics Display, 240 x 120 –...
  • Page 30 Specifications Operating Temperature 14°F to 122°F (-10°C to 50°C) Compensated range Storage Temperature -10°F to 150°F (-23°C to 65°C) Remove batteries for storage over thirty days Humidity 0%-95% (Non-Condensing) IP Rating IP67 (X Model in Pelican 1450) or IP54 (Portable – Hammer Style) Low Battery Indication 3.7 Volts, 3.5 Volts –...
  • Page 31 Amphenol RTD Connector – 4 Wire with Protective Cap, ½” NPT Compression Fitting with RTD Connections Assemblies Units 23 Selectable, 1 Custom Bluetooth Optional BLE Low Energy, Registered Under FCC: WAP2001 Warranty 4 Years – Register product at www.vaetrix.com. 12/10/2020...

  • Page 32: Range Options

    Range Options (0.05% Full Scale) Range (PSI) Full Scale/Span Sensor Burst Media Type -12 to 15 L (Gas and Liquids compatible with 316SS) -12 to 30 L (Gas and Liquids compatible with 316SS) -12 to 100 L (Gas and Liquids compatible with 316SS) -12 to 300 L (Gas and Liquids compatible with 316SS) -12 to 500...

  • Page 33: Model Configurator

    Model Configurator Model Range (PSI) Sensor / Media Accuracy Options I = Isolated 05 = 0.05% Full Scale 1000 3000 5000 10000 14500 12/10/2020...

  • Page 34: Range And Resolution

    Range and Native Resolution Range MBAR KGCM2 INH2O CMH2O MMH2O FTH2O FTSW INHG MMHG TORR (PSI) 4, 20, 60 4, 20 4, 20 20, 60 5.0001 0.3441 344.01 0.0001 138.01 351.01 3515.1 3.0001 11.001 11.001 10.001 258.01 34.001 0.0001 258.01 15.001 1.0001 1034.1...

  • Page 35: Service And Warranty

    RMA form located on the website manufacturing defects and workmanship for a period of (www.vaetrix.com) or feel free to give us a call. Please have forty eight months from the date of shipment to the original the model number, serial number, and reason for return buyer.
