Vaetrix ETG Series User Manual

• Table of Contents

• Introduction
Thank you for choosing the Vaetrix Test Gauge. Vaetrix is
2-3
engineered by individuals that have been in the process
4
control industry for well over twenty years. We take pride in
the fact that our products are designed and manufactured in
5-8
the USA. The gauge itself is backed by an industry leading
9
four-year warranty. Our products are designed and built to
take abuse. We would have it no other way.
10
The only way we can get better is by listening to you, the
11
customer. If you have any comments or suggestions feel free
12
to send us an email at
3740.
13
14-15
• Brief Overview
16
17
The gauge is powered by 3 AA alkaline batteries that provide
over 1000 hours of continuous use. To replace the batteries
18
just remove the two screws located in the battery door. The
gauge is sealed to meet IP-65 so make sure the battery door
19
screws are tight. Communications for datalogging and
20
downloads is handed by USB. A standard USB to Micro B
cable will work. For further details on all important
21-23
measurement parameters consult the specifications section
24-27
in the manual.
28-29
30
31
32
sales@vaetrix.com
or call at 888-797-
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ETG Series and is the answer not in the manual?

Questions and answers

Related Manuals for vaetrix ETG Series

Summary of Contents for vaetrix ETG Series

  • Page 1: Table Of Contents

    Vaetrix ETG Series User Manual • Table of Contents • Introduction Thank you for choosing the Vaetrix Test Gauge. Vaetrix is Operation and Quick Start Guide engineered by individuals that have been in the process Safety control industry for well over twenty years. We take pride in...

  • Page 2: Operation And Quick Start Guide

    Operation and Quick Start Guide When the power key is pressed down the gauge enters the boot-up sequence. Gauge firmware revision, range, serial number, and contact information will be displayed for two seconds. Once complete the gauge is actively reading pressure in Measure Mode.
  • Page 3 Operation and Quick Start Guide MAIN MENU OPTIONS ADMIN Control Features, Reduce Resolution, Adjust Calibration, Restore Factory Calibration ALARMS On/Off/Set High or Low BARGRAPH On/Off CLOCK Set Date, Time, Time Zone, and Format DAMPING On/Off DATALOGGING Start, Configure DISPLAY Timeouts, Contrast, Refresh Interval, Color LEAKTEST Start, Stop MINMAX...

  • Page 4: Safety

    Vaetrix ETG Series User Manual • Safety We use the International Electrical Symbols on our products • Use a #2 phillips screwdriver when tightening the battery and in the manuals to alert users of key criteria that must be door screws to prevent stripping and provide adequate sealing.

  • Page 5: Admin

    Vaetrix ETG Series User Manual • Admin • Admin - Control Features In the Admin menu you have the ability to CONTROL The menu options in the gauge can locked out according to FEATURES, REDUCE RESOLUTION, ADJUST CALIBRATION, or your preferences.
  • Page 6 Vaetrix ETG Series User Manual • Admin – Reduce Resolution • Admin – Adjust Calibration The least significant digit will removed from the display We recommend calibration on an annual basis. Calibration when selecting REDUCE RESOLUTION. This feature can be...
  • Page 7 Vaetrix ETG Series User Manual • Admin – Adjust Calibration • Admin – Adjust Calibration The unit will prompt you to apply the high reference The unit will respond by with “Storing Calibration” and pressure. We recommend that you are within 10% of the return to Measure Mode.
  • Page 8 Vaetrix ETG Series User Manual • Admin – Restore Calibration If you make a mistake during the calibration process or the gauge is not within specification the factory defaults can be restored. Navigate to RESTORE FACTORY CAL and press the SELECT key.

  • Page 9: Alarms

    Vaetrix ETG Series User Manual • Alarms The ETG can be setup to indicate a Low and High Alarm. Once the alarm setpoint has been reached the high or low Once the low or high value is reached the display or value alarm icon will show on the display and background color will turn red until the pressure changes.

  • Page 10: Bargraph

    Vaetrix ETG Series User Manual • Bargraph The bargraph on the left-hand side of the display indicates If you prefer not to use the bar graph, it can be turned OFF the pressure value from 0% to 100% based on the pressure by using the RIGHT arrow key and pressing SELECT.

  • Page 11: Clock

    Vaetrix ETG Series User Manual • Clock A unique feature of the ETG is a real time operating clock for Make sure that gauge is set to match the PC to avoid any data logging or recording events. The unit will keep time synching issues with time when uploading or downloading even when the standard AA batteries are replaced.

  • Page 12: Damping And Datalogging

    Vaetrix ETG Series User Manual • Damping • Datalogging Damping is designed to average out pulsating pressure and The test gauge has the capability to store up to 64000 smooth out the pressure signal so that it is readable on the pressure readings in up to 200 unique sessions in the display.

  • Page 13: Datalogging

    Vaetrix ETG Series User Manual • Datalogging DELETE ALL DATA will erase all the logged data on the unit. Use the UP arrow key or HOME to escape. Datalogging can be setup to automatically start on an Alarm condition as well. Simply choose START ON ALARM and press SELECT.

  • Page 14: Display

    Vaetrix ETG Series User Manual • Display The ETG has an active graphics display that can be setup Just choose SET and press SELECT to define the interval. Use based on your preferences. the left or right arrow keys to move the cursor and up and down arrow keys to set the value.
  • Page 15 Vaetrix ETG Series User Manual • Display Certain lighting conditions may require an adjustment to the display contrast for optimum viewing. Use the Up and Down arrow keys and bargraph indicator to set the contrast. Press SELECT to confirm the setting.

  • Page 16: Leak Test And Min/Max

    Vaetrix ETG Series User Manual • Leak Test • Min/Max Pressure leak testing is used in many applications to verify The ETG tracks the Maximum and Minimum pressure product or process integrity. Once Leak Test is selected from readings from the time the unit powers on or the data was the menu selection a test will start.

  • Page 17: Sensor

    Vaetrix ETG Series User Manual • Sensor A unique feature that sets the ETG series apart from the competition is the ability to display Absolute or Gauge pressure from single unit. Just make your choice and press the SELECT key. The engineering unit chosen will be followed with A (absolute) Absolute pressure is referenced to a perfect vacuum so it’s...

  • Page 18: Snapshot

    Vaetrix ETG Series User Manual • Snapshot If you look carefully at the keypad on the ETG you will notice a camera icon next to right arrow key. The snapshot feature is a quick way to capture and record pressure readings while in Measure Mode.

  • Page 19: Tare

    Vaetrix ETG Series User Manual • Tare The tare feature lets you deduct a pressure value from live Tare is indicated in Measure Mode when applied. pressure. Applications where existing pressure can’t be removed and must be accounted for are perfect for the tare feature.

  • Page 20: Units

    Vaetrix ETG Series User Manual • Units If you would like to focus on a couple different engineering There are twenty three selectable engineering unit available units or prevent certain users from using an unapproved to choose from. In Measure Mode, press the UNITS key and choice for calibration, units can be locked or unlocked under use the ARROW keys to scroll through the options.

  • Page 21: Data Management Application

    Data Management Software. The software application can value to set the logging interval from one second to twenty- be downloaded free at www.vaetrix.com. You can use it for four hours and the press the Start New Session button. A free on a limited basis. If you would like to use the full session can be ended at any time by clicking Stop Session.
  • Page 22 Vaetrix ETG Series User Manual • Datalogging Application Sessions will be listed by time sequence and numerical The software will confirm the files are saved with a pop-up sequence. Check the sessions and name the sessions you box. The software will bring the data in using the...
  • Page 23 Vaetrix ETG Series User Manual • Datalogging Application Sessions will brought in as a Microsoft® Excel Worksheet The Report tab will bring the data in using a preformatted with two tabs (Report and Data). The Data tab will provide report with graphing function. Individual datapoints can be...

  • Page 24: Specifications

    Specifications Power 3AA Alkaline Batteries (LR6) Dimensions 5.95” x 4.08” x 1.65” (Length x Diameter x Depth) Weight 1.77 Pounds (803 Grams) Case Corrosion Resistant Aluminum (Powder Coated) Display Tri-Color Graphics Display, 240 x 120 – Real True Type Font Digits (0.6”/15.2 mm high), Protected with Polycarbonate Positive Pressure Accuracy ±0.05% Full Scale, ±0.1% Full Scale, or ±0.25% Full Scale...
  • Page 25 Specifications Operating Temperature 14°F to 122°F (-10°C to 50°C) Compensated range Storage Temperature -10°F to 150°F (-23°C to 65°C) Remove batteries for storage over thirty days Humidity 0%-95% (Non-Condensing) IP Rating IP65 Handheld and IP54 (Panel Mount – Front) Low Battery Indication 3.7 Volts, 3.5 Volts - Shutdown Battery Life Typical Use (Duracell Ultra)
  • Page 26 Specifications Update Rate 4 Readings Per Second Units 23 Selectable, 1 Custom Bluetooth Optional BLE Low Energy, Registered Under FCC: WAP2001 Warranty 4 Years – Register product at www.vaetrix.com. 4.08 1.65 (103.6) (41.9) 5.95 (151.1) 1.92 (48.8) 2/19/2019...
  • Page 27 Specifications (Panel Mount) Power 5 Volts (USB – Micro B) 50-60 Hz (100V-240V) AC Adapter Provided Dimensions 5.26” Outer Diameter x 4.08”Inner Diameter x 3.1” Depth Weight 1.7 Pounds (771 Grams) 2/19/2019...

  • Page 28: Range Options

    Range Options (0.05% Full Scale) Range (PSI) Full Scale/Span Sensor Burst Media Type ±15 G (Clean, Dry Gas) ±30 G (Clean, Dry Gas) -12 to 15 L (Gas and Liquids compatible with 316SS) -12 to 30 L (Gas and Liquids compatible with 316SS) -12 to 100 L (Gas and Liquids compatible with 316SS) -12 to 300...
  • Page 29 Range Options (0.1% and 0.25% Full Scale) Range (PSI) Full Scale/Span Sensor Burst Media Type ±5 L (Gas and Liquids compatible with 316SS) -12 to 30 L (Gas and Liquids compatible with 316SS) -12 to 100 L (Gas and Liquids compatible with 316SS) -12 to 500 L (Gas and Liquids compatible with 316SS) 1000...

  • Page 30: Model Configurator

    Model Configurator Model Range (PSI) Sensor / Media Accuracy Options ETG = Portable I = Isolated 05 = 0.05% Full Scale BT = Bluetooth BLE Handheld C = Compound EX = Intrinsically Safe ETGP = Panel (Pending) Mount 1000 3000 5000 10000 ETG = Portable...

  • Page 31: Range And Resolution

    Range and Native Resolution Range MBAR KGCM2 INH2O CMH2O MMH2O FTH2O FTSW INHG MMHG TORR (PSI) 4, 20, 60 4, 20 4, 20 20, 60 5.0001 0.3441 344.01 0.0001 138.01 351.01 3515.1 3.0001 11.001 11.001 10.001 258.01 34.001 0.0001 258.01 15.001 1.0001 1034.1...

  • Page 32: Service And Warranty

    RMA form located on the website manufacturing defects and workmanship for a period of (www.vaetrix.com) or feel free to give us a call. Please have forty eight months from the date of shipment to the original the model number, serial number, and reason for return buyer.
