- Page 1 PLEASE READ THIS GUIDE BEFORE RIDING YOUR EBIKE Models: RANGLER / SPEEDSTER / ASCENT USER GUIDE...
-
Page 2: Table Of Contents
CONTENTS: ASSEMBLY / GENERAL PRECAUTIONS BEFORE RIDING SPECIFICATIONS BATTERY BATTERY CHARGING BATTERY STORAGE INSTALLING AND REMOVING THE BATTERY BATTERY WARNINGS CONTROL PANEL AND LED DISPLAY C900E QUICK START – RIDING THE BIKE and PRE-RIDE CHECK LIST NORMAL OPERATION DISPLAY SETTINGS ERROR CODES MAINTENANCE AND STORAGE DO’S and DON’TS... -
Page 3: Assembly / General Precautions Before Riding
ASSEMBLY The assembly of your HIKOBIKE must be performed and safety checked by a HIKOBIKE dealer or bicycle mechanic. Assembly of the stem, handle bars, and tuning of the gears and brakes requires expert bicycle mechanic knowledge. GENERAL PRECAUTIONS BEFORE RIDING... -
Page 4: Battery
BATTERY The HIKOBIKE come standard with a 48V Samsung or LG Li-Ion Battery with a built in Battery Management system (BMS). The BMS is important component as it allows the charger to charge the battery cells evenly, which will maximise the life expectancy and storage power of the battery. -
Page 5: Battery Storage
BATTERY STORAGE Store your battery at dry temperatures between 15-25 deg C. Your battery likes the same temperature you do. When storing the battery for periods longer than 2 months, fully charge the battery and remove the charger from the wall socket. The Battery has a 4 bar charge indicator on the battery pack. Push the button to see how many bars light up. -
Page 6: Installing And Removing The Battery
The battery is then secure and you can remove the key if you wish. BATTERY WARNINGS The Li-Ion battery is one of the major components on the HIKOBIKE e-bike and great effort should be taken to look after it. •... -
Page 7: Control Panel And Led Display C900E
CONTROL PANEL AND LED DISPLAY C900E The control panel by your left thumb has an ON OFF button, a SET button and up and down arrow buttons. When you press the ON button on the LED display the screen will light up. ❶... -
Page 8: Quick Start - Riding The Bike And Pre-Ride Check List
QUICK START - RIDING THE BIKE PRE-RIDE CHECKLIST Please make sure the brake levers are fitted to the correct side of the handlebar for the country before riding. In UK, NZ and Australia the left brake lever is for rear brake and the right brake lever is for the front brake. -
Page 9: Normal Operation
NORMAL OPERATION Press and hold the ON button for 2 seconds to power on the display. Pressing and holding the ON button again for 2 seconds will turn OFF the display. If the bike is not used after 5 minutes the display will turn OFF automatically. -
Page 10: Display Settings
DISPLAY SETTINGS Press and hold the SET button for 2 seconds to enter the main settings menus. In the general set up screen: 1.1 Reset the trip meter – quick press SET to toggle between Y and N 1.2 Brightness for lights – default is 5 1.3 Speed limit is factory set at 45Kph 1.4 Wheel size is 27.5 –... -
Page 11: Error Codes
ERROR Codes Error Code Error Description Trouble Shooting Normal Current error or MOS damaged Contact dealer Throttle error Check throttle connection Motor no phase position Contact dealer Hall error Contact dealer Brake error (start detection) Check the brakes sensors are not stuck on Under voltage Contact dealer Motor stalling... -
Page 12: Maintenance And Storage
MAINTENANCE AND STORAGE Dealer and Bicycle mechanic routine maintenance: Your bicycle should be taken to a servicing dealer or bicycle mechanic after 250km of riding to check the tension of the spokes. Then every 1000km for a general service and inspection. Failure to do this can void your warranty due to unnecessary wear and tear. -
Page 13: Do's And Don'ts
DO’S AND DON’TS Do treat your e-Bike like any bicycle you would want to last well… keep it stored somewhere secure and away from the elements. Don’t treat your e-Bike as a dirt-bike! The motor and battery are weatherproof, but not water- tight. -
Page 14: Warranty
Warranty work should only be carried out by authorised Hikobike agents and does not cover the any transport costs. Hikobike accept no liability for damage to the e-bike or parts that have arisen from: incorrect tuning of moving parts; the improper use of the e-bike; and the improper maintenance of the e-bike. This includes damage as a result of untimely replacement of parts which suffer wear and tear. -
Page 15: Contact
CONTACT United Kingdom www.hikobike.co.uk Email: hello@hikobike.co.uk New Zealand www.hikobike.co.nz Email: info@hikobike.co.nz...
