Power On/Off Button

The Power On/Off button on the port repli-
cator performs the same functions as the
system Suspend/Resume button. The Power
On/Off button allows you to suspend Tablet
PC activity without powering off, resume
your Tablet PC from standby mode, and
power on your system when it has been shut
down from the Windows operating system.
ATTACHING A PORT REPLICATOR
The port replicator can be attached on your
Tablet PC while the power is on, while in
suspend mode, or while the power is off. To
attach the port replicator follow these steps:
1. Align the port replicator connector on
the bottom of the Tablet PC with the
connector on top of the Port Replicator.
2. Push your Tablet PC down where shown
in Figure 3 to connect it to the port
replicator securely.
Do not hold the system by
the port replicator. The port
replicator and/or the system
could be damaged if the port
replicator is used as a handle.
5
