UNVENTED (VENT-FREE)
PROPANE GAS FIREPLACE
OWNER'S OPERATION AND INSTALLATION MANUAL
®
WARNING: If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury, or loss of life.
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity
of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
— Installation and service must be performed by a qualified installer, service agency,
or the gas supplier.
WARNING: This is an unvented gas-fired heater. It uses air (oxygen) from the
room in which it is installed. Provisions for adequate combustion and ventilation
air must be provided. Refer to the Air for Combustion and Ventilation section in
this manual.
DESA INTERNATIONAL
Manually Controlled
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQQQQQ
QQQQQQ
QQQQQQQQQQ
QQQQQQ
QQQQQQQQQQ
Save this manual for future reference.
QQQ
QQQ
QQQ
Shown with optional
cabinet mantel, hearth
base, and trim
accessories.
