3
Intel
SRCSAS144E Characteristics
This chapter describes the characteristics of the Intel
Figure 5 displays the connectors and headers on the controller and Table 1 describes them.
Jumper
J4
J5
J6
J7
J8
13
®
RAID Controller
Table 1. Jumper Descriptions
Description
Flash Recovery
2-pin
jumper
Port activity LED
8 x 2
header
2
SAF-TE I
C header
3-pin
2
SES I
C header
Cache write
2-pin
pending LED
®
RAID Controller SRCSAS144E.
Figure 5. Card Layout
Type
If a normal firmware update fails, place a jumper
across the J4 pins and reflash. The card will not
function as a controller until the jumper is
removed.
LED signal for activity per port for eight ports.
SAF-TE Enclosure management support.
Warning: Do not connect to a non-expander SAS
backplane or data loss may occur.
SES2 Enclosure management support.
Provides a signal indicating the cache has data to
write.
Intel® RAID Controller SRCSAS144E Hardware Guide
