8947RDA-D/-FR
SD/HD RECLOCKING DA
Instruction Manual
Software Version 1.3.1
071843501
APRIL 2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8947RDA-D-FR - V1.3.1 and is the answer not in the manual?

Questions and answers

Related Manuals for GRASS VALLEY 8947RDA-D-FR - V1.3.1

Summary of Contents for GRASS VALLEY 8947RDA-D-FR - V1.3.1

  • Page 1 8947RDA-D/-FR SD/HD RECLOCKING DA Instruction Manual Software Version 1.3.1 071843501 APRIL 2010...
  • Page 2 Affiliate with the N.V. KEMA in The Netherlands CERTIFICATE Certificate Number: 510040.001 The Quality System of: Thomson Inc, and it’s wordwide Grass Valley division affiliates DBA GRASS VALLEY Headquarters 15655 SW Greystone Ct. 10 Presidential Way 400 Providence Mine Rd...
  • Page 3 8947RDA-D/-FR SD/HD RECLOCKING DA Instruction Manual Software Version 1.3.1 071843501 APRIL 2010...
  • Page 4 Benelux/Belgium: +32 (0) 2 334 90 30 Benelux/Netherlands: +31 (0) 35 62 38 42 1 N. Europe: +45 45 96 88 70 Germany, Austria, Eastern Europe: +49 6150 104 444 UK, Ireland, Israel: +44 118 923 0499 Copyright © Grass Valley, Inc. All rights reserved. This product may be covered by one or more U.S. and foreign patents.

  • Page 5: Table Of Contents

    Contents Preface ..............About This Manual .
  • Page 6 Contents Software Updating ........... . Specifications.

  • Page 7: Preface

    Preface About This Manual This manual describes the features of a specific 8900 module in the GeckoFlex Signal Processing System families. As part of this module family, it is subject to Safety and Regulatory Compliance described in the GeckoFlex 8900 Series frame documentation (see the GeckoFlex Frames 8900FX/FF/FFN Signal Processing System Instruction Manual).
  • Page 8 Preface 8947RDA-D/-FR — Instruction Manual...

  • Page 9: 8947Rda-D/-Fr Hd/Sd Reclocking Da Modules

    8947RDA-D/-FR HD/SD Reclocking DA Modules Introduction This manual covers installation, configuration, and operation of the 8947RDA-D Dual HD/SD Reclocking DA and the 8947RDA-FR HD/SD Reclocking Fiber Ready DA, both of which must be installed in a GeckoFlex frame. The 8947RDA-D is a dual HD/SD re-clocking distribution amplifier with automatic format detection.
  • Page 10 Features • Accepts a wide range of standard definition or high definition input signals, • Non-inverted outputs allow distribution of compressed signals for han- dling signals such as DVB-ASI, • Provides a bypass mode for non-supported signal rates, • Provides separate alarm (signal presence detection) for Coax input 1 and Coax input 2 and status management, •...

  • Page 11: Installation

    Installation Installation The front and the rear modules are delivered together as a set: 8947RDA-D front module with the 8900WE-R rear module or the 8947RDA-FR front fiber ready module with 8900WFR-FR rear module. The optional fiber optic submodule ships separately. The front modules can be plugged in and removed from a GeckoFlex frame with power on, without disrupting operation on adjacent running mod- ules.

  • Page 12: Module Installation Precautions

    Installation Module Installation Precautions Please read and follow the precautions listed below before installing the front and rear modules and any fiber optic option submodule (8947RDA-FR models only): • Use standard anti-static procedures during installation. As modules can be installed or removed when the GeckoFlex frame is powered up, before removing the cover, please use an anti-static bracelet tied to a metal part of the frame.

  • Page 13: Rear Module Installation

    Installation Rear Module Installation 1. To remove a blank rear adapter cover (or a rear module already present), manually loosen the two screws holding each retainer clip on the rear adapter cover or rear module to the frame with the retainer clip tool provided inside the front cover of the frame (751- model frames only) or a 2 mm (5/64”) hex screwdriver.

  • Page 14: Front Module Configuration

    Installation Front Module Configuration If you have an 8900NET module (Net Card) in your frame and will be con- figuring the module remotely with a web browser or the Newton Control Panel, install it as described in Installing Front Module on page If you do not have an 8900NET module in the GeckoFlex frame for remote monitoring and configuration, you will need to configure the module using the local onboard controls before installing it in the frame.
  • Page 15 Installation Configuration Switches S1 and S2 Table 1 gives the configuration parameters set with the onboard switches S1 and S2 on the front of the 8947RDA-D circuit board. Table 2 on page 16 gives the configuration parameters set with the onboard switches S1 and S2 on the front of the 8947RDA-FR circuit board.
  • Page 16 Installation Table 2. 8947RDA-FR Switch S1 and S2 Settings Switches S1 and S2 Function 0 (Left/Off) 1 (Right/On) Switch S2 Config Mode LOCAL (Remote control locked out) LCL&REM (Local and Remote) Factory Mode Factory use only Test Mode Factory use only Tx Opt Mode Off (disable transmit outputs) On (enable transmit outputs)

  • Page 17: Installing Front Module

    Installation Installing Front Module After installing the rear module and configuring the front module using local controls if required, install the front module as follows: 1. Remove the front cover of the frame. 2. Locate the front slot corresponding to the rear module you have already installed.

  • Page 18: Optional Fiber Optic Submodule Installation

    Installation Optional Fiber Optic Submodule Installation After the front and rear modules have been installed, install the SFP Fiber Optic submodule option if being used into the rear module metal cage labeled FIBER (Figure 5 on page 19). The SFP submodule is hot-pluggable and may be installed or removed with power applied to the module.
  • Page 19 Installation To install the fiber optic submodule: 1. Slide the fiber optic submodule into the cage connector connected to the front module at the rear of the frame (label on right). 2. When installed properly, the front end of the submodule will line up with the rear module BNCs.

  • Page 20: Cabling

    Cabling Cabling Cabling to the 8947RDA-D or 8947RDA-FR module is done on the BNCs and/or the fiber connector on the rear module (when an optional fiber optic submodule is installed on the 8947RDA-FR) in these sections: • 8947RDA-D Module Cabling on page 22 •...

  • Page 21: Video Outputs

    Cabling Video Outputs The 8947RDA-D and 8947RDA-FR outputs conform to the video standards listed in the output specifications in Table 7 on page For the 8947RDA-FR, the video output(s) from the module can be selected from one of the following sources, depending on the presence and type of fiber optic submodule option: •...

  • Page 22: 8947Rda-D Module Cabling

    Cabling 8947RDA-D Module Cabling The 8947RDA-D front module requires the 8900WE-R rear module. Refer to Table 4 Figure 6 for 8900WE-R cabling information. Table 4. Cabling Inputs and Outputs for 8947RDA-FR Module Mode SDI Inputs Outputs J9 BNC J1, J3, J5, J7: 4 SD or HD-SDI electrical outputs Dual J10 BNC J2, J4, J6, J8: 4 SD or HD-SDI electrical outputs...

  • Page 23: 8947Rda-Fr Module Cabling

    Cabling 8947RDA-FR Module Cabling The 8947RDA-FR requires the 8900WFR-FR rear module. Refer to Table 5 Figure 7 for 8900WFR-FR cabling information. Table 5. Cabling Inputs and Outputs for 8900WFR-FR. Rear Fiber Optic Submodule SDI Inputs Outputs No Fiber optic submodule J9 BNC J1, J2, J3, J4, J5, J6, J7, J8 SD or HD electrical outputs Dual Receiver:...

  • Page 24: Power Up

    Power Up Power Up The on-board LED indicators are illustrated in Figure 8. Upon power-up, the green PWR LED should light and the CONFIG, FAULT and COMM LEDs should illuminate during the module initialization. Note When a module is first plugged into a GeckoFlex frame, the 8900NET module (if present) may report a momentary fault.
  • Page 25 Power Up A red FAULT LED indicates an error situation and, when noted with the other indicator LEDs, can indicate a specific problem area. Table 6 describes signal output and LED indications for the various input/reference combi- nations. Table 6. LED Indicators Indication Condition Normal operation...

  • Page 26: Remote Configuration

    Module and setting up and operating the GeckoFlex 8900 frame network. Note Upgrade software and instructions for the 8900NET can be downloaded from the Grass Valley ftp site. Newton Control Panel Configuration A Newton Control Panel (hard and/or soft version) can be interfaced to the GeckoFlex frame over the local network.

  • Page 27: Web Browser Interface

    Remote Configuration An example of the Newton Configurator is shown in Figure Figure 9. Newton Configurator Example Web Browser Interface The web browser interface provides a graphical representation of module configuration and monitoring. Use of the web interface offers the following considerations: •...
  • Page 28 Remote Configuration In general, graphics and text colors used indicate the following: • Green = Pass – signal or reference present, no problems detected. • Red = Fault – fault condition. • Yellow = Warning – signal is absent, has errors, or is mis-configured. •...

  • Page 29: 8947Rda Links And Web Pages

    Remote Configuration 8947RDA Links and Web Pages The 8900 GUI provides the following links and web pages for the 8947RDA modules (Figure 11): • Status – reports input and output signals and frame bus communica- tion status and module information (page 31), •...

  • Page 30: 8947Rda-D Configuration

    Remote Configuration 8947RDA-D Configuration The 8947RDA-D can be configured using the front edge onboard controls or using the remote controls available with a web browser or a networked Newton Control Panel. Local Configuration For Local configuration, follow the summary of instructions given in Local Configuration on page 14 for using the front edge onboard switches for con-...

  • Page 31: 8947Rda-D Status Web Page

    Remote Configuration 8947RDA-D Status Web Page The Status web page (Figure 12 on page 32) shows the signal status of the input signal(s) and communication with the frame bus. Color coding of the this display indicates the signal status. Refer to Web Browser Interface on page 27 link for an explanation of the color coding.
  • Page 32 Remote Configuration Figure 12. Status Web Page for 8947RDA-D Module 8947RDA-D/-FR — Instruction Manual...

  • Page 33: 8947Rda-D Settings Web Page

    Remote Configuration 8947RDA-D Settings Web Page The Settings web page for an 8947RDA-D (Figure 13 on page 34) provides controls for configuring and reporting status of DA signals. Routing Mode this link Routing Mode area allows selecting the outputs for DA1 and DA2. •...
  • Page 34 Remote Configuration Figure 13. Settings Web Page for 8947RDA-D Module 8947RDA-D/-FR — Instruction Manual...

  • Page 35: Slot Config Web Page

    Remote Configuration Slot Config Web Page Use the Slot Config web page shown in Figure 14 to perform the following functions on the module: this • Locate Module link • Slot Identification • Slot Memory • Frame Health Reporting • LED Reports •...
  • Page 36 Remote Configuration Locate Module Selecting from the pulldown flashes the yellow COMM Flash Locate Module and CONF LEDs on the front of the module so it can be located in the frame. Slot Identification You may identify the module by typing a specific name in the field.
  • Page 37 Remote Configuration When no checkboxes on any of the media module Slot Restore upon Install Config web pages are selected and the checkbox on the Always Slot Refresh 8900NET Configuration web page is unchecked, the slot refresh polling function on the 8900NET module will be disabled. See the Always Slot Refresh checkbox description in the 8900NET (Net Card) Network Interface Module Instruction Manual for more details.

  • Page 38: 8947Rda-Fr Configuration

    Remote Configuration 8947RDA-FR Configuration The 8947RDA-FR can be configured using the front edge onboard controls or using the remote controls available with a web browser or a networked Newton Control Panel. The module is fiber ready and can have one of three types of fiber optic sub- modules installed: •...

  • Page 39: 8947Rda-Fr Status Web Page

    Remote Configuration 8947RDA-FR Status Web Page The Status web page shows the signal status of the input signal(s) and com- munication with the frame bus. Color coding of the display indicates the this signal status. Refer to Web Browser Interface on page 27 for an explanation of link the color coding.
  • Page 40 Remote Configuration Figure 15. 8947RDA-FR Status Web Page - No Fiber Submodule 8947RDA-D/-FR — Instruction Manual...
  • Page 41 Remote Configuration Figure 16. 8947RDA-FR Status Web Page - Dual Receiver Fiber Submodule 8947RDA-D/-FR — Instruction Manual...
  • Page 42 Remote Configuration Figure 17. 8947RDA-FR Status Web Page - Dual Transmitter Fiber Submodule 8947RDA-D/-FR — Instruction Manual...
  • Page 43 Remote Configuration Figure 18. 8947RDA-FR Status Web Page - Transceiver Fiber Submodule 8947RDA-D/-FR — Instruction Manual...

  • Page 44: 8947Rda-Fr Settings Web Page

    Remote Configuration 8947RDA-FR Settings Web Page The Settings web page for the 8947RDA-FR provides configuration of coax and optional fiber optic inputs and outputs and reporting of signal status. this link The parameters for configuration of a 8947RDA-FR module are explained below: Routing Mode configuration will be different depending on the presence...
  • Page 45 Remote Configuration • – Set the reclock mode to or to the specific data rate: Reclock Mode Auto • Auto (disables selection) Signal Format • 143Mb/s • 177Mb/s • 270Mb/s • 360Mb/s • 540Mb/s • 1485Mb/s • ASI • – Select the signal format as .
  • Page 46 Remote Configuration Figure 19. 8947RDA-FR Settings Page - No Fiber Submodule 8947RDA-D/-FR — Instruction Manual...
  • Page 47 Remote Configuration Figure 20. 8947RDA-FR Settings Page - Dual Receiver Submodule 8947RDA-D/-FR — Instruction Manual...
  • Page 48 Remote Configuration Figure 21. 8947RDA-FR Settings Page - Dual Transmitter Submodule 8947RDA-D/-FR — Instruction Manual...

  • Page 49: Slot Config Web Page

    Remote Configuration Figure 22. 8947RDA-FR Settings Page - Transceiver Submodule Slot Config Web Page Use the Slot Config web page description for the 8947RDA-D as described Slot Config Web Page on page this link 8947RDA-D/-FR — Instruction Manual...

  • Page 50: Status Monitoring

    • LEDs on the Frame, 8900NET module, and individual frame media modules, • Web browser status reporting for each frame component, and • SNMP traps, captured by Grass Valley’s NetCentral or another SNMP Manager Application. Note SNMP trap information is only available when an SNMP Agent has been installed and configured.

  • Page 51: Led Reporting

    When SNMP Agent software is installed on the 8900NET module, enabled status reports are sent to an SNMP Manager such as the Grass Valley’s NetCentral application. Status reporting for the frame is enabled or disabled with the configuration DIP switches on the 8900NET module.

  • Page 52: Software Updating

    Networking Application PC option available free of charge from Grass Valley. The procedures for updating software are given in the 8947RDA Release Notes when software updates become available. Check the Grass Valley web site for update information. Refer to Contacting Grass Valley on page 4 for more information.

  • Page 53: Specifications

    Specifications Specifications Specifications for the 8947RDA modules are given in Table 7. Refer to Table 8 on page 54 for SFP Transmitter submodule specifications and Table 9 on page 54 for SFP Receiver specifications. Table 7. 8947RDA Specifications Parameter Value Coax Input Number and type of inputs Up to 2 BNCs for 8947RDA-D, 1 BNC for 8947RDA-FR...
  • Page 54 Specifications Table 8. SFP Receiver/Transceiver Fiber Optic Submodule Specifications Model Number SFP-13103G-M1DRX SFP-13103G-M1TRX Low wavelength 1260nm 1260nm High wavelength 1620nm 1620nm Receiver channels Connector type Fiber support Single mode Data rate 50Mb/s to 3Gb/s Maximum distance @ 3Gb/s 10km Minimum distance 30km Table 9.

  • Page 55: Service

    Grass Valley Customer Service. Module Repair If the module is still not operating correctly, replace it with a known good spare and return the faulty module to a designated Grass Valley repair depot. Call your Grass Valley representative for depot location. Refer to...

  • Page 56: Alarm Summary Tables

    Service Alarm Summary Tables Table 10 below describes the different type of alarms that can occur on the 8947RDA-D module. Table 10. List of Alarms for 8947RDA-D Module Query status Alarm towards Web Page Description Comments Type Net Card & SNMP Status web page: PRES COAX IN...
  • Page 57 Service Table 11 below describes the different type of alarms that can occur on the 8947RDA-FR module and Fiber Optic submodules. Table 11. List of Alarms for 8947RDA-FR Module and Fiber Optic Submodule Query status Alarm towards Web Page Description Comments Type Net Card &...

  • Page 58: Functional Description

    Functional Description Functional Description A block diagram of the 8947RDA-D is shown in Figure Figure 23. 8947RDA-D Block Diagram Equalizer bypass Reclock bypass 4X HD/ HD/SD Equalizer Reclocker SD-SDI SDI In Equalizer bypass Reclock bypass 4X HD/ HD/SD Equalizer Reclocker SD-SDI SDI In Format...

  • Page 59: Configuration Parameter

    Configuration Parameter Summary Table 12 provides a complete summary of the 8947RDA-D and 8947RDA-FR functions and a comparison of the functionality available with the web page and Newton control panel control type along with the ranges and default values for each parameter. Table 12.
  • Page 60 Configuration Parameter Summary Table 12. Summary of 8985PRC Configuration Functions Local Newton Function Range/Choices Web Page/ Default Onboard Control Type Resolution Function Name Controls Panel Bypass, Auto, 143 Mb/s, 177 Mb/s, Settings/ Table 3 on Reclock Mode: Auto 270 Mb/s, Reclock Mode Reclock page 18...
  • Page 61 Index Numerics 8900NET (Net Card) module GeckoFlex frame frame alarm module placement graphical user interface (GUI) block diagram Grass Valley web site cabling Input Format selection 8947RDA-D module Input power 8947RDA-FR module installation fiber optic submodules precautions overview rear module...
  • Page 62 OPT MODULE PRESENT LED web browser overview power specifications recommended PWR LED web site documentation FAQ database Grass Valley software download rear module installation installation precautions Refresh button Restore upon Install checkbox retainer clip tool routing mode Settings web page...
