Summarization of Contents
General Product Information
Transport and Handling
Product is transported to assembly site via crane or forklift; handle carefully to avoid damage.
Storage Guidelines
Store packages temporarily in a dry, dust-free place, away from aggressive gases or liquids.
Commissioning Requirements
Product must not be used until the entire installation is in operational condition.
Personnel Qualifications
Assembly, installation, and commissioning must be performed by instructed personnel only.
Lifting and Anchoring Procedures
Safe Lifting Practices
Read instructions, use designated methods/accessories, lift only the product, do not stand under loads.
Roof Hood Anchoring
All roof hoods are prepared for anchoring; E-Line uses lifting eyes, S-Line has pre-punched holes.
EKO-T and EKO-TD Inlet Installation
Pre-Installation Safety
Follow lifting instructions for safe lifting and ensure inlet is at least 300mm above the roof.
Installation Steps
Calculate cut out size, use lifting points, secure with brackets, and cover inlet with sealing method.
Sloping Roof Cut-Out Calculation
Formula for cut out size on sloping roofs using width and constant Y from diagram.
EKO-SUH Installation Guide
EKO-SUH Attachment
Place EKO-SUH in roof hood outlet and adapt to attachment points in the hood.
Securing EKO-SUH
Lock EKO-SUH with blind rivet nut M10 and sheet metal screws.
Calculating Outlet Area
Use formula A = q/v to determine outlet area based on desired speed and available airflow.
Mount Frame Assembly Instructions
Frame Plate Folding
Instructions for folding and locking four loose angle plates to form the mount frame.
Mount Frame Installation
Attaching Frame to Inlet
Place mounting frame on Roof inlet and screw it securely using self-drilling sheet metal screws.
Roof Hood Installation
Hood Placement and Fastening
Place hood upright on mounting frame and attach using self-drilling sheet metal screws.
Combined Hood Gasket Use
For Combined Hoods, mount the supplied gasket between exhaust air and intake air.
Routine Maintenance Checks
Damage and Securement Inspection
Check for visible damage, secure attachment to inlet, and condition of wire mesh.
Airflow and Drainage Integrity
Remove obstructions like leaves/snow; ensure airflow and drainage holes are clear.
Product Cleaning Guidelines
Cleaning Frequency and Methods
Cleaning frequency depends on facility needs and warranty. Avoid high-pressure cleaners.
