What You Need
Technical Specifications
Details on product weight, dimensions, flow rate, pressure, and environmental conditions.
Integral 4PLUS Flow Meter Components
Integral 4PLUS Pump Power/Brite Components
Lists components for the integral 4PLUS PUMP POWER and PUMP BRITE accessories.
Integral 4PLUS PowerPACK ex Components
Lists components for the integral 4PLUS powerPACK ex accessory.
Integral 4START Accessories Components
Integral 4START Power Pipe Components
Details components for the integral 4START POWER PIPE accessory.
Integral 4START Brite Pipe Components
Details components for the integral 4START BRITE PIPE accessory.
Mounting Options
Integral 4WALL Option
Details the components and installation for the integral 4WALL option.
Integral 4PLUS Display Option
Details the components and installation for the integral 4PLUS DISPLAY option.
Required Tools
Lists the necessary tools for installation and setup procedures.
Mounting Possibilities
Undertable Mounting
Illustrates how to mount the dispenser under a table or counter.
Wall Mounting
Illustrates how to mount the dispenser directly onto a wall.
Electrical and Water Connections
Power Supply Connection
Illustrates connecting the power adapter to the dispenser and power source.
Water Supply Connection
Shows how to connect the water hose to the dispenser and water source.
Pump Insertion
Scan Dispenser
Instruction to scan the dispenser using a mobile device.
Scan Pump
Instruction to scan the pump unit using a mobile device.
Flow Meter and Dispenser Installation Steps
Scan Flow Meter
Instruction to scan the flow meter using a mobile device.
Dispenser Physical Steps
Illustrates physical steps for installing the dispenser unit.
Dispenser Assembly Steps
Step 6: Component Insertion
Illustrates using a screwdriver to insert a component into the dispenser.
Hose and Connection Steps
Step 7: Connect Hoses
Illustrates connecting the internal hoses to their respective ports.
Step 8: Secure Connection
Shows the process of securing a connection, indicated by a 'CLICK' sound.
Coupling Installation
Step 9: Coupling Procedure
Illustrates pressing, pushing, and verifying the chemistry coupling for secure attachment.
Label Insertion
Step 1: Prepare Label Area
Shows how to open a compartment for label insertion.
Step 2: Insert Label
Illustrates placing the label into the designated slot.
Step 3: Follow App Instructions
Instructs the user to follow the mobile application for label setup.
Individual Dispenser Installation
Under-Table Mounting
Illustrates the first two steps for under-table mounting of a single dispenser.
Under-Table Mounting Steps
Step 3: Drill Mounting Holes
Shows drilling holes into the wall for mounting the bracket, with material guidance.
Step 4: Insert Wall Plugs
Illustrates inserting wall plugs into the drilled holes.
Bracket Mounting Procedure
Step 5: Insert Wall Plugs
Illustrates inserting wall plugs into the prepared holes.
Step 6: Attach Mounting Bracket
Shows screwing the mounting bracket to the wall.
Wall Mounting Individual Dispenser
Step 1: Apply Template
Shows applying a sticker or template to mark drilling points on the wall.
Step 2: Drill and Prepare
Illustrates drilling holes and preparing for bracket attachment.
Step 3: Attach Bracket
Shows securing the mounting bracket to the wall.
Further Mounting Steps
Step 4: Side Part Attachment
Illustrates attaching side parts to the dispenser unit.
Step 5: Attach Bottom Part
Shows attaching a bottom component to the dispenser.
Step 6: Attach Bottom Part
Illustrates attaching another bottom component with a 'CLICK' sound.
Step 7: Final Bracket Attachment
Shows the final attachment of the mounting bracket.
Row Installation
Under-Table Row Mounting
Illustrates the initial steps for mounting multiple dispensers in a row under a table.
Row Mounting Bracket Installation
Step 3: Position Bracket
Shows positioning the mounting bracket for row installation.
Step 4: Drill Mounting Holes
Illustrates drilling holes for attaching the row mounting bracket.
Row Mounting Hole Preparation
Step 5: Drill Holes for Row Mounting
Shows drilling holes for the row mounting bracket.
Step 6: Insert Wall Plugs
Illustrates inserting wall plugs into the drilled holes for row mounting.
Securing Row Mounting Bracket
Step 7: Attach Row Bracket
Shows attaching the row mounting bracket to the wall.
Row Capacity
Indicates the maximum number of dispensers that can be mounted in a row.
Wall Row Installation
Step 1: Apply Wall Template
Shows applying a template for marking wall mounting points for row installation.
Step 2: Drill and Prepare Wall
Illustrates drilling holes and preparing the wall for row mounting.
Step 3: Attach Row Bracket
Shows securing the mounting bracket for row installation on the wall.
Further Wall Row Mounting Steps
Step 4: Side Part Attachment
Illustrates attaching side parts to the dispenser for wall row mounting.
Step 5: Attach Bottom Part
Shows attaching a bottom component to the dispenser for wall row mounting.
Step 6: Attach Bottom Part
Illustrates attaching another bottom component with a 'CLICK' sound.
Step 7: Final Bracket Attachment
Shows the final attachment of the mounting bracket for wall row installation.
Row Mounting Bracket Finalization
Step 8: Attach Back Plate
Illustrates attaching a back plate to the mounting structure.
Step 9: Secure Row Units
Shows securing multiple row units with screws.
Completing Row Installation
Step 10: Secure Unit Attachment
Illustrates securing the dispenser units to the bracket.
Step 11: Final Unit Click
Shows the final click-in mechanism for securing the dispenser.
Step 12: Final Row Assembly
Shows the completed row installation with up to three dispensers.
Integral 4PLUS Flowmeter Installation
Step 1: Check Water Temperature
Specifies the acceptable water temperature range for the flowmeter.
Step 2: Connect Power
Illustrates connecting the flowmeter to the power supply.
Step 3: Water Connection Setup
Shows preparing the water tap for connection.
Step 4: Connect Flowmeter
Illustrates connecting the flowmeter to the water supply hose.
Flowmeter Hose Connection
Step 5: Secure Flowmeter Connection
Shows securing the flowmeter connection, with warnings about incorrect attachment.
Step 6: Connect to Dispenser
Illustrates connecting the flowmeter hose to the dispenser and turning water on.
Hose and Cable Routing (Individual Dispenser)
Hose Installation
Illustrates routing the detergent and rinse-aid hoses for individual dispensers.
Cable Installation
Shows routing the power supply cable for individual dispensers.
Hose and Cable Routing (Multiple Units)
Flowmeter Cable Connection
Illustrates connecting the flowmeter cable to the dispenser unit.
General Cable Routing
Shows general routing of cables for multiple dispenser units.
Side Part Mounting
Step 1: Attach Left Side Part
Illustrates attaching the left side part to the dispenser.
Step 2: Attach Right Side Part
Illustrates attaching the right side part to the dispenser.
Dispenser Mounting
Step 1: Prepare for Insertion
Shows how to push the dispenser to prepare for mounting.
Step 2: Connect Internal Cables
Illustrates connecting internal cables after dispenser insertion.
Dispenser Cable Connection and Closing
Step 3: Connect External Cables
Shows connecting external cables to the dispenser.
Step 4: Close Compartment
Illustrates closing the dispenser compartment.
Connecting L-Parts
Step 1: Prepare L-Part
Shows the L-part component before connection.
Step 2: Connect L-Part
Illustrates connecting the L-part to the hose.
Step 3: Attach L-Part to Dispenser
Shows connecting the L-part to the dispenser's input.
L-Part Hose Connection Details
Step 4: Secure Hose Connection
Shows securing the hose connection to the L-part.
Step 5: Alternative L-Part Connection
Illustrates attaching an L-part to a different dispenser type.
Connecting Cables
Step 1: Connect Dispenser Cables
Illustrates connecting the main cables to the dispenser units.
Final Cable Connections and Closing
Step 2: Secure Cable Cover
Shows placing and securing the cable cover.
Step 3: Close Compartment
Illustrates closing the dispenser compartment.
Step 4: Final Cable Click
Shows the final cable connection with a 'CLICK' indication.
Hose Routing (Row Installation)
Step 1: Route Detergent Hose
Illustrates routing the detergent hose for row installation.
Step 1: Route Rinse-aid Hose
Illustrates routing the rinse-aid hose for row installation.
Cable Routing (Row Installation)
Power Supply and Flowmeter Cable Routing
Shows routing power and flowmeter cables for row installation.
Right Side Cable Routing
Illustrates cable routing for the right side of the row setup.
Side Part Mounting (Row Installation)
Step 1: Attach Left Side Part
Illustrates attaching the left side part for row installation.
Step 2: Attach Right Side Part
Illustrates attaching the right side part for row installation.
Dispenser Insertion (Row Installation)
Step 1: Prepare for Dispenser Insertion
Shows pushing the dispenser to prepare for row mounting.
Step 2: Connect Dispenser Hoses
Illustrates connecting detergent and rinse-aid hoses to dispensers.
Dispenser Cable Connection and Closing (Row)
Step 3: Connect Dispenser Cables
Shows connecting external cables to the dispensers in a row.
Step 4: Close Dispenser Compartments
Illustrates closing the dispenser compartments.
Connecting L-Parts (4START POWER)
Step 1: Prepare for L-Part Connection
Shows the dispenser unit prepared for L-part connection.
Step 2: Connect L-Part to Hose
Illustrates connecting the L-part to the hose for 4START POWER.
L-Part Hose Connection Details (4START POWER)
Step 3: Secure Hose Connection
Shows securing the hose to the L-part for 4START POWER.
Step 4: Attach L-Part to Dispenser
Illustrates attaching the L-part to the dispenser for 4START POWER.
Connecting L-Parts (4START BRITE)
Step 5: Connect L-Part to Hose (BRITE)
Illustrates connecting the L-part to the hose for 4START BRITE.
Repeat for Rinse-aid Dispenser
Instructs to repeat steps for the rinse-aid dispenser.
Connecting Cables (Multiple Dispensers)
Step 1: Connect Unit Cables
Illustrates connecting cables to multiple dispenser units.
Step 2: Secure Cable Covers
Shows placing and securing the cable covers.
Cleaner Connection Installation
Tank Inlet Installation
Shows how to install the tank inlet and route hoses into the dishwasher.
Cleaner Connection Setup
Step 3: Drill Inlet Hole
Illustrates drilling a hole for the cleaner inlet connection.
Step 4: Connect Cleaner Feed Line
Shows connecting the cleaner feed line with appropriate fittings.
Rinse-Aid Connection Installation
Check Valve Installation
Illustrates installing the check valve for the rinse-aid line.
Secure Hoses and Cables
Shows securing all cables and hoses to prevent strain.
Electrical Power Connection
Step 1: Connect Power Adapter
Illustrates connecting the power adapter to the power source.
Step 2: Route Power Cable
Shows routing the power cable.
Step 3: Secure Cable Attachment
Illustrates securing the power cable attachment.
Step 4: Final Power Connection
Shows the complete power connection setup for the dispensers.
App Activation
Step 1: Scan QR Code for App
Shows scanning a QR code to activate the dispenser via the app.
Step 2: Verify Installation in App
Instructs to check installation status and details within the mobile application.
Wearing Parts and Maintenance
Lists components considered wearing parts and mentions app-based service intervals.
Operation and Cartridge Exchange
Cartridge Exchange Steps
Illustrates the step-by-step process for replacing the cartridge.
Pictograms (Integral 4PLUS Dispenser)
Power Status Pictograms
Explains pictograms related to dispenser power status (ready, error, no power).
Cartridge Status Pictograms
Explains pictograms related to cartridge status (empty, reserve, wrong product).
Connectivity Pictograms
Explains pictograms related to Bluetooth connectivity.
Pictograms (Integral 4PLUS Display)
Display Power Status Pictograms
Explains pictograms for display power status (ready, error, empty battery).
Display Cartridge Status Pictograms
Explains pictograms for display cartridge status (empty, wrong product).
Display Battery Status Pictogram
Explains the pictogram for battery drain on the display.
EC Declaration of Conformity
Distributor Information
Details the distributing company and its address.
Compliance with Directives and Standards
Lists European directives and harmonised standards the system complies with.
Need help?
Do you have a question about the ecosol POWER and is the answer not in the manual?
Questions and answers
