YS No. Description
6405 RED 3MM LED 1V7 5MA
6408 GRN 3MM LED 1V9 5MA FROSTED
6825 1N4148 75V 0A45 DIODE
6438 1N4007 400V 1A0 DIODE
6827 1N5402 200V 3A0 DIODE
6822 1N4745A 16V0 1W0 ZENER 5% T&R
6824 1N5246B 16V0 0W5 ZENER 5% T&R
5105 MPSA13 TO92 NPN TRANS DARL T&R
6755 LM3876T IC 40 WATT POWER AMP
6798 MC4741CP IC QUAD OP AMP
6840 MC33078P IC DUAL OP AMP
6882 TL072CP IC FET DUAL OP AMP
6889 TL074CN IC QUAD O/A T.I ONLY
5402 _15P 100V 10%CAP T&R BEAD
5199 100P 100V 2%CAP T&R RAD CER.2"NPO
5410 100P 100V 10%CAP T&R BEAD
5420 680P 50V 10%CAP T&R BEAD
5422 __1N 50V 10%CAP T&R BEAD
5208 __2N2 400V 5%CAP T&R RAD
6451 __4N7 250V 20%CAP BLK 'Y' 10MM AC
5204 _10N 100V 10%CAP T&R RAD
5207 _18N 100V 5%CAP T&R RAD
6435 _22N 275V 20%CAP BLK 'X2' 15MM AC
5308 _47N 50V 10%CAP T&R BEAD
5310 _68N 50V 10%CAP T&R BEAD
5228 100N 100V 5%CAP T&R RAD
5314 100N 50V 10%CAP T&R BEAD
5230 180N 63V 5%CAP T&R RAD
5317 180N 50V 10%CAP T&R BEAD
5231 220N 63V 10%CAP T&R RAD
5233 330N 63V 5%CAP T&R RAD
5234 470N 63V 10%CAP T&R RAD
5255 __1U 63V 20%CAP T&R RAD
5256 __1U 63V 5%CAP T&R RAD
5257 __2U2 63V 20%CAP T&R RAD
5945 _10U 63V 20%CAP T&R RAD
5961 _33U 16V 20%CAP T&R RAD
5267 100U 25V 20%CAP T&R RAD
5630 330U 25V 20%CAP BLK 10X13MM EL
5887 2200U 50V 20%CAP BLK 18X27MM EL
4417 _10K 5B LIN 9MM HORIZONTAL P28
4418 _10K 5C R/A 9MM HORIZONTAL P28
4420 _50K B LIN 9MM HORIZONTAL P28
4419 100K B LIN 12MM HORIZONTAL STP27
711 30 X 50 X 1.5MIL PLASTIC BAG
3804 SNAP ON 1.5" INSULATING BUSHING
8547 PLASTIC FOOT BLACK, POLYETHYLENE
8570 CORNER, 2 LEGS NOTCED LIP BLACK
3463 CLIP 110X020 18-22AWG DISCO/INSL
3478 CLIP 205/187X032 18-22AWG DISCO/INS
3489 CLIP 250X032 18-22AWG DISCO/INSL
3490 CLIP 250X032 14-16AWG DISCO/INSL
3601 RING TERMINAL 16AWG WIRE & #8 SCREW
3682 250 MALE PCB TAB REEL
3795 #8 GROUND LUG ZIERICK 505-169
3498 1/4" JCK PCB MT HORZ
3886 36" RCA DUAL RED-WHITE PREFAB CABLE
3914 RCA SNGL PCB MT HORZ
3417S 6-32 SCREW TERMINAL PC MNT SNAP-IN
3660 XLR FEML PCB MT HORZ
3451 EYELET SMALL 0.089 OD PLATED
3414 INTERNATIONAL PC MOUNT FUSEHOLDER
2468 0.800 AMP SLO-BLO .25X1.25
8451 10" STRAP HANDLE,BLACK METAL ENDCAP
8604 10-32 T NUT
7417 8R 30W TWEETER PIEZO TLC 1
3745 DUAL XSISTOR PBL SPRING CLEAR ZINC
9897 CABINET COVER, BLACK, 54" WIDE
3645 AC SOCKET RECEPTACLE WITH 0.250 TAB
3801 5/8" BUMPER BUTTON BLACK
3803 NYLON SECUR-A-TACH MINI PLASTIC TIE
3810 4" NYLON CABLE TIE
8642 MAROON KNOB FOR AM WINE RED SERIES
8649 BUTTON KNOB FLAT BLACK
3428 8' 3/18 SJT AC LINE CORD REMOVABLE
3834 HEYCO #1214 STRAIN RELIEF
8267 SMALL TRAYNOR LOGO EMBOSSED ALUMIN.
8910 YORKVILLE PRODUCT MANUAL
8900 YORKVILLE WARRANTY CARD 2-YR UNLTD.
8701 4-40 KEPS NUT ZINC
8800 6-32 KEPS NUT ZINC
8787 8-32 KEPS NUT ZINC
8845 10-32 PEMNUT C-1032-2-Z1
8898 1/4-20 CAGE NUT C79 98142027
3830 TO218 PREGREASED MICA 56-78-2AP
8581 CUSTOM PBL TRANSISTOR SPACER
4597 22AWG STRAN TC WIR
YS-118PW
Qty.
BRT 2
1
T&R 7
T&R 1
4
2
1
2
1
1
1
4
2
NPO 2
2
NPO 3
NPO 2
NPO 4
.2"FLM 2
1
.2"FLM 2
.2"FLM 2
1
X7R 1
X7R 1
.2"FLM 1
X7R 15
.2"FLM 1
X7R 1
.2"FLM 2
.2"FLM 1
.2"FLM 1
.2"EL 3
.2"FLM 2
.2"EL 1
.2"EL 1
.2"NP 2
.2"EL 3
2
2
2
1
2
1
1
1
8
6
2
2
9
1
3
10
2
3
1
2
2
1
6
2
FUSE 1
1
2
1
1
1
1
1
1
5
6
1
1
1
1
1
1
2
3
2
2
2
1
1
JMP 7
YS No. Description
4599 22AWG SOLID SC WIR T&R JMP
5299 24AWG SOLID SC WIR RAD JMP
4675 1/2W 10R 5% T&R RES
4816 1/4W 33R 5% T&R RES
4704 5.0W 33R 5% BLK RES
4897 1/4W 120R 5% T&R RES
4857 1/4W 220R 5% T&R RES
4770 1/4W 249R 1% T&R RES
4655 1/2W 330R 5% T&R RES
4799 1/4W 562R 1% T&R RES
4981 1/4W 1K 5%MINI T&R RES
4824 1/4W 1K5 5% T&R RES
6113 1/4W 2K 5%MINI T&R RES
4883 1/4W 2K49 1% T&R RES
4827 1/4W 4K7 5% T&R RES
4639 1/4W 4K99 1% T&R RES
4893 1/4W 5K1 5% T&R RES
4863 1/4W 8K2 5% T&R RES
4800 1/4W 10K0 1% T&R RES
4829 1/4W 10K 5% T&R RES
6116 1/4W 10K0 1%MINI MF T&R RES
4830 1/4W 15K 5% T&R RES
6123 1/4W 20K0 1%MINI MF T&R RES
4840 1/4W 33K 5% T&R RES
4834 1/4W 47K 5% T&R RES
4803 1/4W 49K9 1% T&R RES
4836 1/4W 68K 5% T&R RES
6120 1/4W 100K 5%MINI T&R RES
4849 1/4W 180K 5% T&R RES
4844 1/4W 1M 5% T&R RES
3586 ACC# 1BB1C1C SHORT REVERB
8742 4-40 X 3/8 PAN PH TAPTITE JS500
8842 #4 X 5/16 PAN QUAD TYPE A JS500 BLK
8801 6-32 X 3/8 PAN PH TAPTITE JS500
8829 6-32 X 3/8 FLAT PH TAPTITE BO#4 HEA
8828 6-32 X 3/4 PAN PH TAPTITE JS500
8876 #6 X 1 1/2 PAN PH TYPE A JS500 BLK
8763 8-32 X 1/2 PAN PH MS JS500 BLACK
8767 #8 X 3/4 PAN PHIL TYPE A JS500 BLK
8815 8-32 X 3/4 PAN PH TAPTITE JS500
8749 10-32 X 1/2 QDX PH TAPTITE JS500
8753 #10 X 1/2 PAN PH TYPE A JS500 BLACK
8781 #10 X 7/8 FLAT PHIL TYPE A JS500BLK
8912 10-32 X 1 FLAT PHIL MS JS500 BLK
8843 10-32 X 1 1/8 FLAT PH MS JS500
8770 1/4-20 X 1 5/16 TRUSS PH MS JS500
8905 YORKVILLE PRODUCT SCHEMATIC
3833 8 X 3/8 (250 OD,.171 ID)NY SPACER
7331 8" 8R 50WPGM SPEAKER
8820 #8 FLAT WASHER JS500
8473 #10 BLACK CUPWASHER SWF-10BK
3421 DPDT PUSH SW PCMT MAKE B4 BREAK
3698 SPST ROKR SW QUIK 180" AC PWR BL/BL
8468 VELCRO STRAP 3/4"X22CM (VELSTRAP)
1309 BLOC-40B/40K/40W/50B
Qty.
41
2
2
1
1
2
4
2
8
2
3
3
3
1
5
4
1
2
12
9
3
2
2
2
2
1
1
5
2
1
1
2
2
5
4
3
4
2
8
1
1
16
10
2
2
2
1
3
1
4
3
1
1
1
XFMR 1
