Summarization of Contents
QuickStart
Safety check
Check brakes and tyre pressure before starting your X Speed.
Launch of the electric drive
How to start the system using the E-Key or by pedalling.
Charging the rechargeable battery
Guide on how to charge the battery using the provided charger.
Klever's BIACTRON System
6.1 Sensors and their function
Explains sensor functions for motor support.
6.2 Levels of electric motor support
Details the 5 levels of motor support and their usage.
6.3 Regeneration of battery capacity
Explains energy recovery during braking or coasting.
6.4 Display
Overview of the display unit and its functions.
6.4.1 Function of each button
Describes the functions of the display's buttons.
6.4.2 Display content
Explains the various information shown on the display.
6.4.3 The menu and submenus for settings
Guide to accessing and using the display's settings menu.
Bicycle Parts of X Speed Models
7.1 The speed pedelec, a type-approval vehicle with dedicated equipment
Classification and special equipment.
7.2 Saddle and handlebar adjustment
Adjusting saddle height and handlebar position.
7.3 Air sprung suspension fork
Front suspension fork features and settings.
7.4 Disc brakes
Hydraulic disc brakes, features, and maintenance.
7.5 Belt drive and 12-speed gearbox
Overview of the belt drive and 12-speed gearbox system.
7.5.1 Powerful advantages
Highlights the benefits of the belt drive and gearbox combination.
7.6 Lighting
Details the LED lighting system.
7.7 Wheels and tyres
Information on wheel maintenance and tyre checks.
7.8 Luggage carrier and transport of luggage
Information on the luggage carrier's capacity and load limits.
7.9 Anti-theft protection
Describes the integrated motor lock, immobiliser, and alarm system.
Maintenance, Care and Storage
Maintenance
Regular cleaning, lubrication, and care for longevity.
Storage
Guidelines for storing the vehicle, especially in winter.
Technical Data X Speed 45
Display
Specifications of the illuminated colour LCD display.
Rechargeable battery
Details on battery type, capacity, charging, and temperature limits.
Motor
Specifications for the brushless DC rear hub motor.
Product Liability and Warranty
Warranty claims are granted
Conditions under which warranty claims are accepted.
Warranty claims are rendered void
Conditions that void warranty claims.
Wear
1. Brake discs and pads
Regular inspection and replacement of brake discs and pads.
2. Tyre and inner tubes
Checking tyre pressure, tread depth, and condition.
3. Rims and spokes
Checking wheel concentricity and spoke tension.
4. Belt, rear sprocket, front belt wheel
Maintenance of belt drive components.
FAQ's
How far can I travel with one battery charge?
Information on battery range based on various factors.
Must the battery be empty before I can charge it?
Clarifies that the battery can be charged anytime.
Inspection Plan
1. Inspection & maintenance
First service interval: 500-1,000 km or 1 year.
2. Inspection & maintenance
Second service interval: 3,000-4,000 km or 2 years.
