Summarization of Contents
2.0 System Overview
2.1 Major Components
Details the key components of the M200/M400 Smoke Curtain system, including the smoke detector and AC line.
2.2 Optional Components
Lists optional components available for the M400 model, such as Wall Activation Switch and Controller Backup Battery.
3.0 Install Preparation
3.1 Verify Field Preparation
Details site requirements and clearances needed before installing the Smoke Guard system.
3.2 Preparing the Housing for Mounting
Instructions on how to prepare the housing unit, including removing the dust cover and screen assembly.
4.0 Mounting the Housing and Auxiliary Rails
4.1 Installing the Mounting Plate
Step-by-step guide for installing the mounting plate, including marking height and ensuring levelness.
4.2 Mounting the Housing
Procedure for lifting and securing the housing unit onto the previously installed mounting plate.
4.3 Installing the Auxiliary Rails
Instructions for attaching auxiliary rail backers and rails to the elevator frame for effective sealing.
5.0 Installing the Screen
5.1 Installing the Screen
Guide for attaching the screen to the J-hooks, unrolling, and securing the top bar for proper operation.
5.2 Attaching the Extension Springs (M400 only)
Detailed steps for connecting the door closer extension springs to the housing door for the M400 model.
5.3 Installing the Screen Rewind Switch
Instructions for mounting the Screen Rewind Switch (SRS) on the screen for temporary retract functionality.
6.0 Testing and Adjusting
6.1 Testing the Installation
Procedures for cycle testing the unit to verify screen seal, diode, and rewind switch functionality.
6.2 Anchoring the Magnets
Guide for anchoring the magnets on the threshold pulleys to ensure a proper seal with the rails.
7.0 Finishing the Installation
7.1 Preparing the Unit for Wiring
Steps to prepare the unit for wiring, including disconnecting power and securing the housing door.
7.2 Installing the Dust Cover
Instructions for installing the housing dust cover to protect internal components and maintain aesthetics.
7.3 Wiring
Details electrical contractor and fire alarm technician responsibilities for AC and low voltage wiring.
7.4 Setting the Unit in a Ready State
Procedure to set the unit into a ready state after all wiring is complete, for both M200 and M400 models.
7.5 Final Testing
Final checks to ensure the screen operates correctly when the initiating device is activated.
8.0 Troubleshooting
8.1 Spotting an error
Guidance on how the M200/M400 system indicates a problem and how to identify potential error states.
8.2 Troubleshooting the M200 and M400 without battery
Table and solutions for diagnosing and resolving issues with M200 and M400 models lacking a backup battery.
8.3 Troubleshooting the M400 with battery
Steps for silencing alarms and clearing errors for the M400 model when equipped with a backup battery.
8.4 Error Codes – M400 with Battery
A comprehensive table listing error codes, states, descriptions, causes, and tones for the M400 with battery.
8.5 Solutions Guide
Provides detailed steps to resolve specific error codes for the M400 system, including contact information.
