Summarization of Contents
Important Notice
Box Contents
Lists all components included in the Speedplay pedal system package.
Cleat Installation
Choose Shims for Base Plate Fit
Select appropriate shims for the base plate to ensure the best fit to the shoe sole.
Attach Base Plate to Shoe
Secure the base plate to the shoe using the provided base plate screws.
Fit Cleat Surround
Place the cleat surround around the installed base plate.
Fit Protector Plate to Spring & Housing
Assemble the protector plate with the spring and housing components.
Attach Assembly to Base Plate
Secure the assembled unit to the base plate using protector plate screws.
Adjust Limit Screws for Float
Tighten limit screws to reduce heel movement and set desired float.
Fit Cleat Cover
Secure the cleat cover over the edges of the protector plate.
Apply PTFE Dry Lube (Optional)
Apply dry lube to the spring for reduced engagement force.
