Important Notice
General Safety Warnings
Read and follow all safety information before assembly and use to prevent injury.
Box Contents
Base Plates and Shims
Includes base plates with pre-installed shims and separate shim packets.
Cleat Surrounds and Covers
Components for securing cleats to the shoe, including surrounds and covers.
Protector Plates and Spring Housing
Parts for protecting the cleat mechanism and housing the spring.
Screw Packet
Contains screws for base plates and protector plates.
Tools Required
Required Tools
Lists the necessary Allen wrenches and screwdrivers for installation.
Cleat Installation
Choose Shims for Base Plate Fit
Select the appropriate shims to ensure the best fit between the base plate and shoe sole.
Screw Base Plate to Shoe
Attach the base plate to the shoe using the correct base plate screws and torque.
Fit Cleat Surround
Place the cleat surround around the base plate, ensuring correct left/right orientation.
Fit Protector Plate to Spring & Housing
Assemble the protector plate with the spring and housing mechanism.
Screw Assembly to Base Plate
Secure the protector plate assembly to the base plate using specific screws and pattern.
Adjust Limit Screws for Float
Adjust limit screws to control foot float or heel movement while pedaling.
Fit Cleat Cover Over Protector Plate
Install the cleat cover, ensuring it fits flush with the cleat surround.
Apply PTFE Dry Lube (Optional)
Apply dry lube to the spring to reduce cleat engagement force.
Pedal Installation
Clean Crank Arm Threads and Grease
Clean crank arm threads and apply a small amount of grease before pedal installation.
Identify Left and Right Pedals
Distinguish between left and right pedals using the Wahoo logo orientation.
Thread Pedals onto Crank Arm
Install pedals onto the correct crank arm using the specified wrench and torque.
