24"/32" 720p, 60Hz
48" 1080p, 60Hz
LED Roku TV
English
Version 7.5
NS-24ER310NA17 / NS-24ER310CA17
NS-32DR310NA17 / NS-32DR310CA17
NS-48DR510NA17
Before using your new product, please read these instructions to prevent any damage.
Illustrations in this guide are provided for
reference only and may differ from actual
product appearance. Product design and
specification may be changed without notice.
USER GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ROKU TV NS-24ER310CA17 and is the answer not in the manual?

Questions and answers

Related Manuals for Insignia ROKU TV NS-24ER310CA17

Summary of Contents for Insignia ROKU TV NS-24ER310CA17

  • Page 1 USER GUIDE 24"/32" 720p, 60Hz 48" 1080p, 60Hz LED Roku TV English Version 7.5 NS-24ER310NA17 / NS-24ER310CA17 NS-32DR310NA17 / NS-32DR310CA17 NS-48DR510NA17 Illustrations in this guide are provided for reference only and may differ from actual product appearance. Product design and specification may be changed without notice.

  • Page 2: Table Of Contents

    Contents CHILD SAFETY ............. . . 7 Important Safety Instructions .
  • Page 3 Contents AV (good) ............... . 37 24"...
  • Page 4 Contents Benefits of connecting ............64 Connecting brings out your TV's full potential!.
  • Page 5 Contents Following on Roku..............81 Recent Searches .
  • Page 6 Legal notices ............. .110 One-year limited warranty - Insignia Televisions ......114...

  • Page 7: Child Safety

    CHILD SAFETY PROPER TELEVISION PLACEMENT MATTERS THE CONSUMER ELECTRONICS INDUSTRY CARES Manufacturers, retailers and the rest of the consumer electronics industry are committed to making home entertainment safe and enjoyable. As you enjoy your television, please note that all televisions - new and old - must be supported on proper stands or installed according to the manufacturer's recommendations.

  • Page 8: Important Safety Instructions

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 Important Safety Instructions 12 Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use CAUTION caution when moving the cart/apparatus combination to RISK OF ELECTRIC SHOCK avoid injury from tip-over.

  • Page 9: Caution

    Handling the LCD panel Outdoor antenna grounding • Your TV’s screen is made of glass. Do not drop your If an outside antenna or cable system is connected to TV or hit, jolt, or press hard against the LCD panel. If your TV, make sure that the antenna or cable system is the screen breaks, be careful of broken glass.
  • Page 10 NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 End of life directives Non-active pixels Your TV may contain materials that are regulated for The LCD panel contains almost 3 million thin film environmental reasons. Your TV also contains transistors, which provide exceptionally sharp video materials that can be recycled and reused. To help quality.

  • Page 11: Welcome

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV 24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Welcome Congratulations on the purchase of your new TV! Discover the joy of endless entertainment. After it's set up, you'll be able to access a world of streaming content channels that may include Netflix, YouTube, Crackle, CNET and literally thousands more.
  • Page 12 NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 6 Send your personal media to the big screen • Send personal photos, videos, and music from your compatible smartphone or tablet to the TV screen in just a few taps. Plus, with certain channels, such as Netflix and YouTube,, send movies, shows, sport highlights, and more directly to your TV.

  • Page 13: Installing The Stand(S) Or Wall-Mount Bracket

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Installing the stand(s) or wall-mount bracket • If you want to place your TV on a table or in an entertainment center, go to Installing the stand(s). • If you want to mount your TV on a wall, go to Installing a wall-mount bracket.

  • Page 14: 32" Model

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 2 Align the TV stand with the screw holes on the bottom of your TV, then secure the stand to your TV with the four provided screws. Screw type Screw length # of screws 15 mm 32" model Note •...

  • Page 15: 48" Model

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV 2 Align the TV stands with the screw holes on the bottom of your TV, then secure the stands to your TV with the four provided screws. Screw type Screw length # of screws 15 mm 48"...
  • Page 16 NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 2 Align the TV stands with the screw holes on the bottom of your TV, then secure the stands to your TV with the four provided screws. Screw type Screw length # of screws 15 mm www.insigniaproducts.com...

  • Page 17: Installing A Wall-Mount Bracket

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Installing a wall-mount bracket Warnings • Your TV has four VESA mounting holes on the back. If you attach a wall-mount bracket to the back of your TV, the bracket must be securely attached, using all four holes.
  • Page 18 NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 2 If the TV stand(s) are installed, remove the four screws that secure the stand(s) to your TV. 24" model 32" model 48" model www.insigniaproducts.com...
  • Page 19 24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV 3 Attach the wall-mount bracket to your TV using the mounting holes on the back of your TV. See the instructions that came with the wall-mount bracket for information about how to correctly hang your TV. Notes •...

  • Page 20: Tv Components

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 TV components Side jacks Note Your TV has built-in controls for adjusting basic Images do not necessarily represent the exact settings and several sets of jacks for connecting design of your television. devices to your TV. This section contains information about: 24"...
  • Page 21 24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV 48" model Item Description Connect an HDMI® device to this jack. For more information, see HDMI® (best) on pages 27, 35, or Connecting a computer page 43. 5 HDMI1 (ARC) Connect an ARC-enabled home theater receiver to this jack.

  • Page 22: Back Jacks

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 Back jacks # Item Description 24" or 32" model —Press to turn on your TV when your TV is off (in standby Note mode). Press and hold to turn off your TV when TV is on. Images do not necessarily represent the exact design of your television.
  • Page 23 24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV 48" model # Item Description —Press to turn on your TV when your TV is off (in standby mode). Press and hold to turn off your TV when TV is on. Warning: When your TV is off, power still flows through it.

  • Page 24: Remote Control

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 Remote control Button Description —Moves the highlight up one item. —Moves the highlight down one item. —Moves the highlight left, if possible (if a < hint appears). When watching TV, displays your channel list. When playing most streaming videos, skips backward in the video.
  • Page 25 24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Button Description Button Description When playing streaming video that supports this feature, or Turns volume up one setting with each press. Press and hold broadcast TV if Live TV Pause is enabled: to turn volume up rapidly.

  • Page 26: What Connection Should I Use

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 What connection should I Connection type and Cable connector use? jack Your TV has several connection types for connecting Digital optical devices to your TV. audio output For the best video quality, you should connect a device to the best available connection. Use the following tables to identify cables: Connection Video...

  • Page 27: Connecting A Cable Or Satellite Box

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Connecting a cable or satellite box Many cable or satellite TV boxes have more than one connection type. To get the best video, you should use the best connection type available. For more information, see What connection should I use? on page 26.

  • Page 28: 48"Model

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 48"model Note If your TV is the 24" or 32" model, go to 24" or 32" model on page 27. Side of TV On your TV Cable or satellite box HDMI® cable connector HDMI® cable HDMI® jack Cable wall jack 1 Make sure that your TV’s power cord is unplugged and all connected devices are turned off.

  • Page 29: Av (Good)

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV AV (good) Note Cables are often color-coded to match color-coded jacks. 24" or 32" model Note If your TV is the 48" model, go to 48" model on page 30. Note Images do not necessarily represent the exact design of your television. Side of TV Cable or On your TV...

  • Page 30: 48" Model

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 48" model Note If your TV is the 24" or 32" model, go to 24" or 32" model on page 29. On your TV Cable or satellite box AV cable AV cable Audio cable connector connectors AV jack Analog audio jacks Back of TV...

  • Page 31: Coaxial (Good)

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Coaxial (good) 24" or 32" model Note If your TV is the 48" model, go to 48" model on page 32. Note Images do not necessarily represent the exact design of your television. Cable or satellite box On your TV...

  • Page 32: 48" Model

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 48" model Note If your TV is the 24" or 32" model, go to 24" or 32" model on page 29. Side of TV On your TV Cable or satellite box Coaxial cable Coaxial cable connector ANT/CABLE IN jack Cable wall jack...

  • Page 33: Connecting An Antenna Or Cable Tv (No Box)

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Connecting an antenna or cable TV (no box) 24" or 32" model Note If your TV is the 48" model, go to 48" model on page 34. Note Images do not necessarily represent the exact design of your television. Antenna or cable TV (no On your TV...

  • Page 34: 48" Model

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 48" model Note If your TV is the 24" or 32" model, go to 24" or 32" model on page 33. Side of TV On your TV Antenna or cable TV (no box) Coaxial cable connector Coaxial cable ANT/CABLE IN jack 1 Make sure that your TV’s power cord is unplugged and all connected devices are turned off.

  • Page 35: Connecting A Dvd Or Blu-Ray Player

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Connecting a DVD or Blu-ray player Many DVD or Blu-ray players have more than one connection type. To get the best video, you should use the best connection type available. For more information, see What connection should I use? on page 26.

  • Page 36: 48" Model

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 48" model Note If your TV is the 24" or 32" model, go to 24" or 32" model on page 35. Side of TV On your TV DVD or Blu-ray player HDMI® cable connector HDMI® cable HDMI® jack 1 Make sure that your TV’s power cord is unplugged and the DVD or Blu-ray player is turned off.

  • Page 37: Av (Good)

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV AV (good) Note Cables are often color-coded to match color-coded jacks. 24" or 32" model Note If your TV is the 48" model, go to 48" model on page 38. Note Images do not necessarily represent the exact design of your television. Side of TV On your TV DVD or Blu-ray...

  • Page 38: 48" Model

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 48" model Note If your TV is the 24" or 32" model, go to 24" or 32" model on page 37. DVD or Blu-ray player On your TV AV cable AV cable Audio cable connector connectors Back of TV AV jack Analog audio jacks...

  • Page 39: Connecting A Game Console

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Connecting a game console Many game consoles have more than one connection type. To get the best video, you should use the best connection type available. For more information, see What connection should I use? on page 26.

  • Page 40: 48" Model

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 48" model Note If your TV is the 24" or 32" model, go to 24" or 32" model on page 39. Side of TV On your TV Game console HDMI® cable connector HDMI® cable HDMI® jack 1 Make sure that your TV’s power cord is unplugged and the game console is turned off. 2 Connect an HDMI®...

  • Page 41: Av (Good)

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV AV (good) Note Cables are often color-coded to match color-coded jacks. 24" or 32" model Note If your TV is the 48" model, go to 48" model on page 42. Note Images do not necessarily represent the exact design of your television. Side of TV On your TV Game...

  • Page 42: 48" Model

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 48" model Note If your TV is the 24" or 32" model, go to 24" or 32" model on page 41. Game console On your TV Console-specific AV cable AV cable Audio cable connector connectors Back of TV AV jack Analog audio jacks...

  • Page 43: Connecting A Computer

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Connecting a computer You can use an HDMI® jack on your TV to connect to a computer. 24" or 32" model Note If your TV is the 48" model, go to 48" model on page 44.

  • Page 44: 48" Model

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 48" model Note If your TV is the 24" or 32" model, go to 24" or 32" model on page 43. Side of TV On your TV Computer HDMI® cable connector HDMI® cable HDMI® jack 1 Make sure that your TV’s power cord is unplugged and the computer is turned off. 2 Connect an HDMI®...

  • Page 45: Connecting A Usb Flash Drive

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Connecting a USB flash drive You can use the USB 2.0 jack on your TV to view photos and videos and listen to music stored on a USB flash drive. 24" or 32" model Note If your TV is the 48"...

  • Page 46: 48" Model

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 48" model Note If your TV is the 24" or 32" model, go to 24" or 32" model on page 45. Side of TV USB flash drive 1 Plug a USB flash drive into the USB port on the side of your TV. Caution Do not remove the USB flash drive or turn off your TV while using the USB flash drive.

  • Page 47: Connecting Headphones

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Connecting headphones When you connect headphones, the TV speakers are muted and sound plays through the headphones. Warning Loud noise can damage your hearing. When using headphones, use the lowest volume setting on your headphones that still lets you hear the sound. 24"...

  • Page 48: 48" Model

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 48" model Note If your TV is the 24" or 32" model, go to 24" or 32" model on page 47. Side of TV • Connect the headphones to the jack on the side of your TV. www.insigniaproducts.com...

  • Page 49: Connecting External Speakers Or A Sound Bar

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Connecting external speakers or a sound bar When you connect external speakers or a sound bar, sound plays through your TV speakers and the external speakers or sound bar. You can connect external speakers or a sound bar using the: •...

  • Page 50: 48" Model

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 48" model Note If your TV is the 24" or 32" model, go to 24" or 32" model on page 49. Side of TV On your TV Digital speaker system Digital optical audio cable connector Digital optical audio cable Sound bar Digital optical audio jack...

  • Page 51: Arc Jack

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV ARC jack Your TV can send sound to an ARC device, like an AV receiver, to create a home theater that uses two or more speakers. When you connect external speakers or a sound bar, sound plays through your TV speakers and the external speakers or sound bar.

  • Page 52: 48" Model

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 48" model Note If your TV is the 24" or 32" model, go to 24" or 32" model on page 51. Side of TV On your TV ARC audio device HDMI® cable connector HDMI® cable Sound bar HDMI1 (ARC) jack 1 Make sure that your TV’s power cord is unplugged and the digital speaker system or sound bar is turned off.

  • Page 53: Connecting A Home Theater System With Multiple Devices

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Connecting a home theater system with multiple devices You can connect an AV receiver and your devices to create a home theater. Cable or satellite box DVD or Blu-ray player AV receiver Antenna or cable TV connected directly to the wall jack...

  • Page 54: Connecting Power

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 Connecting power You should connect devices before you connect the power cord. When you are adding devices, make sure that the power cable is unplugged from the power outlet. Note Images do not necessarily represent the exact design of your television. 24"...

  • Page 55: Installing Remote Control Batteries

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Installing remote control batteries Open the back of your TV remote control and insert two AAA batteries, observing the proper orientation. Reattach the back cover. Remote control on page explains how to use the remote control in each of your TV’s operating modes. Cautions •...

  • Page 56: Guided Setup

    2 The power-on screen appears and the status light blinks slowly for a few more seconds. The power-on screen displays the Insignia Roku TV logo while your TV starts up. 3 After a few seconds, Guided Setup starts:...

  • Page 57: Setting Up Your Tv

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Setting up your TV With the first Guided Setup screen on your TV, follow these steps to set it up: 1 Press the OK or RIGHT arrow on the remote control to go to the next screen: 2 Press OK to select Set up for home use.

  • Page 58: Other Options

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 Other options: • Connect to the Internet later —If you’re unable to connect to the Internet, that’s OK. You can skip this step and use your TV to watch broadcasts, play games, and watch DVDs. If you want to connect later, it's easy. We’ll show you how Benefits of connecting on page 64.
  • Page 59 TV software version, go to Settings > System > About after you complete Guided Setup. • You can download an updated User Guide that matches your TV software version from the Insignia web site at: www.insigniaproducts.com/support After your TV restarts, it displays the Activation screen: Note A paid subscription or other payments may be required for some channels.
  • Page 60 NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 8 Using a compatible computer, tablet, or smartphone with an Internet connection, go to the web address Why do I need a Roku Account? displayed on the screen and enter the code that appears You need a Roku Channel Store account for several on your screen.
  • Page 61 24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV 10 Connect all the devices you plan to use with your TV, turn them all on, and then select Everything is plugged in and turned on. Your TV now takes you step by step through each of its inputs and asks what kind of device you have connected.

  • Page 62: Connected Tv Home Screen

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 Connected TV Home screen Here is a typical Home screen from a TV that’s connected to the Internet and paired with a Roku account. Hint–Press Press Highlighted RIGHT to see options when item–Press OK to TV inputs Home menu another screen available select...

  • Page 63: Non-Connected Tv Home Screen

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Non-connected TV Home screen Here is a typical Home screen from a TV that is not connected to the Internet. Press Highlighted Hint–Press options when RIGHT to see item–Press OK to TV inputs Home menu available another screen...

  • Page 64: Benefits Of Connecting

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 Benefits of connecting Connecting brings out your TV's full potential! Make any night a movie night Thousands of movies to choose from, across all major streaming movie channels like Netflix, Cineplex Store, Crackle, and more. You’ll never run out of something new to watch. Note A paid subscription or other payments may be required for some channels.

  • Page 65: But What If I Didn't Connect My Tv

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV To play streaming content that is available on the Internet, you add streaming channels to your Home screen. To add a streaming channel to your Home screen, use the Streaming Channels option on the Home screen menu to go to the Roku Channel Store, and then select the streaming channel you want to add.

  • Page 66: How Do I Set Up The Tv Tuner

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 How do I set up the TV tuner? Setting up the TV tuner is easy—your TV does most of the work. You just have to answer a couple of questions. 1 Make sure your antenna (sold separately) or TV cable is connected to your TV’s ANT/CABLE input. 2 On the Home screen, select the Antenna TV tile.
  • Page 67 24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV 6 Wait while your TV scans for broadcast (antenna TV) stations... … and then cable TV channels. Cable TV channels are channels from a cable TV provider that you can receive by connecting their cable directly to your TV (unscrambled NTSC, ATSC, and QAM channels, if you’re the kind of person who is interested in the details).
  • Page 68 NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 8 If you connected your TV to the Internet, you have the option of setting up Live TV Pause. Pausing Live TV page explains how to set up and use this feature. If you don't want to set up Live TV Pause, or if this option is not available to you, select Done to start watching Live TV.

  • Page 69: Using Your Tv

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Using your TV This section provides information on using the day-to-day features of your TV. Status light Your TV has a single status light on the front panel. It goes on and off and blinks in different ways depending on the status of the TV, as shown in the following table: TV condition Status indicator...

  • Page 70: Viewing Program Information

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 Viewing program information To view information about the current program, press OK. Your TV displays a banner at the bottom of the screen with as much information as is available in the program data stream, as shown in the following example. Program information, subject to availability within the broadcast information, includes: •...

  • Page 71: Pausing Live Tv

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Pausing Live TV Using Live TV Pause, your Roku TV gives you the ability to pause, play, fast forward, and rewind digital broadcast TV. You can pause live TV for up to 90 minutes. Requirements To use this feature, you need to: 1 Connect your TV to the Internet.

  • Page 72: Notes About Live Tv Pause

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 Whenever you use any of the Live TV Pause features, the TV momentarily displays a progress bar: 90 minute Current Extent of Current time Time at current mark (max playback pause time playback pause time) position (up to 90 position minutes) The progress bar also displays tick marks at each half hour point, to help you locate the boundaries where one show...

  • Page 73: Playing Content From Usb Storage Devices

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Playing content from USB storage devices Your TV has a USB port that can be used to play personal music, video, and photo files from a personal USB flash drive or hard disk. If your TV is connected to the Internet, your Home screen has the Roku Media Player tile. If your TV has not been connected to the Internet, the Home screen has the USB Media Player tile.

  • Page 74: Settings Menu

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 Settings menu Use the Settings menu to adjust overall TV settings. Press to go to the Home screen, and then navigate to Settings > TV picture settings. You can adjust the following overall TV picture settings from the Settings screen: •...

  • Page 75: Options Menu

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Options menu The Options menu for each TV input provides settings for controlling the appearance of the picture and the quality of the audio. To view the Options menu, press whenever you are watching a TV input or streaming a video. The Options menu is a panel that appears over the left side of the screen: To adjust the settings on the Options menu, press the UP or DOWN arrow to highlight a setting, and then press the LEFT or RIGHT arrow to change the setting.

  • Page 76: Advanced Picture Settings

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 • Captioning track—(Canadian models only) Selects which caption track to display when Closed Captioning is on. (On U.S. models, you can find Captioning track under Accessibility.) This setting remains in effect on all inputs that provide captions. For more information, see Changing caption settings (Canadian models only) on page 87.

  • Page 77: Accessibility (U.s. Models Only)

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV • Contrast—Adjusts the white level of the light areas of the picture. • Sharpness—Adjusts the sharpness of the edges of objects in the picture. • Color—Adjusts the intensity of colors in the picture. A setting of 0 removes all color and displays a black and white picture.

  • Page 78: Changing Privacy Settings

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 • Streaming video channel—Turn captions on or off, set them to appear only when the TV sound is muted, or only during instant replay (for streaming content that supports instant replay). Note If the Instant Replay button is not available on your remote control, you can use on the Roku App or the Jump Back button on a universal remote.

  • Page 79: My Feed

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV My Feed Use My Feed to find out when you can watch movies coming soon, and to get updates on movies, TV shows, and actors that you are following. Movies Coming Soon My Feed gives you updates on your list of movies that are coming soon to theaters.

  • Page 80: Searching For Something To Watch

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 Searching for something to watch Searching for movies and shows across multiple streaming channels is one of the unique features of your TV. Within a single search operation, you can search by: • Movie name • TV show name •...

  • Page 81: Following On Roku

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Following on Roku Rather than watch the show you found in Search, you can add it to My Feed and wait until it’s available on a particular streaming channel or available at a better price. From the search results screen, select Follow on Roku. Then go to My Feed periodically to check for updates to each of your followed movies, TV shows, or people.

  • Page 82: Customizing Your Tv

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 Customizing your TV There are several things you can do to personalize your TV. Rearrange tiles Whenever you add a TV input tile, it’s added at the top of your Home screen. Whenever you add a new streaming channel from the Roku Channel Store, it’s added at the bottom of your Home screen.

  • Page 83: Edit Broadcast Tv Channel Lineup

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Edit broadcast TV channel lineup When you set up the TV tuner as described in Setting up Antenna TV on page 65, your TV adds all the channels with good signals that it could detect in your area. It’s likely that you now have more channels than you want in your channel list.

  • Page 84: Remove Unwanted Tiles

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 Remove unwanted tiles It’s easy to remove unused TV inputs and unwanted channel or app tiles. For example, if you never use the HDMI 3 input, or if you don’t like the weather app you added from the Roku Channel Store, you can remove them from your Home screen.

  • Page 85: Configure Power Settings

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Configure power settings Power settings let you set up your TV so that it turns on to the location you choose. Power settings also help your TV save energy by automatically turning it off under certain conditions. Power on settings Power on settings tell your TV what to do when you turn on the power.

  • Page 86: Configure Accessibility (U.s. Models Only)

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 Configure accessibility (U.S. models only) Accessibility settings enable users with vision or hearing impairment to use the TV more effectively. Accessibility settings are located under Settings > Accessibility. (On models sold in Canada, you can find the Captions mode and Captions style options under Settings >...

  • Page 87: Audio Guide Settings

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Audio Guide settings The Audio Guide settings help users who are blind or visually impaired to configure the text-to-speech reader, enabling them to operate their TV more easily. The Audio Guide uses voice prompts that speak volume and channel changes, menu options, and setting changes.

  • Page 88: Configure Parental Controls

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 Configure parental controls Parental controls enable you to control whether the members of your household can view certain kinds of broadcast TV programs. When a program or feature is blocked, you can unblock it by entering a parental control PIN that only you know.
  • Page 89 24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV 2 In the Parental controls screen, navigate to TV tuner > Parental control of TV shows. 3 Make sure the check box next to Enable parental controls is checked. If not, highlight it and press OK. Blocking based on U.S.
  • Page 90 NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 New Region Rating Tables can have independent rating levels, or rating levels that interact in the same ways as the built-in U.S. TV and MPAA Movie ratings. If your TV downloads a new Region Rating Table, you’ll have to experiment with its settings to understand how to use it.

  • Page 91: What Happens When A Tv Show Is Blocked

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV What happens when a TV show is blocked? After you've set up parental controls, TV shows and movies can be blocked: • When you change channels and the new channel is playing a program whose rating exceeds your settings. •...

  • Page 92: More Settings

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 3 Follow the instructions on the screen to confirm that you want to erase all parental control settings. Resetting parental controls also erases your parental control PIN. More settings This section describes the features and settings of your TV that were not covered in the other parts of this guide. Changing network settings If needed, you can change your network settings at any time.

  • Page 93: Changing Time Settings

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Changing time settings You can change time settings to suit your preferences. You can find the following settings by navigating from the Home screen menu to Settings > System > Time: • Sleep timer—Set a time delay after which your TV will automatically shut off. This setting reflects the setting you can make in the Options menu from any TV input, as explained in Options menu settings on page 75.

  • Page 94: Setting Up A Digital Audio Connection

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 Setting up a digital audio connection You can connect your TV to an external amplifier, receiver, or soundbar by using either of these two connections: • HDMI1 (ARC)—The HDMI® Audio Return Channel enables your TV to output digital audio on one of its HDMI® connectors.

  • Page 95: Restarting Your Tv

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Enabling system audio control System audio control enables your TV remote control to change the volume and mute state of an amplifier or soundbar connected through HDMI®, and to display the external device's volume and mute status in your TV’s on-screen display. Your TV automatically turns off its internal speakers and sends volume and mute control signals to an external amplifier when all of the following are true: •...

  • Page 96: What If I Can't Access The Factory Reset Option

    If your TV is not connected to the Internet, you can still get updates by using a USB flash drive. You can download an updated User Guide that matches your Roku TV software version from the Insignia web site at: www.insigniaproducts.com/support...

  • Page 97: Getting Updates On A Non-Connected Tv

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Getting updates on a non-connected TV If your TV is not connected to the Internet, you can still get system updates by using a USB flash drive and a computer with an Internet connection. To get a system update, navigate to Settings >...

  • Page 98: Other Devices

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 Other devices Getting and using the Roku mobile app Roku makes the Roku mobile app free for compatible iOS, Android, and Microsoft Windows mobile devices. The Roku mobile app is an alternative remote control for your Roku TV The Roku mobile app also lets you find and add new Roku Channels, more easily search and find something to watch, and even use your voice to search without typing.

  • Page 99: Troubleshooting

    For the latest answers to Frequently Asked Questions, visit General Support & FAQs under the Support and Service section of the Insignia TV support website (www.insigniaproducts.com) and the Support section of the Roku website (www.roku.com). Video and audio...
  • Page 100 NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 Symptom Possible cause Try this... • Try another channel. The station may be experiencing Broadcast TV may be problems. experiencing problems • If you are using an antenna and the signal strength is low, or may not be set up adjust the antenna or use a highly directional outdoor antenna or set-top antenna with a built-in amplifier.
  • Page 101 24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Symptom Possible cause Try this... • Make sure that the antenna or cable TV is connected correctly and securely. See Connecting a cable or satellite box page Connecting an antenna or cable TV (no box) Cables may not be page 33.

  • Page 102: Remote Control

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 Symptom Possible cause Try this... Light in the viewing area • Make sure that the room is not too bright. Light reflecting off may be interfering the screen can make the picture difficult to see. Poor picture A connected camera or •...

  • Page 103: General

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV General Symptom Possible cause Try this... • Make sure that the power cord is correctly connected to both your TV power connector and power outlet. See Connecting power on page 54. You should see an LED in the front of your Power cord may not be TV panel when a button on the remote is pressed.

  • Page 104: Roku

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 Symptom Possible cause Try this... • Make sure that the sleep timer is not turned on. See the Sleep TV keeps Sleep time may be Timer option in Options menu settings on page turning off turned on Changing time settings on page 93.

  • Page 105: Cec-Compatible Devices

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV CEC-compatible devices Symptom Possible cause Try this... • Make sure that the HDMI® cable is connected securely to your Cables may not be TV and the device. connected correctly • Make sure that the device is connected to your TV with an HDMI®...
  • Page 106 NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 Symptom Possible cause Try this... Connected device may • Make sure that the device is turned on. not be turned on • Make sure that no objects (or pets) are obstructing the line-of-sight from the remote control to the remote sensor on Line-of-sight obstructed the front of your TV and the device.

  • Page 107: Specifications

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Specifications Outputs Video Specifications are subject to change without notice. Headphone 1 (back) Digital audio 1 (optical) (side) 24" model WiFi Dimensions and weight Ethernet 13.4 × 22 × 2.1 in. (33.9 × 55.8 × 5.3 cm) Audio Without stand (H ×...

  • Page 108: 32" Model

    NS-24ER310NA17/NS-24ER310CA17 NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17 32" model Outputs Video Dimensions and weight Headphone 1 (back) 17.3 × 28.9 × 3.7 in. (43.9 × 73.4 × 9.3 cm) Digital audio 1 (optical) (side) Without stand (H × W × D) 9.5 lbs (4.3 kg) WiFi With stand (H ×...

  • Page 109: 48" Model

    24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV 48" model Outputs Video Dimensions and weight Headphone 1 (side) 25.4 × 43 × 3.4 in. (64.5 × 109.3 × 8.7 cm) Digital audio 1 (optical) (side) Without stand (H × W × D) 21.2 lbs (9.6 kg) WiFi With stand (H ×...

  • Page 110: Legal Notices

    After your Roku Account is created, you can link your Insignia Roku INSIGNIA ROKU TV FOR THE FIRST TIME. TV to your account. By using the Insignia Roku TV, you agree to the Overview following disclaimer. For the avoidance of doubt, the content disclaimer set forth herein shall refer to all content and channels This End User License Agreement (“EULA”) between you and Roku,...
  • Page 111 24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV Changes to This EULA Software Updates Roku may amend this EULA at any time in its discretion. Such in its sole discretion, ROKU MAY PROVIDE UPDATES TO YOUR amendments shall be effective immediately upon posting of the TELEVISION VIA the internet, including BUG FIXES AND amended EULA on Roku's website or via the Television or your Roku UPDATES,CHANGES IN THE USER INTERFACE OR HOW YOU ACCESS...
  • Page 112 800-778-7879. For If You desire to contact Insignia, please send your correspondence Claims between You and Roku of $75,000 or less, you will by mail to be responsible for the initial arbitration filing fee, up to the...
  • Page 113 24"/32" 720p, 48" 1080p, 60Hz, LED Roku TV FCC Statement Dolby License Notice and Trademark Acknowledgement Note: This equipment has been tested and found to comply with Manufactured under license from Dolby the limits for a class B digital Device, pursuant to part 15 of the FCC Laboratories.

  • Page 114: One-Year Limited Warranty - Insignia Televisions

    Insignia repair center or store personnel, LOST PROFITS. INSIGNIA PRODUCTS MAKES NO OTHER EXPRESS Insignia will (at its sole option): (1) repair the Product with new or WARRANTIES WITH RESPECT TO THE PRODUCT, ALL EXPRESS AND rebuilt parts;...
  • Page 115 For product inquiries or accessibility assistance, please contact us with the information below: 1-877-467-4289 www.insigniaproducts.com INSIGNIA is a trademark of Best Buy and its affiliated companies. Distributed by Best Buy Purchasing, LLC 7601 Penn Ave South, Richfield, MN 55423 U.S.A.

Table of Contents

Save PDF
