Model: RCCP80V
IMPORTANT: Read and understand this manual before assembling, starting, or servicing
heater. Improper use of heater can cause serious injury. Keep this manual for future reference.
GENERAL HAZARD WARNING: FAILURE TO COMPLY WITH THE PRECAUTIONS AND
INSTRUCTIONS PROVIDED WITH THIS HEATER, CAN RESULT IN DEATH, SERIOUS BODILY
INJURY AND PROPERTY LOSS OR DAMAGE FROM HAZARDS OF FIRE, EXPLOSION, BURN,
ASPHYXIATION, CARBON MONOXIDE POISONING, AND/OR ELECTRICAL SHOCK.
ONLY PERSONS WHO CAN UNDERSTAND AND FOLLOW THE INSTRUCTIONS SHOULD USE
OR SERVICE THIS HEATER.
IF YOU NEED ASSISTANCE OR HEATER INFORMATION SUCH AS AN INSTRUCTIONS
MANUAL, LABELS, ETC. CONTACT THE MANUFACTURER.
TABLE OF CONTENTS
SAFETY INFORMATION ............................................................ 2
PRODUCT IDENTIFICATION ..................................................... 3
UNPACKING ............................................................................... 3
THEORY OF OPERATION ......................................................... 3
PROPANE SUPPLY .................................................................... 3
VENTILATION ............................................................................. 3
INSTALLATION ........................................................................... 4
OPERATION ............................................................................... 4
Save this manual for future reference.
Save this manual for future reference.
CANADIAN PROPANE
CONSTRUCTION HEATER
OWNER'S MANUAL
TM
STORAGE ................................................................................... 5
MAINTENANCE .......................................................................... 6
SPECIFICATIONS ...................................................................... 6
REPLACEMENT PARTS ............................................................ 6
TROUBLESHOOTING ................................................................ 7
ACCESSORIES .......................................................................... 7
ILLUSTRATED PARTS BREAKDOWN AND PARTS LIST ......... 8
WARRANTY AND REPAIR SERVICE ........................ Back Cover
VARIABLE
40,000 - 80,000 BTU/HR
