- Page 1 Secure Local Access Document ID: sv_secure_local_access_en_v18_04 https://sevio.it...
- Page 2 Other product names and brands are registered brands or trademarks of their respective owners. Declaration of terms In the interest of improving internal design and operational aspects, Sevio S.r.l. reserves the right to make changes to the products described herein without any prior warning.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Firewall and Secure Local Access ....................... 4 Configuration ............................5 Sevio Portal ........................... 5 Local Control Stations configuration ..................... 7 Windows 10 ® ..........................8 Enable Internet connectivity on the Local Control Station ............9 Connecting to the private network....................10 Disconnecting from the private network .................. -
Page 4: Firewall And Secure Local Access
INTERNET Sevio Basic Sevio One The internal firewall, who grant the network isolation, is a fundamental feature on which Sevio Router is based on. The internal Firewall of Sevio Router provides many advantages: no IP address conflicts, no need to change the existing automation network configuration;... -
Page 5: Configuration
VPN Client Protocol. Sevio Portal Sevio Portal, the web application for the Sevio system, can be used to configure and view the status of the devices that are part of the Realm, for more detailed information please refer to the User Guide. - Page 6 The range can change from 1 Local Control Station (E.g. from x.x.x.250 to x.x.x.250) to a maximum of 4 Local Control Station (E.g. from x.x.x.250 to x.x.x.253). 2. The first three octects in range fields must coincide with the Sevio network, 10.255.254.x in the example.
-
Page 7: Local Control Stations Configuration
Using the procedure described below, it is possible to enable the Local Control Stations to access on LAN (automation network). It will only be configured one time for each Local Control Station. Before starting to configure, verify that the Local Control Stations and Sevio Router are connect to the same WAN, without interposed hub or router. -
Page 8: Windows 10
Change virtual private network. Click on Add a VPN connection. Select a built-in VPN provider, assign a connection name (E.g. Sevio Local). In Server name field type Sevio Router address (E.g. 192.168.1.50). Select VPN type L2TP/IPsec with pre-shared key then as pre-shared key type sevio. -
Page 9: Enable Internet Connectivity On The Local Control Station
2. Select Change adapter options. 3. Select the Local VPN then with a right 4. Select Network, Internet Protocol mouse button select Properties. version 4 and Properties. 5. Press Advanced. 6. Deselect flag Use default gateway on remote network. Document ID: sv_secure_local_access_en_v18_04 https://sevio.it... -
Page 10: Connecting To The Private Network
Connecting to the private network Select VPN and Connect. Disconnecting from the private network Click on the Sevio Local network (or the name set during setup of the private network) using Network icon application bar and select Disconnect. Document ID: sv_secure_local_access_en_v18_04... -
Page 11: Windows 7
Set up a virtual private network (VPN) connection. Set in Internet address field The Sevio Router WAN IP address (E.g. 192.168.1.50) assign connection name (E.g. Sevio Local). Flag on Don’t connect now, just set it up so I can connect later. - Page 12 Click on Network icon in application bar, select the Sevio Local network with the right mouse button and select Properties. Select Security menu L2TP/IPSec then Advanced settings. preshared authentication and type sevio, then click OK. Document ID: sv_secure_local_access_en_v18_04 https://sevio.it...
-
Page 13: Enable Internet Connectivity On The Local Control Station
During a VPN connection, Windows OS sends all traffic to VPN and inhibits Internet connectivity. 1. Select Network, Internet Protocol 2. Press Advanced. version 4 and Properties. 3. Deselect flag Use default gateway on remote network Document ID: sv_secure_local_access_en_v18_04 https://sevio.it... -
Page 14: Connecting To The Private Network
Connecting to the private network Click on Sevio Local network (or the name set during setup of the private network) using Network icon in the application bar and select Connect. Disconnecting from the private network Click on Sevio Local network (or the...
