Honeywell HD4CH Brochure & Specs

HD4CH
VANDAL DOME CAMERA
Honeywell's HD4CH is a vandal resistant fixed dome camera that is perfect for
indoor and outdoor applications. Loaded with high performance features, the
HD4CH integrates a camera and lens into a single, vandal resistant, compact unit
that is a snap to install. The rugged scratch-resistant 3.5 mm thick polycarbonate
construction can withstand heavy external impacts. In addition, the housing
incorporates a new breather vent that prevents any condensation from forming
inside the housing. This innovative camera, with waterproof properties, meets IP66
standards for critical outdoor installations. It comes completely assembled and is
designed to mount directly to a ceiling, wall, or to a 4S (using the supplied adapter
plate), single, or double electrical box. The unit also comes with a pan/tilt/rotation
mechanism and a second video service cable for simple camera adjustments.
This latest addition to Honeywell's 4" mini-dome series responds to the need for a
completely integrated, high resolution camera with the widest lens configuration on
the market today. The HD4CH incorporates a 1/3" CCD that offers 540 TV lines of
crisp, clear horizontal resolution and a built-in 2.8-10 mm (F1.3) Vari-focal Auto Iris
lens to cover a wide range of viewing angles. The HD4CH accepts both 12 VDC
and 24 VAC (auto-sensing). Installing this dome lets you meet all of your application
requirements with one high-performing, competitively-priced camera.
Market Opportunities
The HD4CH is the ideal solution for a wide range of surveillance applications. The
compact, one-piece design allows for fast, easy installation in commercial,
government, school, professional, and any other quality-sensitive, high-risk
environment such as prisons, airports and train stations.
Features
• 1/3" Sony HAD CCD™
• High resolution color: 540 TVL
• Vandal resistant aluminum alloy
housing with polycarbonate dome
• Built-in breather vent for use in various
weather conditions
• Single model instantly converts to
flush or surface mount
• Local video output for setup
• 3-D axis gimbal
• One power connection self-configures
to either 12 VDC or 24 VAC. AC line
lock standard with all cameras in
24 VAC operation
• Pendant and wall mount kits available
www.honeywellvideo.com
HD4CH shown with mount
ring for surface mount
HD4CH shown without
mount ring for flush mount
