Chassis name
TPM18.7E LA
Published by Amy/SC 1811 Quality
2018
TP Vision Netherlands B.V.
©
All rights reserved. Specifications are subject to change without notice. Trademarks are the
property of Koninklijke Philips Electronics N.V. or their respective owners.
TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust
earlier supplies accordingly.
PHILIPS and the PHILIPS' Shield Emblem are used under license from Koninklijke Philips Electronics N.V.
Platform
MTK5800
Subject to modification
TPM18.7E
Model name
32PFS5803/12
32PFS5823/12
43PFS5803/12
43PFS5823/12
50PFS5803/12
3122 785 20690
2018-Mar-16
Advertisement
Table of Contents
Related Manuals for Philips 43PFS5823/12
Summarization of Contents
Product Information
Display Resolution
Details screen size and supported display resolutions.
Reception
Specifies aerial input, tuner bands, and digital/analogue video playback.
HDMI Input
Lists supported input resolutions for HDMI connections.
Component and Composite Video Inputs
Details supported resolutions for component and composite video signals.
Computer Input Resolutions
Lists supported resolutions for computer/VGA connections.
Sound Specifications
Outlines sound features like dynamic surround and output power.
Multimedia Connections
Lists available multimedia connectivity options like USB and Wi-Fi.
Supported USB File Systems
Specifies the file systems compatible with the TV's USB port.
Precautions, Notes, and Abbreviation List
Safety Instructions
Outlines essential safety regulations and precautions for performing repairs.
Warnings
Highlights critical warnings regarding electrostatic discharge (ESD) and high voltage.
General Notes
Provides general guidelines for measurements, waveforms, and voltage checks.
Schematic Notes
Explains conventions used in schematic diagrams, like resistor and capacitor values.
Spare Parts Information
Directs users to the Philips Spare Parts Web Portal for component information.
BGA IC Handling
Introduces BGA ICs and provides a URL for handling information.
BGA Temperature Profiles
Mentions the necessity of correct temperature profiles for BGA-ICs.
Lead-free Soldering
Details rules and tools for working with lead-free soldering technology.
Alternative BOM Identification
Explains how to identify different Bill of Materials (BOM) versions using the serial number.
Board Level Repair (BLR) / Component Level Repair (CLR)
Guides on deciding between board replacement and component-level repair.
Practical Service Precautions
Offers advice on avoiding electrical shock and handling components safely.
Abbreviation List
Provides a comprehensive list of technical abbreviations used in the manual.
Mechanical Instructions
Cable Dressing
Illustrates cable routing for 32" 5803/5823 series models.
Assembly and Panel Removal
Details procedures for disassembling the TV, including stand and IR board removal.
Rear Cover Removal
Describes the steps for safely removing the TV's rear cover.
Keyboard Control Unit Removal
Explains how to remove the keyboard control panel and its connectors.
Small Signal Board (SSB) Removal
Guides on detaching and removing the Small Signal Board (SSB) and its LVDS connector.
Power Supply Unit (PSU) Removal
Details the process for unplugging and removing the Power Supply Unit (PSU).
Speaker Removal
Outlines the steps for disconnecting and removing the TV speakers.
WIFI Module Removal
Explains how to disconnect and remove the WIFI module.
LCD Panel Removal
Provides instructions for removing the LCD Panel, including associated clamps and parts.
Service Modes
Overview of Service Modes
Introduces Service Alignment Mode (SAM), Factory Mode, and Customer Service Mode (CSM).
Service Alignment Mode (SAM) Details
Explains the purpose, specifications, activation, and navigation of SAM.
Factory Mode Details
Covers the purpose, specifications, activation, and exit procedures for Factory Mode.
Customer Service Mode (CSM) Details
Describes the purpose, specifications, activation, and exit procedures for CSM.
Software Upgrading, Error Codes, and Panel Codes
Software Upgrading Procedure
Details the steps for preparing and performing a firmware (F/W) upgrade via USB.
Checking Software Version
Instructions on how to verify the current software version using CSM after an upgrade.
Error Code System
Explains the purpose and types of error codes used to indicate TV set failures.
Reading the Error Buffer
Describes methods for reading the error buffer via screen or blinking LED.
Error Codes Overview
Provides an overview of 'layer 2' error codes related to SSB issues triggered by LED blinking.
Panel Code Reset
Details the procedure for resetting the panel code using a specific RC transmitter sequence.
Electrical Diagrams
Block Diagram
Provides a high-level overview of the TV's internal component connections and data flow.
Power Supply Architecture
Illustrates the power distribution and architecture of the platform.
Power Tree Diagram
Shows the detailed power distribution paths and voltage rails within the TV.
SSB Power Layout
Details the power distribution points and voltage labels on the Small Signal Board (SSB).
IC Data Sheets
MT5800VHEJ (Scaler) IC Details
Presents the block diagram and pin functions for the MT5800VHEJ scaler IC.
AD87072-LG48NRY (Audio) IC Details
Provides the block diagram and pin configuration for the AD87072 audio IC.
SI2169-D60-GMR (Demodulator) IC Details
Shows the block diagram and pinout for the SI2169D demodulator IC.
TDSY-G430D--EUROPE (Tuner) IC Details
Details the TDSY-G430D tuner IC, including its block diagram and pin description.
TDQS-A751F--EUROPE (Tuner) IC Details
Provides pin descriptions and a block diagram for the TDQS-A751F tuner IC.
Circuit Diagrams
715G7734 PSU Circuit Diagrams
Includes AC input and LED driver schematics for the 32" PSU.
715G8962 PSU Circuit Diagrams
Covers AC input, PFC, Main Power, and LED driver schematics for the 43"/50" PSU.
SSB System Power Diagrams
Details system power circuits including 12V to 5V_STB and 12V to Core Power converters.
SSB Peripheral Circuits
Illustrates peripheral circuits like EMMC, UART, and strapping configurations.
SSB Audio Interface Circuits
Shows schematics for audio interfaces, headphone output, and optical SPDIF output.
SSB Video Interface Circuits
Details video interface connections including YPbPr, CVBS, and analog power circuits.
SSB LVDS Interface Circuits
Provides schematics for LVDS signal transmission and associated analog power.
SSB DRAM Circuits
Shows DRAM connections, termination networks, and power capacitors for memory modules.
CI Card Interface Circuits
Details the CI slot connections, power control, and bus interface for CI cards.
SSB MII/GPIO/ServAD2 Circuits
Illustrates MII, GPIO, and other interface signals connected to the main processor.
HDMI Interface Circuits
Covers HDMI input/output connections, CEC, MHL sensing, and ARC functionality.
Tuner and Demodulator Circuits
Shows schematics for T2 and S2 tuners, demodulators, and their I2C interfaces.
USB, WIFI, and RJ45 Interface Circuits
Details USB ports, Wi-Fi power control, and Ethernet (RJ45) connections.
IR and Keypad Connector Circuits
Illustrates the circuit for the IR receiver, keypad connector, and LED drivers.
VCCK & DVSS Power Distribution
Details VCCK and DVSS power connections and bottom-side capacitor placements.
IR/LED Panel
IR Receiver and Light Sensor Circuits
Shows the circuit for the IR receiver, light sensor, and standby LED.
Keyboard Control Panel
Joystick and Keypad Circuit
Details the joystick mechanism, key functions, resistance values, and circuit diagram.
Styling Sheets
32" Series Styling and Parts
Provides an exploded view and parts list for the 32" 5803/5823 series TV.
43"/50" Series Styling and Parts
Offers an exploded view and parts list for the 43" 5803/5823 and 50" 5803 series TVs.
