Panasonic AJD230 - DVC PRO Service Manual

Sec. 1 Maintenance
Sec. 2 Mechanical Adjustment
Sec. 3 Major Mechanism Parts Replacement
and Adjustment Procedures
This material is mentioned about procedures of Mechanical Adjustment and Replacement for DVCPRO
product. Please refer to below indicated table, which models apply to this material.
TYPE
A
B 25M Camera Recorder
C 25M Lap-top & Portable
D 25M 4X Transmitter
E
F 50M Camera Recorder
G
Category
25M Studio VTR
50M Studio VTR
50M Portable
DVCPRO MECHANISM
AJ-D440, AJ-D450, AJ-D640, AJ-D650, AJ-D750, AJ-D850
AJ-D200, AJ-D210, AJ-D215, AJ-D400, AJ-D610, AJ-D700,
AJ-D700A, AJ-D800, AJ-D800A, AJ-D810, AJ-D810A
AJ-D220, AJ-D230, AJ-D230H, AJ-D250, AJ-LT75, AJ-LT85
AJ-DE77, AJ-D780
AJ-D940, AJ-D950, AJ-D950A
AJ-D90, AJ-D900W, AJ-D900WA, AJ-D910WA, AJ-PD900W,
AJ-PD900WA
AJ-D92, AJ-D94, AJ-D95DC
© 2000 Matsushita Electric Industrial Co., Ltd. All rights reserved.
Unauthorized copying and distribution is a violation of law.
ORDER NO. VSD9912M914
D20/D25
Models
2nd Issue
