Summarization of Contents
Installation Procedure
Phase 1: Securing the Tap
Tighten the fastening rod on the tap, position it on the sink, and secure with the fastening nut.
Phase 2: Connecting Hoses
Connect the rigid pipe to the tap and the shower hose to the mixed water connection.
Phase 3: Water Mains Connection
Connect hot and cold water hoses to mains, preventing leaks or unscrewing.
Maintenance and Cleaning
Cartridge Replacement
Unscrew the fastening screw and remove the handle. Unscrew the fastening ring nut.
Filter Cleaning
Unscrew the aeration filter and wash it. Repeat cleaning after first use.
Spare Parts
Spare Parts for Model 64200
List of spare parts for model 64200 with item numbers.
Spare Parts for Model 64203
List of spare parts for model 64203 with item numbers.
Flow Rates
Flow Rate for Model 64200
Graph showing flow rate (l/min) versus water pressure (bar) for model 64200.
Flow Rate for Model 64203
Graph showing flow rate (l/min) versus water pressure (bar) for model 64203.
Product Disposal and Recycling
Packaging Disposal
Dispose of packaging materials responsibly and deliver them to the nearest waste separation collection centers.
Product Disposal
Ensure intelligent recovery of valuable materials for recycling.
