Summary of Contents for Volantex 792-5
-
Page 2: Safety Precautions And Warnings
WARNING The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product: NOTICE: Procedures, which if not be properly followed, will create a possibility of physical property damage AND or possibility of injury. WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before operating. -
Page 4: Getting Started
Boat Batteries Installation open Unlock Lock 1. Rotate the hatch of the hull cover by clockwise to unlock the hatch. 2. Open the hull cover. 3. Adhere included loop tape or velcro tape to the battery. 4. Secure the boat battery on the hook strip in the boat. 5. -
Page 5: Motor Care
WARNING: DO NOT TURN OFF THE TRANSMITTER BEFORE UNCONNECTING BATTERY OF RECEIVER, OR THE RECEIVER MAY PICK UP STRAY SIGNALS AND RUN OUT OF CONTROL TO CAUSE ACCIDENT! NOTICE: Always store the boat with hatch removed to prevent mold and mildew growth inside the hull. Test Your Boat in Water 1. -
Page 6: Maintenance
Maintenance Always replace the shaft when it is damaged or shows visible wear or injury and property damage may result. Lubricating the shaft is vital to the life of the drivetrain. The lubricant also acts as a water seal, keeping water from entering the hull through the stuffing box. -
Page 7: Check List
Check List Before Boating - Install fully charged batteries in your boat and transmitter. - Connect the boat battery to ESC. - Make sure the boat is bound to the transmitter(otherwise, bind the boat to the transmitter using the included binding instructions.) - Make sure all linkages move freely on the boat. - Page 8 Power Adaptor Balance Charger Lithium Battery For balance charger & power adaptor set - 1. Plug the included balance charger to the power adaptor, then plug the power adaptor into a compatible AC outlet(depends on different contries and area) , then connect the power output lead to the receptacle on the side of the balance charger The power adapter and balance charger are powered on when the green color LED indicator is glowing.
-
Page 9: Troubleshooting Guide
Troubleshooting Guide Problem Possible Cause Solution Boat does not respond Throttle servo travel is lower than Make sure throttle servo travel is 100% or to throttle but responds 100% greater to other controls Throttle channel is reversed Reverse throttle channel on transmitter Damaged propeller, shaft or motor Replace damaged parts Extra noise or extra... - Page 10 Problem Possible Cause Solution Move powered transmitter a few feet from Transmitter is too near boat during boat, disconnect and reconnect battery to linking process boat Boat or transmitter is too close to large Move boat or transmitter away from large metal object metal object Rebind transmitter to boat and remove bind...
- Page 11 11 / 12...
