Kyocera LYNCOM PV12T Datasheet

Ly n c o m 's micro p rocessor based charge controllers incorporate state-of-the-art design and
advanced pulse-width-modulation (PWM) battery charging operation, offering the highest
quality and more feature s than comparably priced PV contro l l e r s .
Model PV12T is an advanced PV lighting system
c o n t roller for 12 volt solar systems rated 12
amps or less, designed for applications such
as sign lights, security or flood lights,
c a m p g round & re c reation facilities,
remote homes and marinas.
Field proven PWM design for battery charg i n g ,
reduces water loss, extends battery life, and
allows more daily amp-hours into the battery
as compared to traditional "on-off" contro l l e r s .
Model PV12T features an automatic load timer,
which senses dusk by the solar array and initiates the lighting time period, which is f i e l d
adjustable. When the timer circuit is '0' (defeated), PV12T can also be used as a continuous
load controller with LV D .
The Model PV12T lighting timer operation can be pre-set from 0 to 10 hours continuously
adjustable or from dusk to dawn. A low battery voltage load disconnect circuit (LVD)
p revents battery over- d i s c h a rge during extended overcast periods.
The PV12T has three system status LED's: system charging, battery full and battery low.
The reverse polarity protection circuit features a reverse polarity red LED for PV or battery,
ensuring proper hook up.
S t a n d a rd Feature s
•
Advanced solid state design
•
O n - b o a rd micro p rocessor to control voltage settings and parameters accurately
•
Pulse-width-modulation charge algorithm to extend battery life compared to
conventional "on-off" type contro l l e r s
•
Te m p e r a t u re compensation circuit to automatically adjust the optimum battery re g u l a t i o n
voltage and LVD voltage for a range of -30°C to +80°C
•
Lightning transient pro t e c t i o n
•
PV and battery reverse polarity pro t e c t i o n
•
O v e r-voltage pro t e c t i o n
•
O v e r- t e m p e r a t u re pro t e c t i o n
•
Selection of battery type between flooded and sealed
•
Automatic battery equalization for flooded battery
•
Parallel capability
•
5 year limited warr a n t y
R a t i n g s
•
B a t t e ry Voltage:
•
Maximum PV current:
•
Maximum Load current:
•
Self-Consumption:
LYNCOM MODEL PV12T
PV SYSTEM LIGHTING
C O N T R O L L E R
12 Vo l t s
12.0 Amps
12.0 Amps
13.0 mA
