  • Page 2 WSAN-YMi 91-141 WSAN-YMi 91-141 Quick guide Cascade unit Domestic Hot Water Master unit Slave unit MENU MENU FOR SERVICEMAN FOR SERVICEMAN CASCADE SET DHW MODE SETTING Solar panels Boiler HEATING mode HEATING + DHW mode Solar IN MENU MENU FOR SERVICEMAN...
  • Page 3 WSAN-YMi 91-141 Quick guide Running signal Thermostat Running Defrosting signal Defrost MENU FOR SERVICEMAN ROOM THERMOSTAT = YES MODE SETTING = YES 2-zone system - mixed 2-zone system - not mixed...
  • Page 4 Yours faithfully. CLIVET Spa The data contained in this manual is not binding and may be changed by the manufacturer without prior notice. Reproduction, even is part, is FORBIDDEN © Copyright - CLIVET S.p.A. - Feltre (BL) - Italia...

  • Page 5: Table Of Contents

    CONTENTS Product line-up Saftey considerations General information Installation Water connections Electrical connections Start-up and configuration Service information Maintenance Trouble shooting Controller user manual Controller navigation menu Cascade function Modbus General technical data Dimensional drawings...

  • Page 6: Product Line-Up

    Product line-up Size Nominal kW Power supply 400TN 3-phase 400TN 3-phase 400TN 3-phase 400TN 3-phase...
  • Page 7 The precautions listed here are divided into the following types.They are quite important, so be sure to follow them carefully. Meanings of DANGER, WARNING, CAUTION and NOTE symbols. DANGER Indicates an imminently hazardous situation which if not avoided, will result in death or serious injury. WARNING Indicates a potentially hazardous situation which if not avoided, could result in death or serious injury.
  • Page 8 DANGER Before touching electric terminal parts, turn off power switch. When service panels are removed, live parts can be easily touched by accident. Never leave the unit unattended during installation or servicing when the service panel is removed. Do not touch water pipes during and immediately after operation as the pipes may be hot and could burn your hands. To avoid injury, give the piping time to return to normal temperature or be sure to wear protective gloves.
  • Page 9 CAUTION  Ground the unit.  Grounding resistance should be according to local laws and regulations.  Do not connect the ground wire to gas or water pipes, lightning conductors or telephone ground wires.  Incomplete grounding may cause electric shocks. ...
  • Page 10  Confirm the safety of the installation area ( walls, floors, etc. ) without hidden dangers such as water, electricity, and gas.Before wiring/pipes.  Before installation , check whether the user's power supply meets the electrical installation requirements of unit ( including reliable grounding , leakage , and wire diameter electrical load, etc.
  • Page 11 These units are used for both heating and cooling applications. They can be combined with fan coil units, floor heating applications, low temperature high efficiency radiators, domestic hot water tanks (not supplied) and solar kits (not supplied). A wired controller is supplied with the unit . The unit have a freeze prevention function that uses the heat pump and backup heater (option) to keep the water system safe from freezing in all conditions.
  • Page 12 Not supplied. A domestic hot water tank(with or without booster heater) can be connected to the unit. See table for specific tank. If the tank volume is greater than 240L, the temperature probe (T5) should be installed at a position higher than half of the tank’s height.
  • Page 13 Name Quantity Adaptor Y-shape filter Water outlet connection pipe assembly Wired controller Tighten belt for customer wiring use Thermistor for domestic hot water tank (T5) * Extension wire for T5 Network termination resistor Name Quantity Thermistor for balance tank (Tbt1)* Thermistor for Zone 2 flow temp.
  • Page 14 Be sure to confirm the model name and the serial number of the unit. Due to relatively large dimensions and heavy weight, the unit should only be handled using lifting tools with slings. The slings can be fitted into foreseen sleeves at the base frame that are made specifically for this purpose. CAUTION To avoid injury, do not touch the air inlet or aluminum fins of the unit.
  • Page 15 CAUTION There is flammable refrigerant in the unit and it should be installed in a well-ventilated site. If the unit is installed inside, an additional refrigerant detection device and ventilation equipment must be added in accordance with the standard EN378. Be sure to adopt adequate measures to prevent the unit from being used as a shelter by small animals.
  • Page 16 In case of strong wind and the wind direction can be fore- seen,refer to the figures below for installation of the unit(any one is OK): Turn the air outlet side toward the building's wall, fence or screen. NOTE Unit is top heavy! Try not to install on the building frame.
  • Page 17 Check the strength and level of the installation ground so that the unit may not cause any vibrations or noise during its operation. In accordance with the foundation drawing in the figure, fix the unit securely by means of foundation bolts. (Prepare four sets each of Φ10 Expansion bolts, nuts and washers which are readily available in the market.) Screw in the foundation bolts until their length is 20 mm from the foundation surface.
  • Page 19 If the water hardness is high install a system suitable to  confirming to local regulations preserve the unit from harmful deposits and limestone  Langelier (IL) index between 0 and +0.4 formations.  within the limits indicated by table If necessary, fit a water softener to reduce water hardness.
  • Page 20 Air purge valve Expansion vessel Pump Safety valve Manometer Flow switch Refrigerant gas connection Refrigerant liquid connection Plate heat exchanger Water outlet connection Water inlet connection 12.1 Electrical resistance 12.2 Electrical resistance 12.3 Electrical resistance TW_out Water temperature sensors TW_in Refrigerant temperature sensors...
  • Page 21 NOTE If the installation is equipped with a domestic hot water tank (optional), please refer to the domestic hot water tank Installation And Owner's Manual. If there is no glycol (anti-freeze) in the system there is a power supply or pump failure, drain the system (as shown in the figure below).
  • Page 22 NOTE In most applications this minimum water volume will be satisfactory. In critical processes or in rooms with a high heat load though, extra water might be required. When circulation in each space heating loop is controlled by remotely controlled valves, it is important that this minimum water volu- me is kept even if all the valves are closed.
  • Page 23 Example 1： The unit (16kW) is installed 5m below the highest point in the water circuit. The total water volume in the water circuit is 100 L. In this example, no action or adjustment is required. Example 2： The unit(16kW) is installed at the highest point in the water circuit. The total water volume in the water circuit is 250 L. Result: Since 250 L is more than 230 L, the pre-pressure must be decreased (see table above).
  • Page 24 Ice formation can cause damage to the hydraulic system. As the outdoor unit may be exposed to sub-zero temperatures, care must be taken to prevent freezing of the system. All internal hydronic parts are insulated to reduce heat loss. Insulation must also be added to the field piping. ...
  • Page 25 NOTE CounterclockWise rotation, remove the flow switch. Drying the flow switch completely. Mantenere asciutto CAUTION Use of glycol Glycol use for installations with a domestic hot water tank: Only propylene glycol having a toxicity rating or class of 1, as listed in "Clinical Toxicology of Commercial Products, 5th edition"...
  • Page 26  Connect the water supply to the fill valve and open the valve.  Make sure the automatic air purge valve is open (at least 2 turns).  Fill with water until the manometer indicates a pressure of approximately 2.0 bar. Remove air in the circuit as much as possible using the air purge valves.
  • Page 27 WARNING A main switch or other means of disconnection, having a contact separation in all poles, must be incorporated in the fixed wiring in accordance with relevant local laws and regulations. Switch off the power supply before making any connections. Use only copper wires.
  • Page 28 Outdoor unit P_d: DHW pump (not supplied) Solar energy kit (not supplied) SV2: 2-way valve (not supplied) User interface SV1: 3-way valve for domestic hot water tank (not sup- plied) Room thermostat (not supplied) Domestic hot water tank Boiler (not supplied) Booster heater P_s: Solar pump (not supplied) Contactor...
  • Page 29 Description N. conductors Maximum running current Solar energy kit signal cable 200mA User interface cable 200mA Room thermostat cable 2 or 3 200mA (a) Boiler control cable 200mA Thenrmistor cable for Tw2 DHW pump control cable 200mA (a) 2-way valve control cable 200mA (a) 10 11 23 3-way valve control cable 2 or 3...
  • Page 30 Coding Assembly unit High voltage wire hole Low voltage wire hole High voltage wire hole / low voltage Water outlet Water inlet Drainage pipe hole Safety valve drainage pipe hole Field wiring guidelines  Most field wiring on the unit is to be made on the terminal block inside the switch box. To gain access to the terminal block, remove the switch box service panel (door 2).
  • Page 31  Use a round crimp-style terminal for connection to the power supply terminal board. In case it cannot be used due to unavoidable reasons, be sure to observe the following instructions.  Do not connect different gauge wires to the same power supply terminal. (Loose connections may cause overheating.) ...
  • Page 32 CN11 CN11 Solar input Wired Controller Room thermostat Outdoor unit SV1 - 3-way valve 1OFF System parallel 2OFF SV2 - 3-way valve pump P_c (zone 2) pump P-o (zone 1) solar pump Unit signal in operation DFT2 HW PUMP Defrosting prompt signal DFT1 resistance TBH Antifreeze resistance...
  • Page 33 Port provide the control signal to the load.Two kind of control signal port: Type 2: Type 1 Port provide the signal with 220V voltage. Dry connector without voltage. Cable section: 0,75 mm If the current of load is <0.2A, load can connect to the port directly.
  • Page 34 Type 2 Type 2 TBH tank boost heater Connection of the booster heater cable depends on the application. NOTE Only when the domestic hot water tank is installed will this Wiring of the 3-way valve is different for NC (normal close) wiring be needed.
  • Page 35 Type 2 Type 2 Type 2 Type 2...
  • Page 36 Type 2 HEATING mode HEATING + DWH mode Photovoltaic signal Smart grid Unit is turned off. Unit works normally Forced unit in DHW, even if it was off, with temperature increased to 70 °C Forced unit in DHW...
  • Page 37 COMMUNICATION NOTE Use shielded wire and earth the wire. This equipment supports MODBUS RTU communication protocol. - See ATTACHMENTS Wire type 5 wire shielded cable Wire section (mm 0.75~1.25 Maximum wire length (m) Input voltage (A/B) 13.5VAC Do not install the unit in a place with much oil, steam, sulfide gas. Otherwise, the product may deform and fail.
  • Page 38 1) Use straight head screwdriver to insert in the buckling position in the bottom of wired controller, and spin the screwdriver to take down the back cover. (Pay attention to spinning direction, otherwise will damage the back cover!) 2) Use three M4X20 screws to directly install the back cover on the wall. 3) Use two M4X25 screws to install the back cover on the 86 electrician box, and use one M4X20 screws for fixing on the wall.
  • Page 39 Avoid the water enter into the wired remote controller, use trap and putty to seal the connectors of wires during wiring installation. Wiring Wall hole and wiring hole hole Diameter：ø8 --ø10 Putty Putty Putty Trap Trap Trap After adjusting the front cover and then buckle the front cover; avoid clamping the communication switching wire during installation. Sensor can not be affected with damp.
  • Page 40 There are three methods for connecting the thermostat cable and it depends on the application. CN11 Method A  On-Off + Heat from input H - L1  On-Off + Cool from input C - L1 User interface setting: ROOM THERMOSTAT and ROOM THERMOSTAT to MODE SET CN11 Method B ...
  • Page 41 The unit should be configured by the installer to match the installation environment (outdoor climate, installed options, etc.) and user expertise. CAUTION It is important that all information in this chapter is read sequentially by the installer and that the system is configured as applicable. The Climate related curves can be selected in the user The terms related to this unit are shown in the table below.
  • Page 42 T4: Outdoor Temperatures T1S: set water temperature It is curve number 9. It can be set as shown in the figure.
  • Page 43 T4: Outdoor Temperatures T1S: set water temperature It is curve number 9. It can be set as shown in the figure.
  • Page 44 WARNING Switch off the power supply before opening the switch box service panel and making any changes to the DIP switch settings. Work on the DIP switches with an insulated screwdriver, in order to avoid electrostatic discharges. ON = 1 OFF = 0 Factory configuration switch...
  • Page 45 On the wired control, access the menu: FOR SERVICEMAN - POWER INPUT LIMITATION During initial start-up and when water temperature is low, it is important that the water is heated gradually. Failure to do so may result in concrete floors cracking due to rapid temperature change. Please contact the responsible cast concrete building contractor for further details.
  • Page 46 When power to the unit is turned on, "1%~99%" is displayed on the user interface during initialization. During this process the user interface cannot be operated. The pump speed can be selected by adjusting the red knob on the pump. The notch point indicates pump speed.
  • Page 47 Pump Description Cause Remendy status Mains undervoltage Power supply too low on mains side Check mains voltage. Mains overvoltage Power supply too high on mains side Check mains voltage. Pump hydraulics have fluid running Generator operation Check the system through them. Check flow, install non-return valves Turbine operation The pump is driven in reverse...
  • Page 48 The unit shall be configured by the installer to match the installation environment (outdoor climate, installed options, etc.) and user demand. A number of field settings are available. These settings are accessible and programmable through “FOR SERVICEMAN” in user interface. Keys Function MENU...
  • Page 49 How to set the DHW mode To determine whether the DHW mode is effective. Go to MENU> FOR SERVICEMAN> DHW MODE SETTING. Press OK. The following page is displayed: How to set the Heat mode To determine whether the HEAT mode is effective, go to MENU >...
  • Page 50 Only ROOM TEMP = YES How to set the AUTO mode To determine whether the AUTO mode is effective, go to MENU > FOR SERVICEMAN > AUTO MODE SETTING. Press OK. The following page is displayed. WATER FLOW TEMP = YES ROOM TEMP = YES Zone 1 Zone 2...
  • Page 51 HOLIDAY AWAY setting About setting About room thermostat The HOLIDAY AWAY SETTING is used to set the outlet water The ROOM THERMOSTAT is used to set whether the room temperature to prevent freezing when away for holiday.. thermostat is available. How to enter the setting How to set the room thermostat To enter the HOLIDAY AWAY SETTING, go to MENU >...
  • Page 52 If YES is selected, the following page is displayed: The RESTORE FACTORY SETTING is used to restore all the parameters set in the user interface to the factory setting. To restore factory settings, go to MENU > FOR SERVICEMAN > RESTORE FACTORY SETTINGS. Press OK.
  • Page 53 When the HEAT MODE RUNNING is selected, the page will If you select AIR PURGE : displayed as follows: When in air purge mode, the 3-way valve will open, the 2-way valve will close. During HEAT MODE test running, the default target outlet 60s later the pump in the unit (PUMPI) will operate for 10min water temperature is 35°C.
  • Page 54 When special functions are active, the wired controller cannot operate , it is not possible to return to the homepage and the screen shows the page where the specific function is running. During preheating for floor, all the buttons except OK are NOTE invalid.
  • Page 55 When the cursor is on OPERATE FLOOR DRYING? Use UP DOWN to scroll to YES and press OK. The page will be displayed as follows: The AUTO RESTART function is used to select whether the unit reapplies the user interface settings at the time when power returns after a power supply failure.

  • Page 56: Installation

    The installer is obliged to verify correct operation of unit after installation. Final check Before switching on the unit, read following recommendations:  When the complete installation and all necessary settings have been carried out, close all front panels of the unit and refit the unit cover.
  • Page 57 setting Code State Default unit interval DHW MODE Enable or disable the DHW mode:0=NON,1=YES DISINFECT Enable or disable the disinfect mode:0=NON,1=YES DHW PRIORITY Enable or disable the DHW priority mode:0=NON,1=YES DHW PUMP Enable or disable the DHW pump mode:0=NON,1=YES DHW PRIORITY TIME Enable or disable the DHW priority time set:0=NON,1=YES dT5_ON The temperature difference for starting the heat pump...
  • Page 58 setting Code State Default unit interval The ambient temperature 1 of climate related curves for 2.10 T4C1 °C cooling mode. The ambient temperature 1 of climate related curves for 2.11 T4C2 °C cooling mode. The type of zone1 end for cooling mode：0=FCU(fan coil 2.12 ZONE1 C-EMISSION unit)，1=RAD.(radiator)，2=FLH(floor heating)
  • Page 59 setting Code State Default unit interval The temperature difference betw een T1S and T1 for dT1_IBH_ON °C starting the backup heater. The time that the compressor has run before the first t_IBH_DELAY backup heater turns on T4_IBH_ON The ambient temperature for starting the backup heater °C The temperature difference between T1S and TW2 for dT1_AHS_ON...
  • Page 60 setting Code State Default unit interval Define the CN12 port,0= REMOTE ON/OFF,1= TBH ON/OFF 15.1 CN12 ON/OFF 2= AHS ON/OFF 15.2 SMART GRID Enable or disable the SMART GRID. 0=NON ； 1=YES Enable or disable the T1b (Tw2) 15.3 T1b (Tw2) 0=NON,1=YES Enable or disable the Tbt1;...
  • Page 61 DANGER Risk of fire / flammable materials 1) Checks to the area Prior to beginning work on systems containing flammable refrigerants, safety checks are necessary to ensure that the risk of ignition is minmised. For repair to the refrigerating system, the following precautions shall be complied with prior to conducting work on the system.
  • Page 62 Initial safety checks shall include:  That capacitors are discharged: this shall be done in a safe manner to avoid possibility of sparking;  That there no live electrical components and wiring are exposed while charging, recovering or purging the system; ...
  • Page 63 14) Removal and evacuation When breaking into the refrigerant circuit to make repairs of for any other purpose conventional procedures shall be used, However, it is important that best practice is followed since flammability is a consideration. The following procedure shall be ...
  • Page 64 18) Labelling Equipment shall be labelled stating that it has been de-commissioned and emptied of refrigerant. The label shall be dated and signed. Ensure that there are labels on the equipment stating the equipment contains flammable refrigerant. 19) Recovery  When removing refrigerant from a system, either for service or decommissioning, it is recommended good practice that all refrigerants are removed safely.
  • Page 65 Check that the backup heater insulation cover is fastened be carried out at regular intervals. tightly around the backup heater vessel. This maintenance has to be carried out by your local Clivet  Domestic hot water tank pressure relief valve (field technician.
  • Page 66 WARNING Switch off all power i.e. unit power supply and backup heater and domestic hot water tank power supply before removing doors 1 and 2. Parts inside the unit may be hot. Push the grill to the left until it stops, then pull its right edge, so you can removed the grill. You can also reverse the procedure.

  • Page 67: Water Connections

    This section provides useful information for diagnosing and correcting certain troubles which may occur in the unit. This troubleshooting and related corrective actions may only be carried out by your local technician. Before starting the troubleshooting procedure, carry out a thorough visual inspection of the unit and look for obvious defects such as loose connections or defective wiring.
  • Page 68 The unit is turned on but the compressor is not starting (space heating or domestic water heating) POSSIBLE CAUSES CORRECTIVE ACTION In case of low water temperature, the system utilizes the backup heater to reach the minimum water temperature first (12°C). The unit must start up out of its ...
  • Page 69 Space heating capacity shortage at low outdoor temperatures Check that the "OTHER HEATING SOURCE/ BACKUP HEATER"is enabled, see chapter 9 Start-up and configuration - OTHER HEATING SOURCE. Check whether or not the thermal protector of the backup heater has been activated (see chapter to Backup heater operation is not Electronic board layout - main control board to thermal protector of the backup heater for location of activated.
  • Page 70 This menu is for installer or service engineer reviewing the operation parameter.  At home page, go to ''MENU''>''OPERATION PARAMETER''.  Press ''OK''.  There are five pages for the operating parameter as following. Use UP DOWN scroll. INFORMATION The power consumption parameter is preparatory. Some parameter is not be activated in the system, the parameter will show "--"...
  • Page 71 When a safety device is activated, an error code will be displayed on the user interface. A list of all errors and corrective actions can be found in the table below. Reset the safety by turning the unit OFF and back ON. In case this procedure for resetting the safety is not successful, contact your local dealer.
  • Page 72 ERROR MALFUNCTION OR FAILURE CAUSE AND CORRECTIVE ACTION CODE PROTECTION 1. The Tbt1sensor connector is loosen. Re connect it. 2. The Tbt1sensor connector is wet or there is water in. remove the water, make Tbt1 sensor error the connector dry. Add waterproof adhesive 3.
  • Page 73 ERROR MALFUNCTION OR FAILURE CAUSE AND CORRECTIVE ACTION CODE PROTECTION 1. The EEprom parameter is error, rewrite the EEprom data. The main control board of 2. EEprom chip part is broken, change a new EEprom chip part. hydraulic module EEprom failure 3.
  • Page 74 ERROR MALFUNCTION OR FAILURE CAUSE AND CORRECTIVE ACTION CODE PROTECTION 1. Check that the power supply values are in the available range. 2. The unit was turned on and off several times at close intervals. Keep the unit Main circuit voltage failure turned off for at least 3 minutes before turning it on again.
  • Page 75 ERROR MALFUNCTION OR PROTECTION FAILURE CAUSE AND CORRECTIVE ACTION CODE 1. System is lack of refrigerant volume. Charge the refrigerant in right volume. 2. When at heating mode or heat water mode, Heat exchanger is dirty or something is block on the surface. Clean the heat exchanger or remove the obstruction.
  • Page 76 ERROR MALFUNCTION OR FAILURE CAUSE AND CORRECTIVE ACTION CODE PROTECTION 1. Check that all shut off valves of the water circuit are completely open. 2. Check if the water filter needs cleaning. 3. Refer to chapter WATER CONNECTIONS - Charging water" 4.
  • Page 77 ERROR MALFUNCTION OR FAILURE CAUSE AND CORRECTIVE ACTION CODE PROTECTION Anti-freeze mode protection Unit will return to the normal operation automatically. 1. The water inlet/outlet sensor wire connector is loosen. Reconnect it. 2. The water inlet/outlet （TW_in /TW_out） sensor is broken, Change a new Water inlet temperature is higher sensor.
  • Page 78 Keys Function MENU Access to the menu structure (from the screen) Moving the cursor on the display LEFT - RIGHT  Movement within the menu structure UP DOWN  Adjustment of parameter settings Turn on/off the space heating/cooling operation or DHW mode Turn on/or off functions in the menu ON/OFF structure Activation / deactivation of functions in the menu structure...
  • Page 79 Key lock The compressor is activated At the next scheduled action, the temperature will Pump active decrease The temperature not change Weekly schedule The temperature will decrease Time schedule The temperature will increase Outdoor temperature Fan coil Wi-Fi Radiator Domestic hot water (DHS) Floor heating (radiant panels) Disinfect function (anti-legionella) active Switch on...
  • Page 80 Away / at home holiday Anti-freeze mode active Defrosting mode active Silent mode active ECO mode active active Fan coil Radiator Radiant panels Energy cost Free High Smart grid Energy source Photovoltaics From the network From the network Energy absorbed Average Average Peak...
  • Page 81 When you turn on the wired controller, the system will enter the language selection page, You can choose your preferred language, then press OK to enter the home pages. If you don't press OK in 60 seconds, the system will enter in the currently selected language. Depending on the system layout, the following home pages may be possible: ...
  • Page 82 The system includes the floor heating and domestic hot water function. Type 2 home page appears 23,5°C= desired ambient temperature SERVICEMAN menu Temp type setting Temp. Water flow NO Ambient Temp. NOTE It is necessary to install the wall-mounted control unit in the floor heating room to make it possible to control ambient temperature. The system provides floor heating and ambient heating for the fan coil unit.
  • Page 83 The system includes the cooling, ambient cooling function for the fan coil unit and domestic hot water. There is a main page and an additional one. 13°C= desired water flow temperature zone 1 23°C= actual DHW tank temperature SERVICEMAN menu Ambient thermostat TWO ZONES YES 23°C= desired water flow temperature zone 2...
  • Page 84 * Access by pwd is reserved to qualified personnel; The parameters changes may cause malfunctions.

  • Page 85: Service Information

    If the UNLOCK icon is on the screen, the controller is locked. Use the UNIT INTERFACE. The following page appears It is possible to control the activation / deactivation of the unit via the interface if AMBIENT THERMOSTAT = NO. Press LEFT and UP on the home page, the black cursor appears.
  • Page 86 If TYPE TEMP = AMBIENT TEMP. , the following pages are displayed: Use the AMBIENT THERMOSTAT. Use the interface to activate / deactivate the unit for the DHS. 1 - AMBIENT THERMOSTAT = NO. Press RIGHT and DOWN on the home page, the black cursor appears: Press LEFT and UP on the home page, the black cursor appears.
  • Page 87 If the ambient operation mode is deactivated (OFF), the following pages are displayed: Press LEFT and UP on the home page, the black cursor appears. If the cursor is on the temperature, use LEFT and RIGHT to select and use UP and DOWN to adjust the temperature.
  • Page 88 Go to MENU > OPERATION MODE. Go to MENU > OPERATION MODE - OK If you press any key, the following page is displayed: The following page is displayed: It is possible to select three modes: HEAT mode, COOL mode, AUTO mode. Use LEFT and RIGHT to scroll, press OK to select.
  • Page 89 INFORMATION Use LEFT RIGHT, UP and DOWN to scroll. When the ambient operation mode is changed, DEFAULT Use UP and DOWN to adjust the time and temperature. TEMP. switches off automatically. When the cursor is as shown in the figure, press OK. It is possible to use the DEFAULT TEMP function in HEAT or Timer 1 is selected.
  • Page 90 To use the HEAT mode in zone 1, select LOW HOT MODE ZONE 1 TEMP. To use the COOL mode in zone 1 select LOW COLD MODE ECO mode saves energy. ZONE 1 TEMP. MENU > PRESET TEMPERATURE > ECO MODE > If ON is selected, the following page is displayed: Press OK.
  • Page 91 INFORMATION SET. ECO MODE has two types of curves: the high temperature setting curve for heating the low temperature setting curve for heating If the high temperature for heating is set: it only has the high temperature setting curve for heating. If the low temperature for heating is set: it only has the low temperature setting curve for heating.
  • Page 92 INFORMATION INFORMATION If CURRENT STATUS is deactivated (OFF), the FAST DHW If CURRENT STATUS is deactivated (OFF), TANK HEATER function is not valid, while if it is active (ON) the FAST DHW cannot be activated. function is active. If the T5 tank sensor is in failure, the tank heater cannot work. The FAST DHW function is activated once.
  • Page 93 The setting is the following: Use LEFT RIGHT and UP DOWN to scroll and UP DOWN to adjust the time, mode and temperature. Move and press OK to select / deselect. 6 timers can be set. To cancel the TIMER, move the cursor and press OK. If the set start time is later than the end time (or if the temperature is not within mode range), the following page is displayed:...
  • Page 94 INFORMATION If the start and end times in a timer coincide, the timer is not valid. If the timer function is on and the weekly schedule is off, the most recent setting is effective. If the WEEKLY PROGRAM. It is activated, the related icon appears on the home page.
  • Page 95  TIMER or WEEKLY PROGRAM. they are not valid when ECO or COMFORT are activated. TIMER or WEEKLY PROGRAM. . they are activated when ECO or COMFORT are not in operation.  TIMER or WEEKLY PROGRAM. have the same priority. The function with the most recent setting is valid.
  • Page 96 Use ON-OFF to select active (ON) or disabled (OFF). Go to MENU > OPTIONS > HOLIDAY AWAY. If CURRENT STATUS is set to OFF, SILENT MODE is Press OK. invalid. The following page is displayed: When you select SILENCE LEVEL and press OK or RIGHT, the following page is displayed: Example: ...
  • Page 97 INFORMATION INFORMATION It is necessary to restore Holiday away or Holiday at home if  The remote control does not accept commands when the operating mode of the unit is changed. holiday away mode is active (ON).  Unit disinfecting is completed at 23:00 on the last day, if the related function is activated.
  • Page 98 This function allows you to prevent children from using the unit incorrectly. It is possible to lock or unlock the setting of the modes and control temperature regulation using the CHILD LOCK function. Select MENU> CHILD LOCK. The following page is displayed: Enter your current password.
  • Page 99 The menu includes the following items: 1. SERVICE CALL 2. ERROR CODE 3. PARAMETERS 4. VIEW How to access the menu INFORMATION Select MENU> SERVICE INFORMATION. It is possible to record a maximum of 8 error codes Press OK The following page is displayed: The parameter function allows you to view the main Service call can contain a phone or mobile phone number.
  • Page 100 This menu is reserved for the installer or the service technician who checks the operating parameters. Select MENU> OPERATING PARAMETERS Press OK. There are 6 pages relating to the operating parameters. Use UP DOWN to scroll. INFORMATION Entering the energy consumption parameter is optional. Parameters not activated in the system are marked with "--".
  • Page 101  The keyboard has an intelligent control system based on a This menu is reserved for the installer or the service built-in module, which receives control signal from the technician. APP. Select MENU> FOR SERVICEMAN.  Before connecting to the WLAN, check if your router is Press OK.

  • Page 102: Trouble Shooting

    Reset the WLAN setting using the interface. Adding home equipment. Select MENU> WLAN SETUP> RESTORE WLAN 1. Choose the control unit model, then add the device SETTINGS. 2. Configure the control unit following APP instructions. Press OK. The following page is displayed: Use LEFT RIGHT to move to YES.
  • Page 107 Cascade operation allows up to 6 units to be connected in parallel, thereby ensuring that the system is fully reliable and efficient. The Master unit controls and displays the parameters of the entire system on its User Interface, activating the Slave units when its capacity is not enough to fulfil the system load.
  • Page 108 Cooling, Heating and DHW logic there can be up to 2 units in defrosting mode at the same The unit’s control system can monitor and display the operations time. of the whole system only by connecting the Master unit to the When these units have completed the defrosting stage, the HMI user interface.
  • Page 109 Connections shielded cable – earthed display heater for network termination on last unit The Slave units are automatically addressed and they do not need to be addressed manually. For the automatic addressing function to work properly, the units must be connected to the same power supply, shielded and then turned on together.
  • Page 110 Communication protocol: ModbusRTU : 9600 , 8, N, 1 Baud rate: 9600 bps Data bits : 8 Data bits Check digit : None Parity Stop bit: 1 stop bit PC and wired remote supports only one connection, wire is made from the unit. The address of the remote control and the address of the hydraulic module (the hydraulic module selects the address by dialing code ) should be the same .
  • Page 111 The remote controller can be connected to the host computer or not. As a slave, the line controller communicates normally with the host computer when it is connected to the host computer; when the host computer is not connected, the line controller does not send data or report a communication failure with the host computer. Register address Data content Remarks...
  • Page 112 BIT15 Reserved BIT14 Reserved 1: curve setting enable; 0: curve setting disable BIT13 (Zone2) 1: curve setting enable; 0: curve setting disable BIT12 (Zone1) DHW pump's running constant-temperature water BIT11 recycling BIT10 ECO mode BIT9 Reserved Holiday home (the status can only be read, not BIT8 Function setting changed)
  • Page 113 Register address Data content Remarks Operating frequency Compressor operating frequency in Hz The actual operation mode of the whole unit, 2 : cooling , Operating mode 3 : heating , 0 : OFF Fan speed Fan speed, unit r/min PMV opening External machines electronic expansion valve opening degree , the unit: P Inlet water temperature TW_in , unit: °C.
  • Page 114 BIT15 Reserved BIT14 Reserved BIT13 Reserved BIT12 Reserved BIT11 1: Free electricity 0 : judge based on SG signal BIT10 1 : normal electricity 0 : high price electricity ( judgment when EVU is 0 ) BIT9 Water tank anti-freezing reserved Status bit 1 BIT8 Solar signal input...
  • Page 115 Water flow Actual value *100 unit: M3/H External unit frequency Solution value ----- external unit feedback 174 limiting scheme Hydraulic module capacity Actual value *100 unit: Kw value Solar sensor temperature Unit online number infor- BIT1-BIT15 respectively represent the online status of slaves 1-15 mation BIT0 reservation High battery value...
  • Page 116 BIT15 Enable hot water BIT14 Support water tank electric heating TBH (read only) BIT13 Support sterilization function Whether to support DHW PUMP, BIT12 1 : support; 0 : not support BIT11 Reserved BIT10 DHW pump supports Pipe Disinfect BIT9 Cooling enable T1S cooling high / low temperature setting (read only) BIT8 Zone1...
  • Page 117 T4DHWmin Default: - 25°C, the range of - 25 -5°C, adjusted spacing 1°C t_TBH_delay Default: 30 min Range: 0~240min ; adjustment interval 5min dT5S_TBH_off Default: 5°C, range: 0 ~ 10°C, adjustment interval 1°C T4_TBH_on Default: 5°C, range: -5~20°C, adjustment interval 1°C Sterilization function water tank set temperature, setting range 60~70°C, default 65°...
  • Page 118 TBH power Range 0-200 , default 0 , unit 100W Comfort parameters Reserved, query the register to report an address error Comfort parameters Reserved, query the register to report an address error t_ DRYUP Heating days, setting range: 4~15days , default 8 days t_ HIGHPEAK Drying days, setting range: 3~7days , default 5 days t_ DRYD...
  • Page 119 Register address Data content Remarks The actual operation mode of the whole unit, 2 : cooling, 1000 Operating mode 3 : heating, 0 : shutdown 1001 Operating frequency Compressor operating frequency in Hz . Send value = actual value 1002 Inlet water temperature TW_in , unit: °C.
  • Page 120 Total outlet temperature, unit: °C. Send value = actual value invalid value 1011 0x7F Total water output of the system (after auxiliary heat source), unit: °C. 1012 Send value = actual value invalid value 0x7F Refrigerant liquid side temperature , unit: °C. Send value = actual value 1013 invalid value 0x7F Temperature of refrigerant gas side , unit: °C.

  • Page 121: 15 - General Technical Data

    15 - General technical data Performance SIZE Power supply 400/50/3+N RADIANT PANELS Heating 16,3 18,0 22,0 26,0 30,1 Heating capacity (EN 14511:2018) 3,63 3,83 5,00 6,37 7,70 Total power input (EN 14511:2018) 4,49 4,70 4,40 4,08 3,91 COP (EN 14511:2018) ErP Space Heating Energy Class - 8,11 A+++...
  • Page 122 General technical data Construction SIZE Compressor Type of compressors Rotary Inverter DC Refrigerant No. of compressors Oil charge Refrigerant Charge User side exchanger Type of internal exchanger Water content 1,01 External Section Fans Type of fans Brushless DC motor No. of fans Standard airflow 1710 2958...
  • Page 123 General technical data Sound levels - Standard Mode Sound power level Sound Sound pressure power level level SIZE Octave band (Hz) Sound levels refer to units with full load under nominal test conditions. The sound pressure level refers to a distance of 1 meter from the outer surface of the unit operating in open field. Noise levels are determined using the tensiometric method (UNI EN ISO 9614-2).
  • Page 124 General technical data Operating range Cooling Twu [°C] = Leaving exchanger water temperature Tae [°C] = External exchanger inlet air temperature Normal operating range Heating Twu [°C] = Leaving exchanger water temperature Tae [°C] = External exchanger inlet air temperature Normal operating range Operating range with only back-up heate Operating range with the Hybrid version of the condensing boiler...
  • Page 125 General technical data Admissible water flow rates SIZE Minimum flow-rate Qmin [l/s] 0,48 0,54 0,66 0,78 0,90 Maximum flow-rate Qmin [l/s] 0,92 1,03 1,26 1,49 1,72 Fouling Correction Factors Internal exchanger m²C/W 0,44x10 (-4) 0,88x10 (-4) 0,96 0,99 1,76x10 (-4) 0,93 0,98 The cooling performance values provided in the tables are based on the external exchanger having clean plates (fouling factor 1).

  • Page 126: Dimensional Drawings

    Dimensional drawings DABPB0001_0 Size 91-141 Three Phase DATA/DATE 14/05/2020 Compressor compartment Electrical panel Power input Functional spaces Electric fan (supply - return) Internal exchanger water inlet (OD = 1” 1/4 GAS M) Internal exchanger water outlet (OD = 1” 1/4 GAS M) Support point Drain hole (M) Air Supply...
  • Page 128 Via Camp Lonc 25, Z.I. Villapaiera 32032 Feltre (BL) - Italy Tel. +39 0439 3131 - Fax +39 0439 313300 info@clivet.it...
