Summarization of Contents
Getting started
Important safety information
Cautions and notes to minimize risk of personal injury to service personnel.
Important service information and precautions
Guidelines for professional service technicians regarding repairs and precautions.
RoHS (2002/95/EC) requirements
Legal requirement for electronics products regarding hazardous substances.
Firmware updates
Information on where to find and apply monitor firmware updates.
Before returning the repaired product to the customer
Procedure for AC leakage current check before returning the product.
Monitor features
Features
Overview of monitor capabilities including screen size, resolution, connectivity, and software.
Front components
Identifies and describes the components located on the front of the monitor.
Rear components
Identifies and describes the components located on the rear of the monitor.
Locating the serial number and product number
Information on how to find the serial and product numbers on the monitor's rating label.
Illustrated parts catalog
How to order parts
Information on ordering replacement parts, including component distributors and part numbers.
Removal and replacement procedures
Preparation for disassembly
Steps to prepare the workspace and equipment for monitor disassembly.
RC removal
Steps to remove the RC component from the monitor.
Connector repair
Procedures for repairing VGA and HDMI connectors on the main board.
Function test
Procedure to confirm all monitor functions are working after repair.
Support and troubleshooting
Solving common problems
Table listing common monitor problems, their causes, and recommended solutions.
