Summarization of Contents
Application
Check before starting measurement / test
Perform checks on wiring, test movements manually, and test automatic movement before starting operation.
Speed setting
Adjustable speed setting for the test bench, with the set speed displayed on the screen.
Presettable cycles
Allows setting a number of cycles to run automatically, displayed and resettable via control keys.
RS 232 connection
Enables connection to force gauges and PCs for control, data evaluation, and overload prevention.
Limit switch
Stops movement at limit switches in manual mode and at perimeter switch in auto mode.
Assembly instructions for the test system
Internal load cell assembly
Describes mounting force gauges with internal sensors using adapter plates to the crosshead.
External load cell assembly (TVM 5000N230N/NL & TVM 10KN120N)
Details mounting external load cells using AFM 41 bracket and connecting the measuring cell.
External load cell assembly (TVM 20KN100 & TVM 30KN)
Explains mounting external load cells for specific TVM models using the AFM 41 bracket.
Test bench wiring
Connects the force gauge to the test stand via the equipment port using an RS232 cable.
Cabling TVM with force and length measuring devices
Guides on wiring the force gauge and connecting the linear encoder to a PC via USB-RS232 adapter.
